slide-1
SLIDE 1

An Assist with Design-Assist and Lean Construction: Closing Design Gaps Through Collaboration

Brian Perlberg Executive Director of ConsensusDocs

56th Annual Meeting of Invited Attorneys

Chicago, Illinois May 25 – 26, 2017

In partnership with

slide-2
SLIDE 2

58th Annual Meeting of Invited Attorneys

Why Design-Assist?

  • Common Goal

– Moves complex projects from design to construction for successful project, especially complex envelop design

  • Proactive Approach

– Key subcontractors provide early design support

  • Collaborative

– Typically used with CM at Risk, synonymous with CM@R subcontracting, works well using design- build MEP, plus more

slide-3
SLIDE 3

58th Annual Meeting of Invited Attorneys

Design-Assist Added Value

  • Utilizes trade contractor expertise EARLIER in the process
  • Promotes high quality set of design documents
  • Mitigates RFIs, field issues, and change orders
  • Avoid redesign
  • Improves pricing estimating accuracy
  • Reduces constructability issues
  • Initial step towards collaborative delivery methods such as IPD
  • Informs Owner with organized info, earlier
slide-4
SLIDE 4

58th Annual Meeting of Invited Attorneys

May 20, 2019

Design-Assist Challenges

  • Competitive Pricing Perception
  • Design liability
  • Added time and cost at design phase
  • Design Professional concerns over diminished design role

– “Who is on first, What is on 2nd”

  • Subcontractor administration
  • Procurement limitations
  • “FreeCon” PreCon = U get what = What you pay for.
slide-5
SLIDE 5

58th Annual Meeting of Invited Attorneys

ConsensusDocs 541 Design Assist Addendum Published Sept. 2019

slide-6
SLIDE 6

58th Annual Meeting of Invited Attorneys

How is this Different that IPD?

Owner CM/GC Key Trades

IPD CD 300

Owner

CM/ GC

Design Prof. Trade Contractors

IPDish CD 541 & 305

Specialty Designers

CD305

DP

CD 541 Or Both

Key Design Consultants

slide-7
SLIDE 7

58th Annual Meeting of Invited Attorneys

Addendum vs. Silence

  • Contracting in first collaborative act
  • Increase alignment among parties
  • Parameters for Lean behavior and activities
  • Some Lean methods conflict with standard contract language

– Avoid the “two schedule approach” one for the contract and

  • ne we really use
  • Allows enforcement of Lean requirements, but not contract

shouldn’t be a collaboration hammer.

slide-8
SLIDE 8

58th Annual Meeting of Invited Attorneys

CD 541 Design Assist Services

  • Owner’s Program Evaluation
  • Constructability
  • Cost Estimating

– Fixed vs. Continuous

  • Value Analysis vs. Value Engineering

– The good kind, not just subtracting scope or a race to the bottom

  • Schedule and Manpower Analysis.
slide-9
SLIDE 9

58th Annual Meeting of Invited Attorneys

Design Assist Subcontractors and Recommendation of Design-Assist Subcontracts

  • Selection of Design-Assist trades

– Which trades? When? How?

  • Design Coordination

– If everyone is in charge, no one is in charge – Avoid weasel words

  • Design Criteria Standards
  • Design-Build Trade Packages

– Owner, DP, and CM jointly decide which packages will be design-build.

slide-10
SLIDE 10

58th Annual Meeting of Invited Attorneys

CD 541 Design Assist Addendum Overview

  • BIM
  • Compensation
  • Optional risk analysis
  • Optional production planning

– Lean Design – Pull planning leads to pull scheduling.

slide-11
SLIDE 11

58th Annual Meeting of Invited Attorneys

Responsibility Matrix (Example 1)

slide-12
SLIDE 12

58th Annual Meeting of Invited Attorneys

Responsibility Matrix (Example 2)

Primary Review Due Date Source

Specification Design Criteria for Package Design of major Interfaces Detailed design and Permit Construction Documents (Stamp documents) Contribute toward Permit Construction Documents Fully Coordinated shop drawings Connection Detailing Produce all installation details Produce dimensioned and coordinated 2D drawing Shop Drawings for Review by A/E BIM Models where required for Review by A/E

DA ‐ Design Assistance from Sub‐Contractor

slide-13
SLIDE 13

58th Annual Meeting of Invited Attorneys

Design-Assist Services Possible Deliverables

  • Life Cycle Cost Analysis
  • Sustainable Design Recommendations
  • Risk Analysis
  • Design for Production Planning
slide-14
SLIDE 14

58th Annual Meeting of Invited Attorneys

Case Study Academy Museum of Motion Pictures and Sciences – Los Angeles, CA

slide-15
SLIDE 15

58th Annual Meeting of Invited Attorneys

Complex core and shell and envelope design coupled with an aggressive schedule fostered need for design assist subcontracting of Concrete, Architectural Precast, and Steel and Glass Façade.

Case Study Academy Museum of Motion Pictures and Sciences – Los Angeles, CA

slide-16
SLIDE 16

58th Annual Meeting of Invited Attorneys

Positives – Early involvement of key subcontractors – Constant collaboration – Earlier budgeting – Earlier focus on constructability, safety, and field issues – Earlier start of mock ups – Earlier cross collaboration among design-assist subcontractors – Earlier generation of shop drawings – Earlier fabrication of materials – Fewer RFI’s and change orders

Case Study Academy Museum of Motion Pictures and Sciences – Los Angeles, CA

slide-17
SLIDE 17

58th Annual Meeting of Invited Attorneys

Example of how Design-Assist can help your construction projects final construction.

slide-18
SLIDE 18

58th Annual Meeting of Invited Attorneys

Best in Class Projects

  • Early involvement of core team
  • Quals-based selection
  • Transparency in cost accounting.
slide-19
SLIDE 19

58th Annual Meeting of Invited Attorneys

May 20, 2019

The “Collabometer”

Design Assist

“Collabometer”

Courtesy of Jack Mumma Michigan State University

slide-20
SLIDE 20

58th Annual Meeting of Invited Attorneys

Chronology of ConsensusDocs 300 IPD Project

slide-21
SLIDE 21

58th Annual Meeting of Invited Attorneys

Risk Pool Plan

Risk Pool

Risk Pool Members Owner

slide-22
SLIDE 22

58th Annual Meeting of Invited Attorneys

Program Services & Validation

slide-23
SLIDE 23

58th Annual Meeting of Invited Attorneys

Integrated Design & TVD

slide-24
SLIDE 24

58th Annual Meeting of Invited Attorneys

CD305 Check-the-Box Example 1

slide-25
SLIDE 25

58th Annual Meeting of Invited Attorneys

Construction Phase Lean Features

Article 7 of CD 305 –Quality, Standardized Work, PDCA –Material Flow –Information Flow –5S Plan

slide-26
SLIDE 26

58th Annual Meeting of Invited Attorneys

Sort Set in Order Shine/Sweep Standardize Sustain

5S Plan

slide-27
SLIDE 27

58th Annual Meeting of Invited Attorneys

Takeaways

  • Culture is Important
  • Conform the Contract to the Process
  • (not the other way around)
  • Collaboration and Communication

Reduces Risk + Cost of the Risks

  • Incentivize the Right Behaviors.
slide-28
SLIDE 28

58th Annual Meeting of Invited Attorneys

Questions?

Brian Perlberg

Executive Director & Sr. Counsel ConsensusDocs

bperlberg@consensusdocs.org 703-837-5318

For More Info

www.ConsensusDocs.org

support@consensusdocs.org

866-925-3627
