The script-writer’s dream: How to write great SQL in your own language and be sure it will succeed.

Ezra Cooper University of Edinburgh August 24, 2009

The Problem

The Problem

The Problem

Problems with SQL:

◮ Embedding is usually a pain ◮ Lacks nested data structures ◮ Lacks abstraction

The Problem

Problems with SQL:

◮ Embedding is usually a pain ◮ Lacks nested data structures ◮ Lacks abstraction

The Solution Language-integrated query

Example: Little League database

teams: name Marchmont United Bruntsfield Hustlers Newington Numpties Leith Sluggers players: name team age Sam Marchmont United 17 Ezra Bruntsfield Hustlers 15 Angus Newington Numpties 18 Jeremy Newington Numpties 15 Paidi Leith Sluggers 15 Bob Newington Numpties 14 Lucy Leith Sluggers 17 Hugh Bruntsfield Hustlers 13

Meet the comprehension

for (x ← src) body

Meet the comprehension

for (x ← src) body

Bind x to successive values from src evaluating body for each one; the result is the union of all the collections so produced.

Meet the comprehension

for (x ← src) body

Bind x to successive values from src evaluating body for each one; the result is the union of all the collections so produced. Some syntactic sugar:

for (x ← src) where(cond) body = for (x ← src) (if (cond) then body else [])

Example: A simple query

var players = table “players” : [(age : int, name : string)]; fun overAgePlayers() { query { for (p ← players) where (p.age > 16) [(name = p.name)] } }

Example: A simple query

var players = table “players” : [(age : int, name : string)]; fun overAgePlayers() { query { for (p ← players) where (p.age > 16) [(name = p.name)] } } SQL: select p.name as name from players as p where p.age > 16

Example: Detecting non-queryizable operations

fun overAgePlayersReversed() { query { for (p ← players) where (p.age > 16) [(name = reverse(p.name))] # ERROR! } }

Example: Abstracting the query

fun selectedPlayers(pred) { query { for (p ← players) where (pred(p)) [(name = p.name)] } }

Example: Abstracting the query

fun selectedPlayers(pred) { query { for (p ← players) where (pred(p)) [(name = p.name)] } } SQL ?? select p.name as name from players as p where [ · · · ]

Example: Nested query

fun unusablePlayers() { query { var teamRosters : [(roster : [Player])]= for (t ← teams) [(roster = for (p ← players) where (p.team == t.name) [p])]; for (tr ← teamRosters) where (length(tr.roster) < 9) tr.roster } }

Example: Nested query, unnested as SQL

SQL: select p.* from players as p, teams as t where p.team = t.name and ((select count(*) from players as p2 where p2.team = t.name) < 9)

Example: Nested query, refactored

fun teamRosters() { for (t ← teams) [(name = t.name roster = for (p ← players) where (p.team == t.team)) [p]]; } fun unusablePlayers() { query { for (tr ← teamRosters() ) where (length(tr.roster) < 9) tr.roster } }

Example: Nested query, abstracted

fun unusablePlayers(pred) { query { for (t ← teamRosters() ) where (pred(t.roster)) t.roster } }

Example: Nested query, abstracted

fun unusablePlayers(pred) { query { for (t ← teamRosters() ) where (pred(t.roster)) t.roster } } Very hard in SQL

Example: Nested query, abstracted, attempted in SQL

select p.* from players as p, teams as t where p.team = t.name and ((select count(*) from players as p2 where p2.team = t.name) < 9)

The goal

Write queries in an ordinary programming language.

The goal

Write queries in an ordinary programming language.

◮ Allow nested data structures.

The goal

Write queries in an ordinary programming language.

◮ Allow nested data structures. ◮ Allow abstraction.

The goal

Write queries in an ordinary programming language.

◮ Allow nested data structures. ◮ Allow abstraction. ◮ Statically detect unqueryizable expressions.

The goal

Write queries in an ordinary programming language.

◮ Allow nested data structures. ◮ Allow abstraction. ◮ Statically detect unqueryizable expressions.

“Language-integrated query”

Previous work, language-integrated query

◮ Libkin and Wong (early 90s):

Theory; proof for first-order unnesting, pure setting, total.

◮ Kleisli, LINQ, Links (originally):

Implemented, impure setting, partial.

◮ Ferry (Grust, et al., 2009):

Implemented, pure setting, total, handles nested final results.

◮ Fegaras (1998):

Theory, higher-order, but no proof of termination.

◮ Van den Bussche (2001):

Theory, nested final results.

Example: Nested query with untranslatable fragment

fun teamRosters() { query{ for (t ← teams) [(name = reverse(t.name) # ERROR! roster = for (p ← players) where (p.team == t.team)) [p]]; } }

Example: Nested query with untranslatable fragment

fun teamRosters() { query{ for (t ← teams) [(name = reverse(t.name) # ERROR! roster = for (p ← players) where (p.team == t.team)) [p]]; } } Original version of Links, like Kleisli, translates this to an iteration

• ver a query—one players query for each row of teams.

What I want to show you

What I want to show you

How to translate any “pure” expression

• f relational type

to an equivalent single SQL query.

What I want to show you

How to translate any “pure” expression

• f relational type

to an equivalent single SQL query. and How to statically detect whether a designated expression is queryizable.

The contribution

Add to language-integrated query

◮ Handling higher-order functions. ◮ Separating query-translatable from non-translatable

sublanguages of a general-purpose language.

◮ Providing a complete translation from the translatable

sublanguage.

The Solution

Plan

Compile time Run time Type-and-effect check Normalize Translate

The source language

(types) T ::=

• | (−

− → l : T) | [T]| S

e

→ T (base types)

• ::=

bool | int | string | · · · (terms) B, L, M, N ::= for (x ← L) M | if B then M else N | table s : T | [M]| []| M ⊎ N | (− − − → l = M) | M.l | LM | λx.N | x | c | length(M) | empty(M) | prim(− → M) | query{M} (atomic effects) E ::= noQ (effect sets) e a set of effects E

Type-and-effect checking

Typing judgment

Γ ⊢ M : T ! e Γ variable typing environment M expression T type of M e effects (a set) “In environment Γ, evaluating expression M has effects contained in e and results in type T.”

Typing rules

Γ ⊢ M : T ! ∅ T has the form [(− − → l : o)] Γ ⊢ query{M} : T ! ∅ (T-Query)

Typing rules

prim : S1 × · · · × Sn

e

→ T Γ ⊢ Mi : Si ! ei for each 1 ≤ i ≤ n Γ ⊢ prim(− → M) : T ! e ∪

i ei

(T-Prim)

Typing rules

prim : S1 × · · · × Sn

e

→ T Γ ⊢ Mi : Si ! ei for each 1 ≤ i ≤ n Γ ⊢ prim(− → M) : T ! e ∪

i ei

(T-Prim) Side condition: Every primitive must have an SQL equivalent or an effect tag.

Typing rules

T has the form [(− − → l : o)] Γ ⊢ (table s : T) : T ! ∅ (T-Table)

Typing rules

Γ ⊢ M : [S]! e Γ, x : S ⊢ N : [T]! e′ Γ ⊢ for (x ← M) N : [T]! e ∪ e′ (T-For)

Typing rules

Γ ⊢ c : Tc ! ∅ (T-Const) Γ, x : T ⊢ x : T ! ∅ (T-Var) Γ, x : S ⊢ N : T ! e′ Γ ⊢ λx.N : S e′ → T ! ∅ (T-Abs) Γ ⊢ L : S

e

→ T ! e′ Γ ⊢ M : S ! e′′ Γ ⊢ LM : T ! e ∪ e′ ∪ e′′ (T-App)

Typing rules

Γ ⊢ M : [T] Γ ⊢ empty(M) : bool (T-Empty) Γ ⊢ M : [T] Γ ⊢ length(M) : int (T-Length)

Typing rules

Γ ⊢ []: [T]! ∅ (T-Null) Γ ⊢ M : T ! e Γ ⊢ [M]: [T]! e (T-Singleton) Γ ⊢ M : [T]! e Γ ⊢ N : [T]! e′ Γ ⊢ M ⊎ N : [T]! e ∪ e′ (T-Union)

Typing rules

Γ ⊢ Mi : Ti ! ei for each Mi, Ti in − − − → M, T Γ ⊢ (− − − → l = M) : (− − → l : T) !

i ei

(T-Record) Γ ⊢ M : (− − → l : T) ! e (l : T) ∈ (− − → l : T) Γ ⊢ M.l : T ! e (T-Project) Γ ⊢ L : bool ! e Γ ⊢ M : T ! e′ Γ ⊢ N : T ! e′′ Γ ⊢ if L then M1 else M2 : T ! e ∪ e′ ∪ e′′ (T-If) Γ ⊢ M : S

e

→ T e ⊂ e′ Γ ⊢ M : S e′ → T (T-Subsump)

What the typing gives us

Any well-typed expression query{M}: has relation type and never executes any primitive that lacks an SQL equivalent.

What the typing gives us

Any well-typed expression query{M}: has relation type and never executes any primitive that lacks an SQL equivalent. So, at runtime M can be translated to an SQL query.

Run Time

Translation

Normal forms

(normal forms) V , U ::= V ⊎ U | []| F (comprehension NFs) F ::= for (x ← table s : T) F | Z (comprehension bodies) Z ::= if B then Z else []| [(− − − → l = B)]| table s : T (basic expressions) B ::= if B then B′ else B′′ | empty(V ) | length(V ) | prim(− → B ) | x.l | c

Target SQL fragment

Q, R ::= Q union all R | S S ::= select − − − → e as l from − − − → t as x where e e ::= case when e then e′ else e′′ end | c | x.l | e ∧ e′ | ¬e | prim(− → e ) | exists(Q) | count(∗)

SQL translation of normal forms

V ⊎ U = V union all U for (x ← table s : T) F = select − − − → e as l from s as x, − − − → t as y where B where (select − − − → e as l from − − − → t as y where B) = F if B then Z else [] = select − − − → e as l from t where B′ ∧ B where (select − − − → e as l from t where B′) = Z table s : [( − − → l : o)]

• =

select − − − − → s.l as l from s where true [( − − − → l = B)]

• =

select − − − − − → B as l from ∅ where true if B then B′ else B′′ = case when B then B′ else B′′ end empty(V ) = ¬exists(V ) length(V ) = select count(∗) from t where B where (select − − − → e as l from t where B) = V prim( − → B ) = prim( − → B) x.l = x.l c = c

Example

• for (x ← table s)

for (y ← table t) if (x.c > 0) then [(a = x.a, b = y.b)] else []

• =

select x.a as a, y.b as b from s as x, t as y where x.c > 0

Normalization

Rewriting source expressions

Partial evaluation, with some twists.

(λx.N)M : T

• N[M/x]

(abs-β) ( − − − → l = M).l : T

• Ml

(record-β) for (x ← [M]) N : T

• N[M/x]

(for-β)

Rewriting

Simplifying list expressions.

if B then []else []: T

• []

(if-zero) for (x ← []) M : T

• []

(for-zero-src) for (x ← N) []: T

• []

(for-zero-body) for (x ← M1 ⊎ M2) N : T

• (for-union-src)

(for (x ← M1) N) ⊎ (for (x ← M2) N) for (x ← M) (N1 ⊎ N2) : T

• (for-union-body)

(for (x ← M) N1) ⊎ (for (x ← M) N2) if B then M ⊎ N else []: T

• (if-union)

if B then M else []⊎ if B then N else []

Rewriting

Rearranging comprehensions, unions, and conditionals.

if B then (for (x ← M) N) else []: T

• (if-for)

for (x ← M) (if B then N else []) for (x ← if B then M else []) N : T

• (for-if-src)

if B then (for (x ← M) N) else [] for (x ← for (y ← L) M) N : T

• (for-assoc)

for (y ← L) (for (x ← M) N) if y ∈ fv(N)

Rewriting

Eliminating non-base-type conditionals

(if B then L else L′)M : T

• if B then LM else L′M

(app-if) if B then M else N : (− − → l : T)

• (−

− − → l = L) (if-record) where Ll = if B then M.l else N.l if B then M else N : [T] (if-split) (if B then M else []) ⊎ (if ¬B then N else []) if N = []

Rewriting

Special forms.

empty(M) : bool

• empty(for (x ← M) [()])

if M : S and S not a flat relation type (empty-flatten) length(M) : bool

• length(for (x ← M) [()])

if M : S and S not a flat relation type (length-flatten) query{M} : T

• M

(ignore-query)

Normal forms

◮ These rules are strongly normalizing.

Normal forms

◮ These rules are strongly normalizing. ◮ If query{M} typechecks, and substitution σ closes M, then

the normal form of Mσ lies in the SQL-like sublanguage.

Adding Recursion

Add a fixpoint operator letrec which produces a recursive function annotated with an effect rec: Γ, f : S

{rec}∪e

− → T, x : S ⊢ M : T ! e Γ, f : S

{rec}∪e

− → T ⊢ N : U ! e′ Γ ⊢ letrec f x = M in N : U ! e′ (T-LetRec) If a recursive function is applied anywhere within a query expression, type-checking will fail.

The whole process

,

The message

SQL queries can be written with a natural query construct and integrated with a general-purpose programming language, allowing more flexibility and robustness.

The message

SQL queries can be written with a natural query construct and integrated with a general-purpose programming language, allowing more flexibility and robustness.

The end
