The Tor Project, Inc. Our mission is to be the global resource for technology, advocacy, research and education in the ongoing pursuit of freedom of speech, privacy rights online, and censorship circumvention. 1 What is Tor? Online anonymity

slide-1
SLIDE 1

1

The Tor Project, Inc.

Our mission is to be the global resource for technology, advocacy, research and education in the ongoing pursuit of freedom

  • f speech, privacy rights online, and

censorship circumvention.

slide-2
SLIDE 2

2

What is Tor?

Online anonymity 1) open source software, 2) network, 3) protocol Community of researchers, developers, users, and relay operators Funding from US DoD, Electronic Frontier Foundation, Voice of America, Google, NLnet, Human Rights Watch, NSF, US State Dept, SIDA, Knight Foundation, ...

slide-3
SLIDE 3

3

U.S. 501(c)(3) non-profit

  • rganization dedicated to

the research and development of tools for

  • nline anonymity and

privacy

The Tor Project, Inc.

slide-4
SLIDE 4

4

Estimated ~800,000? daily Tor users

slide-5
SLIDE 5

5

Threat model: what can the attacker do?

Alice Anonymity network Bob watch (or be!) Bob! watch Alice! Control part of the network!

slide-6
SLIDE 6

6

Anonymity isn't encryption: Encryption just protects contents.

Alice Bob “Hi, Bob!” “Hi, Bob!” <gibberish> attacker

slide-7
SLIDE 7

7

Anonymity isn't just wishful thinking...

“You can't prove it was me!” “Promise you won't look!” “Promise you won't remember!” “Promise you won't tell!” “I didn't write my name on it!” “Isn't the Internet already anonymous?”

slide-8
SLIDE 8

8

Anonymity serves different interests for different user groups.

Anonymity

Private citizens “It's privacy!”

slide-9
SLIDE 9

9

Anonymity serves different interests for different user groups.

Anonymity

Private citizens Businesses “It's network security!” “It's privacy!”

slide-10
SLIDE 10

10

Anonymity serves different interests for different user groups.

Anonymity

Private citizens Governments Businesses “It's traffic-analysis resistance!” “It's network security!” “It's privacy!”

slide-11
SLIDE 11

11

Anonymity serves different interests for different user groups.

Anonymity

Private citizens Governments Businesses “It's traffic-analysis resistance!” “It's network security!” “It's privacy!” Human rights activists “It's reachability!”

slide-12
SLIDE 12

12

The simplest designs use a single relay to hide connections.

Bob2 Bob1 Bob3 Alice2 Alice1 Alice3 Relay E(Bob3,“X”) E(Bob1, “Y”) E ( B

  • b

2 , “ Z ” ) “Y” “Z” “X”

(example: some commercial proxy providers)

slide-13
SLIDE 13

13

But a single relay (or eavesdropper!) is a single point of failure.

Bob2 Bob1 Bob3 Alice2 Alice1 Alice3 Evil Relay E(Bob3,“X”) E(Bob1, “Y”) E ( B

  • b

2 , “ Z ” ) “Y” “Z” “X”

slide-14
SLIDE 14

14

... or a single point of bypass.

Bob2 Bob1 Bob3 Alice2 Alice1 Alice3 Irrelevant Relay E(Bob3,“X”) E(Bob1, “Y”) E ( B

  • b

2 , “ Z ” ) “Y” “Z” “X”

Timing analysis bridges all connections through relay ⇒ An attractive fat target

slide-15
SLIDE 15

15

So, add multiple relays so that no single one can betray Alice.

Bob Alice R1 R2 R3 R4 R5

slide-16
SLIDE 16

16

Alice makes a session key with R1 ...And then tunnels to R2...and to R3

Bob Alice R1 R2 R3 R4 R5 Bob2

slide-17
SLIDE 17

17

slide-18
SLIDE 18

18

slide-19
SLIDE 19

19

slide-20
SLIDE 20

20

Tor Controller Interface

  • stem
  • pytorctl
  • jtorctl
  • txtorcon
slide-21
SLIDE 21

21

Tor specs

slide-22
SLIDE 22

22

freehaven.net/anonbib/

slide-23
SLIDE 23

23

Tor network simulators

  • Shadow
  • ExperimenTor
  • Chutney
  • Puppetor
slide-24
SLIDE 24

24

slide-25
SLIDE 25

25

slide-26
SLIDE 26

26

slide-27
SLIDE 27

27

Attackers can block users from connecting to the Tor network

1) By blocking the directory authorities 2) By blocking all the relay IP addresses in the directory, or the addresses of other Tor services 3) By filtering based on Tor's network fingerprint 4) By preventing users from finding the Tor software (usually by blocking website)

slide-28
SLIDE 28

28

Relay versus Discovery

There are two pieces to all these “proxying” schemes: a relay component: building circuits, sending traffic over them, getting the crypto right a discovery component: learning what relays are available

slide-29
SLIDE 29

29 R4 R2 R1 R3 Bob Alice Alice Alice Alice Alice Blocked User Blocked User Blocked User Blocked User Blocked User Alice Alice Alice Alice Alice Alice Alice Alice Alice Alice

slide-30
SLIDE 30

30

slide-31
SLIDE 31

31

slide-32
SLIDE 32

32

slide-33
SLIDE 33

33

slide-34
SLIDE 34

34

slide-35
SLIDE 35

35

slide-36
SLIDE 36

36

slide-37
SLIDE 37

37

slide-38
SLIDE 38

38

slide-39
SLIDE 39

39

slide-40
SLIDE 40

40

slide-41
SLIDE 41

41

slide-42
SLIDE 42

42

slide-43
SLIDE 43

43

What we're up against

Govt firewalls used to be stateless. Now they're buying fancier hardware. Burma vs Iran vs China New filtering techniques spread by commercial (American) companies :(

slide-44
SLIDE 44

44

slide-45
SLIDE 45

45

slide-46
SLIDE 46

46

Modularity

slide-47
SLIDE 47

47

Pluggable transports

  • Flashproxy (Stanford), websocket
  • FTEProxy (Portland St), http via regex
  • Stegotorus (SRI/CMU), http
  • Skypemorph (Waterloo), Skype video
  • uProxy (Google), webrtc
  • Lantern (BNS), social network based
  • ScrambleSuit (Karlstad), obfs-based
  • Telex (Michigan/Waterloo), traffic divert
slide-48
SLIDE 48

48

Tor's safety comes from diversity

  • #1: Diversity of relays. The more relays

we have and the more diverse they are, the fewer attackers are in a position to do traffic confirmation. (Research problem: measuring diversity over time)

  • #2: Diversity of users and reasons to use
  • it. 50000 users in Iran means almost all of

them are normal citizens.

slide-49
SLIDE 49

49

Tor's anonymity comes from...

  • The first 100,000 users (user diversity)
  • The last 1,000,000 users (end-to-end

correlation resistance)

  • The first 1,000 relays (location diversity)
slide-50
SLIDE 50

50

Only a piece of the puzzle

Assume the users aren't attacked by their hardware and software No spyware installed, no cameras watching their screens, etc Users can fetch a genuine copy of Tor?

slide-51
SLIDE 51

51

slide-52
SLIDE 52

52

slide-53
SLIDE 53

53

“Still the King of high secure, low latency Internet Anonymity” Contenders for the throne:

  • None
slide-54
SLIDE 54

54

NSA/GCHQ programs that affect Tor

  • Quick Ant (QFD), Quantum Insert, Foxacid
  • Quantum for cookie tests (good thing we

moved away from Torbutton's “toggle”)

  • Remember, they can do these things even

more easily to non-Tor users

  • At least they can't target specific Tor users

(until they identify themselves)

  • “Don't worry, we never attack Americans” (!)
slide-55
SLIDE 55

55

Perception

  • DoJ's aborted study finding 3% bad

content on the Tor network

  • How do you compare one Snowden leak to

ten true reviews on Yelp?

  • BBC's Silk Road articles telling people

how to buy drugs safely

slide-56
SLIDE 56

56

slide-57
SLIDE 57

57

slide-58
SLIDE 58

58

slide-59
SLIDE 59

59

High-profile hidden services

The media has promoted a few hot topics:

  • WikiLeaks (~2010)
  • Farmer's market (pre-2013)
  • Freedom Hosting (2013)
  • Silk Road (2013)

There are many more (eg: many GlobaLeaks deployments, etc) which aren't well known by the media (yet).

slide-60
SLIDE 60

60

So what should Tor's role in the world be?

  • Can't be solely technical (anymore, if it

ever could have been)

  • But technical is what we're best at (at least,

historically)

  • Remember how important diversity of

users is

slide-61
SLIDE 61

61

Three ways to destroy Tor

  • 1) Legal / policy attacks
  • 2) Make ISPs hate hosting exit relays
  • 3) Make services hate Tor connections

– Yelp, Wikipedia, Google, Skype, …

slide-62
SLIDE 62

62

slide-63
SLIDE 63

63

Botnet

  • Some jerk in the Ukraine signed up 5

million bots as Tor clients (not relays)

  • Our scalability work paid off!
  • Good thing it wasn't malicious.
  • Ultimately it didn't work: everybody

noticed, and Microsoft has been cleaning up the bots

slide-64
SLIDE 64

64

Number of daily Tor users

slide-65
SLIDE 65

65

So what's next?

  • “Tor: endorsed by Egyptian activists,

Wikileaks, NSA, GCHQ, Chelsea Manning, Snowden, ...”

  • Different communities like Tor for

different reasons.

slide-66
SLIDE 66

66

slide-67
SLIDE 67

67

Tor Browser Bundle 3.x

  • Deterministic Builds
  • “Tor launcher” extension, no Vidalia
  • Asks if you want bridges first
  • Local homepage, so much faster startup
  • Security slider (for e.g. JavaScript)
  • Privacy fixes, e.g. font enumeration
slide-68
SLIDE 68

68

slide-69
SLIDE 69

69

Orbot

slide-70
SLIDE 70

70

Tails LiveCD

slide-71
SLIDE 71

71

“Core” Tor tasks

  • Core Tor (specs, design, hidden services)
  • Tor Browser Bundle, deterministic builds
  • Metrics and measurements
  • Bridges and pluggable transports
  • Helping the research community
  • Outreach and education
