The Woodlands Township Pavement Management Plan

1

Pavement Management Plan

• Study Objectives
• Study Approach
• Benefits
• Existing Pavement Conditions
• Budget Analyses

Pavement Management Plan

2

Pavement Management Plan

Study Objectives

• Understanding of the current roadway condition
• Development of a pavement management

system

• Performing a network-level pavement condition

survey

• Applicable software to identify future M&R

needs.

• Future maintenance costs

Good Condition Poor Condition

3

Pavement Management Plan

Study Approach

• Implemented the Paver™ system roadway

pavement network.

• Pavement Condition Index (PCI) Survey

Performed a network-level field condition survey and established a PCI

• f the Township’s roadway pavements.
• Roadway Pavement M&R Budget Analyses

Performed five-year budget analyses of multiple scenarios using Paver™ to determine future needs of alternative scenario.

4

Pavement Management Plan

Benefits of a Pavement Management Program

• Quantify Maintenance & Rehabilitation (M&R) budget
• Evaluate different budget scenarios
• Analyzing cost effectiveness of alternative strategies.
• Establish an objective funding program
• Establish Central repository for inventory data.
• Schedule timely M&R activities.

5

Pavement Management Plan

Condition Assessment Scale

Condition Assessment PCI Value

Excellent 98-100 Very Good 90-99 Good 80-89 Satisfactory 60-79 Fair 60-69 Unsatisfactory 40-59 Failed 0-39

Existing Pavement Conditions

6

Pavement Management Plan

Pavement Surface Type Inspected Pavement Area (SY) Pavement Area (%) 2018 Average PCI Asphalt 62,444 0.96 64.3 Concrete 6,425,152 99.03 95.0

Existing Pavement Conditions and Field Observations

Table 1: Pavement Condition Distribution of Each Surface Type

7

Pavement Management Plan

Results for Concrete Pavement 5-year Capital Improvements: $6,250,500 § Reconstruction: $1,250,000/year § Preventative Maintenance: $550,000/year Results for Asphalt Pavement 5-year Capital Improvements: $2,500,000 § M&R $500,000/year Five-year Capital Improvements for both Concrete and Asphalt Streets in The Woodlands: § $11,500,000

Maintenance & Rehabilitation Budget Analyses

8

Pavement Management Plan

Alternative Annual M&R Budget Scenarios Resultant PCI (2019 – 2023) Classification $1,800,000/Year (Eliminates Backlog

• f about $6.7M)

95.0 – 91.3 Excellent $1,300,000/Year (Reduces Backlog to about $3.5M) 94.2 – 89.7 Excellent $1,100,000/Year (Reduces Backlog to about $5.0M) 94.2 – 89.5 Good $800,000/Year (Backlog Increases to about $6.6M) 94.2 – 89.4 Good $0/Year (Backlog Increases to about $8.2M) 94.1 – 89.3 Good

Table 2: Effect of Budget on Overall Concrete Pavement Conditions

This table is a projection of pavement condition based on several selected M&R budgets.

Budget Analyses

9

Pavement Management Plan

Alternative Annual M&R Budget Scenarios for Asphalt Pavements Resultant PCI (2019 – 2023) Classification $500,000/Year (Eliminates Backlog of about $2.5M) 64.5 - 80.1 Satisfactory $400,000/Year (Reduces Backlog to about $0.75M) 64.1 – 75.2 Satisfactory $300,000/Year (Reduces Backlog to about $1.50M) 63.6 – 66.7 Fair $200,000/Year (Backlog Increases to about $2.25M) 62.2 – 59.6 Fair $0/Year (Backlog Increases to about $3.50M) 60.5 – 54.2 Unsatisfactory

Table 3: Effect of Budget on Overall Asphalt Pavement Conditions

This table is a projection of pavement condition based on several selected M&R budgets.

Budget Analyses

10

Pavement Management Plan

Budget Analyses

• Concrete 100 Year Life Span
• Built Over 40+ Year Period
• Plan for 2060
• $2,125,000/Year Yields $180,414,500

Stop Gap Fund

• Unforeseen Damage

Flooding Utility Breaks Etc.

• Budget $500,000 Annually
