The Economic Club of Florida Tallahassee August 13, 2018 Nancy P Mendenhall, MD The Promise of Protons The Economic Club of Florida, Tallahassee 2018 0813 The Promise of Protons Cancer and radiation therapy The promise of protons

slide-1
SLIDE 1

The Promise of Protons

The Economic Club of Florida Tallahassee August 13, 2018 Nancy P Mendenhall, MD

slide-2
SLIDE 2

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

  • Cancer and radiation therapy
  • The promise of protons
  • UFHPTI: missions and operation
  • The economic impact
  • The future…….
slide-3
SLIDE 3

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

Cancer and Radiation

slide-4
SLIDE 4

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Cancer & Radiation

  • Cancer affects 1 in every 3 Americans
  • Cancer is 2nd most common cause of

death in the US

slide-5
SLIDE 5

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Cancer & Radiation

Standard Cancer Therapy

Local

Surgery Radiation

Systemic

Chemotherapy

Hormonal & Targeted therapy

Immunotherapy

  • Cryosurgery, laser, & HIFU are local therapies used in certain settings.
  • Radiation may be delivered with an external source (external beam

therapy), an implanted or intracavitary source (brachytherapy), or an isotope (systemic)

slide-6
SLIDE 6

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Cancer & Radiation

  • Radiation used in ~50% of cancer patients
  • Most is External Beam Radiation Therapy

using a radiation source external to patient’s body

  • Most EBRT uses X rays (Photons) aka

“conventional radiation therapy”

Including cancers of the prostate, breast, lung, colorectum, brain, head & neck, female organs, male organs, urinary tract, lymphatic system, and children

slide-7
SLIDE 7

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

The Promise of Protons

slide-8
SLIDE 8

First Principles of Radiation Therapy

Radiation Therapy is a non- specific treatment

  • Damages normal tissue

as well as cancer

  • Damage is dose-related

and volume-related

  • Dose distribution is key

determinant of the patient’s outcome

slide-9
SLIDE 9

0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 5 10 15 20 25 30

Percent Depth Dose Water-Equivalent Depth (g/cm2)

Depth dose comparison of 18 MV X-rays & Protons

Dose Distribution: Depth dose for X rays & Protons

18 MV Photon (X ray) 18 MV Photon (X ray) Proton

slide-10
SLIDE 10

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Photons (X rays)

  • X rays leave a track of damage like a bullet
  • The dose decreases with depth of penetration
  • There is a higher dose (red) along the entrance

path than in the target, and more dose along the exit path

  • Protons are particles with mass; they only penetrate

the body according to the energy they are given

  • They can be programmed to stop in the target (tumor)
  • The entrance dose is much less and there is no exit

dose

slide-11
SLIDE 11

WHAT IS THE IMPACT OF RADIATION DOSE TO NORMAL TISSUE?

Modeling Radiation Dosimetry to Predict Cognitive Outcomes in Pediatric Patients with CNS Embryonal Tumors Including Medulloblastoma

Merchant et al, IJROBP - 2006

  • Each Gy increased IQ decline
  • THERE WAS NO DOSE THRESHOLD
  • Merchant. Cancer J 15:298-305.

Merchant et al. J Neurosurg 104: 94-102. Merchant et al. Pediatr Blood Cancer 51: 110-117. Merchant et al. J Clin Oncol 27: 3691-3697.

slide-12
SLIDE 12

Craniopharyngioma: IMRT vs SRT vs PT

Craniopharyngioma-Comparative Dose Distribution IMRT:photons SBRT: photons Protons

CLINICAL DATA: ~850 pediatric brain tumors treated, including >100 craniopharyngiomas, pc Dr. Daniel Indelicato.. Collaboration with St. Jude Research Hospital, NHS, PPCR

Mean Dose cGyE IMRT STR PT % dec with PT body 233 215 63 71% brain 888 810 358 65% LTL 951 1200 370 61% LH 2749 3299 815 61% Target Dose of 54 GyE

slide-13
SLIDE 13

36 Gy/CGE Mean Dose Cardiac IMRT Proton Mean Dose 20 1 Dosimetry: courtesy of Z Li PhD, D Louis CMD. RATIONALE: Increased risk of 2nd malignancy with dose ≥ 4 Gy (Travis et al, 2002, 2003, Tukenova, 2010) Increased risk of cardiac disease with doses ≥1Gy (Mulrooney 2009, Darby 2013).

Craniospinal Axis Irradiation: 3DCRT vs PT Medulloblastoma: Photons & Protons

CLINICAL DATA: Giantsoudi et al, IJROBP 95: 2016: 111 children, 5 y, similar disease control and acute toxicity to historical controls. …anticipating less late effects.

slide-14
SLIDE 14

Impact of Radiation on Ischemic Heart Disease in Breast Cancer Patients

DESPITE A SURVIVAL ADVANTAGE WITH with RADIATION in breast cancer…. The rate of major cardiac events increased by 7.4% for each increase of 1 Gy in the mean RT dose to the heart

Darby S et al. Risk of Ischemic Heart Disease in Women after Radiotherapy for Breast Cancer. New England Journal of Medicine 2013; 368(11):987-98

slide-15
SLIDE 15

Breast Cancer: IMRT and PT

Xu et al Can proton therapy improve the therapeutic ratio in breast cancer patients at risk for nodal disease? Am J Clin Oncol 2013. Bradley et al. Early Clinical Results. 2017.

IMRT 3DPT

Mean heart dose

5 Gy 1Gy

slide-16
SLIDE 16

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

UFHPTI:

The University of Florida Proton Therapy Institute

Mission and Operation

slide-17
SLIDE 17

University of Florida Proton Therapy Institute Mission

With the compelling rationale for protons, UF decided to create a proton facility Missions

  • Provide best patient care possible
  • Conduct research into best indications and

techniques for proton therapy

  • Fiscal stewardship*
  • Education

*Funded by state grants, city loans, bonds, philanthropy

slide-18
SLIDE 18

University of Florida Proton Therapy Institute: Operations

  • 1st proton facility in Southeast US, opened in 2006
  • 501c3, Affiliated with University of Florida
  • Mission of Patient Care and Proton Therapy

Research

  • >255K treatments to >7500 patients, >1500 children
  • ~40 Prospective Clinical Trials and Studies
  • ~98% of patients involved in outcome studies
  • 150 staff including 11 subspecialty MDs, 11 PhD

Physicists, and 12 engineers

slide-19
SLIDE 19

Gainesville: University of Florida and College of Medicine (COM) Jacksonville: second UF COM campus and site of the UF Proton Therapy Institute Population ~ 1.3 m International air and sea ports Excellent interstate highways

slide-20
SLIDE 20

UFHPTI Treatment Floor

Simulation

Proton Area Photon Area

PET-CT Large Bore CT MR

Eye Treatment Room

230 MeV Cyclotron

slide-21
SLIDE 21

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Facility 440,000 lbs Cyclotron

slide-22
SLIDE 22

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Facility

slide-23
SLIDE 23

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Facility 3 Story - 200,000 lbs Gantry

slide-24
SLIDE 24

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Facility

Proton Treatment Room and Nozzle

slide-25
SLIDE 25

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Clinical Operation

Clinical Mission

Daily >90 patients 14-16 operating hours

  • Prostate
  • Breast
  • Pediatrics
  • Lung
  • Lymphoma
  • Pancreas
  • Head & Neck
  • Sarcoma
  • Bone
  • Eye
slide-26
SLIDE 26
slide-27
SLIDE 27

Current Expansion Project Current Expansion Project

slide-28
SLIDE 28

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Expansion

Expansion Fun Facts:

  • ~11,000 Sq. Ft. project
  • 172 tons (344K pounds) of steel rebar
  • 210 trucks of high density concrete
  • 8.8 million pounds of concrete
slide-29
SLIDE 29

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Research Operation UFHPTI Research Mission

  • 98% patient participation in in-house IRB

approved Outcomes Tracking Protocol

  • ~40% also in bench mark, optimization,

comparative IRB approved studies

  • ~40 clinical research trials/studies conducted
  • Currently 18 open
  • >130 publications to date in peer reviewed

medical journals dealing with technical issues and clinical outcomes treatment

slide-30
SLIDE 30

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Research Operation UFHPTI Research Mission

  • Collaborations with
  • St. Jude
  • Pediatric Proton Cooperative Registry
  • Proton Cooperative Group
  • Mayo Clinic
  • University of Pennsylvania
  • PROSTQA Prostate Study Group
  • Radiation Therapy Oncology Group/NRG
  • Aarhus University Netherlands
  • University of Groningen
  • COMPPARE consortium
  • First UFHPTI/UF federal funded research

grant 2018

slide-31
SLIDE 31

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

UFHPTI:

The Economic Impact of UFHPTI

slide-32
SLIDE 32

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Economic Impact

  • Covered by Medicare and most

major insurers

  • The actual proton treatment

takes 1-10 minutes

  • Each treatment visit takes 15-60

minutes

  • Patients receive proton therapy

daily for 6-8 weeks after a 1-2 week planning interval

  • ~900 patients are evaluated for

protons each year

  • ~3000 physical followup visits

annually

slide-33
SLIDE 33

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Economic Impact

  • Initial capital investment = $125 million*
  • Current expansion / equipment upgrade

project = $44 million

  • Total employees = 193 FTEs [152 (UFHPTI) +

26(UF) +15(IBA)]

  • Total annual operating budget = ~$46.1

million

*State grants, city loans, bonds, philanthropy

slide-34
SLIDE 34

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Economic Impact

  • ~60% of patients

travel >60 miles

  • All US states &

32 countries including:

  • U.K.
  • Canada
  • Australia
  • Norway
  • Peru
  • Saudi Arabia
  • Hong Kong
  • Mainland China
slide-35
SLIDE 35

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Economic Impact

  • Patients typically in JAX for 2-3 months
  • >100 short-term housing options are

currently offered on our web site

  • Estimated average ~$5,500/person spent

by non-local patients for food, housing, transportation and entertainment

  • Estimated non-medical expenditures

>$25 million since 2006

slide-36
SLIDE 36

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Research Economics

  • Research Mission is critically important

to patients, institution, society

  • Answers questions of best indications

and techniques for proton therapy

  • UFHPTI is not only a clinical, but also a

research leader in proton therapy

  • UFHPTI Research to date has been

funded by operating revenue, philanthropy, state and regional grants ($2m per year)……

slide-37
SLIDE 37

PCa: IMRT and PT Dose Distribution

Obvious difference in radiation dose distribution between IMRT and Protons in Prostate Cancer: Does it make a difference?

slide-38
SLIDE 38

Observations from UFHPTI published prostate cancer trials/studies & published IMRT results on disease control (PSA)

Mind the Gap!!!

slide-39
SLIDE 39

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: Research Economics

  • Results from UFHPT prostate cancer

trials provided the basis for a federally funded national clinical trial, COMPPARE, which will compare

  • utcomes of 3000 men treated for

prostate cancer with IMRT vs Protons

  • 44 institutions, UF leadership, funding

by PCORI ($11.9m over 5 years)

slide-40
SLIDE 40

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons

The Future…..

slide-41
SLIDE 41

The Economic Club of Florida, Tallahassee 2018 0813

The Promise of Protons: The Future

  • With the compelling rationale and first

decade of clinical, research, and

  • perational results, we believe the

future is bright

  • More clinical expansion, enhanced

technology, more research to probe the limits of the Promise of Protons ….

slide-42
SLIDE 42

University of Florida Health Proton Therapy Institute

www.floridaproton.org
