10Hz Spectral Lines Joschua Dilly 10Hz Spectral Lines 2 Introduction Ions 50cm Protons 30cm Protons 60/15cm flatoptics Protons at Injection Conclusion Summary 10Hz Spectral Lines 3 Introduction In the context of the luminosity problems

slide-1
SLIDE 1
slide-2
SLIDE 2

10Hz Spectral Lines

Joschua Dilly

10Hz Spectral Lines 2

slide-3
SLIDE 3

Introduction Ions 50cm Protons 30cm Protons 60/15cm flatoptics Protons at Injection Conclusion Summary

10Hz Spectral Lines 3

slide-4
SLIDE 4

Introduction

In the context of the luminosity problems in IP2 during the ion runs at the end of 2018, a 10Hz modulation on the beam has been detected to cause additional problems (i.e. beam dumps). This modulation seems to originate in the IP2 triplets. In this study the spectra of some measurements was investigated to see this modulation and extract statistics about it. Furthermore, it was checked if this modulation occurs during proton runs as well.

10Hz Spectral Lines 4

slide-5
SLIDE 5

Hints

The amplitude A of the modulation is calculated as: A = Af AQ · pk2pk, where

  • Af is the amplitude of the frequency line
  • AQ is the amplitude of the tune line
  • pk2pk is the peak-to-peak value (in mm) of the focusing

quadrupoles in the arcs

10Hz Spectral Lines 5

slide-6
SLIDE 6

Hints

  • I added some markers for the 10Hz and the 12Hz onto the pictures.

These are only a visual aid and not in any way accurate.

10Hz Spectral Lines 6

slide-7
SLIDE 7

Ions 50cm

  • Date: 2018-11-03 01:38
  • FILL#: 7396
  • BeamProcess:

SQUEEZE-6.37TeV-ATS-1m-50cm-2018 ION V1@270 [END]

10Hz Spectral Lines 7

slide-8
SLIDE 8

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 11 03@01 38 04 244.sdds X 0.85 · 10−3 ± 1.5 · 10−4 8.32 · 10−3 ± 2.85 · 10−3 9.00 · 10−4 ± 3.92 · 10−5 Beam1@Turn@2018 11 03@01 38 04 244.sdds X 1.15 · 10−3 ± 1.5 · 10−4 1.66 · 10−2 ± 7.44 · 10−3 1.04 · 10−3 ± 3.64 · 10−5

10Hz Spectral Lines 8

slide-9
SLIDE 9

Figure: Beam 1 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 11 03@01 38 04 244.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 4.15 · 10−3 ± 1.60 · 10−3 9.18 · 10−4 ± 1.33 · 10−5 Beam1@Turn@2018 11 03@01 38 04 244.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.31 · 10−3 ± 7.49 · 10−4 1.13 · 10−3 ± 6.72 · 10−5

10Hz Spectral Lines 9

slide-10
SLIDE 10

Figure: Beam 2 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 11 03@01 35 06 976.sdds X 0.85 · 10−3 ± 1.5 · 10−4 7.10 · 10−3 ± 3.42 · 10−3 8.48 · 10−4 ± 3.52 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds X 1.15 · 10−3 ± 1.5 · 10−4 2.18 · 10−2 ± 9.78 · 10−3 1.03 · 10−3 ± 1.56 · 10−5

10Hz Spectral Lines 10

slide-11
SLIDE 11

Figure: Beam 2 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 11 03@01 35 06 976.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.84 · 10−3 ± 1.12 · 10−3 7.94 · 10−4 ± 0.11 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.73 · 10−3 ± 8.67 · 10−4 1.21 · 10−3 ± 7.84 · 10−5

10Hz Spectral Lines 11

slide-12
SLIDE 12

Protons 30cm

  • Date: 2018-06-16 15:37
  • FILL#: 6811
  • BeamProcess:

RAMP PELP-SQUEEZE-6.5TeV-ATS-1m- 2018 V3 V1 MD1@1210 [END]

10Hz Spectral Lines 12

slide-13
SLIDE 13

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 06 16@15 37 05 144.sdds X 1.00 · 10−3 ± 1.5 · 10−4 5.90 · 10−3 ± 2.61 · 10−3 1.01 · 10−3 ± 2.52 · 10−5

10Hz Spectral Lines 13

slide-14
SLIDE 14

Figure: Beam 1 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 06 16@15 37 05 144.sdds Y 1.00 · 10−3 ± 1.5 · 10−4 1.76 · 10−3 ± 5.08 · 10−4 9.79 · 10−4 ± 6.73 · 10−5

10Hz Spectral Lines 14

slide-15
SLIDE 15

Figure: Beam 2 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 06 16@15 38 07 781.sdds X 0.85 · 10−3 ± 1.5 · 10−4 2.70 · 10−3 ± 2.99 · 10−3 8.68 · 10−4 ± 7.31 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds X 1.15 · 10−3 ± 1.5 · 10−4 7.29 · 10−3 ± 3.66 · 10−3 1.04 · 10−3 ± 2.21 · 10−5

10Hz Spectral Lines 15

slide-16
SLIDE 16

Figure: Beam 2 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 06 16@15 38 07 781.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.38 · 10−3 ± 4.49 · 10−4 7.62 · 10−4 ± 2.62 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 1.95 · 10−3 ± 1.14 · 10−3 1.10 · 10−3 ± 2.82 · 10−5

10Hz Spectral Lines 16

slide-17
SLIDE 17

Protons 60/15cm flatoptics

  • Date: 2018-10-30 13:04
  • FILL#: 7391
  • BeamProcess:

SQUEEZE-6.5TeV-ATS-65cm-60 15cm- 2017 V1 ATSFlat@526 [END]

10Hz Spectral Lines 17

slide-18
SLIDE 18

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 10 30@13 04 27 548.sdds X 0.85 · 10−3 ± 1.5 · 10−4 1.18 · 10−2 ± 4.49 · 10−3 9.00 · 10−4 ± 3.38 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds X 1.15 · 10−3 ± 1.5 · 10−4 6.91 · 10−3 ± 2.84 · 10−3 1.05 · 10−3 ± 3.72 · 10−5

10Hz Spectral Lines 18

slide-19
SLIDE 19

Figure: Beam 1 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 10 30@13 04 27 548.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.21 · 10−3 ± 1.97 · 10−3 8.00 · 10−4 ± 6.95 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.03 · 10−3 ± 1.22 · 10−3 1.20 · 10−3 ± 4.45 · 10−5

10Hz Spectral Lines 19

slide-20
SLIDE 20

Figure: Beam 2 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 10 30@13 04 06 462.sdds X 1.00 · 10−3 ± 1.5 · 10−4 1.28 · 10−2 ± 4.22 · 10−3 1.00 · 10−3 ± 1.85 · 10−5

10Hz Spectral Lines 20

slide-21
SLIDE 21

Figure: Beam 2 Frequency Spectrum of vertical BPMs.

∼10Hz ∼12Hz File Plane Window Amplitude [mm] Frequency Beam2@Turn@2018 10 30@13 04 06 462.sdds Y 1.00 · 10−3 ± 1.5 · 10−4 2.45 · 10−3 ± 6.52 · 10−4 1.00 · 10−3 ± 5.92 · 10−5

10Hz Spectral Lines 21

slide-22
SLIDE 22

Protons at Injection

  • Date: 2018-04-03 23:06
  • FILL#: 6504

Here the conclusion is not conclusive, as different measurements show very different spectra in this region. Hence shown are 4 measurements of Beam 1 horizontal for comparison.

10Hz Spectral Lines 22

slide-23
SLIDE 23

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz

10Hz Spectral Lines 23

slide-24
SLIDE 24

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz

10Hz Spectral Lines 24

slide-25
SLIDE 25

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz

10Hz Spectral Lines 25

slide-26
SLIDE 26

Figure: Beam 1 Frequency Spectrum of horizontal BPMs.

∼10Hz ∼12Hz

10Hz Spectral Lines 26

slide-27
SLIDE 27

Conclusion

10Hz Spectral Lines 27

slide-28
SLIDE 28

Conclusion

  • Lines around 10Hz are visible in the horizontal spectrum
  • No lines can be found in the vertical spectrum
  • often two lines at around 10Hz and 12Hz
  • the 12Hz line is bigger
  • sometimes only one line around 11Hz
  • these lines are visible for Ions and Protons
  • they are more distinct for Ion optics, especially in Beam 2

10Hz Spectral Lines 28

slide-29
SLIDE 29

Summary

10Hz Spectral Lines 29

slide-30
SLIDE 30

Summary Table

File Plane Window Amplitude [mm] Frequency Beam1@Turn@2018 11 03@01 38 04 244.sdds X 0.85 · 10−3 ± 1.5 · 10−4 8.32 · 10−3 ± 2.85 · 10−3 9.00 · 10−4 ± 3.92 · 10−5 Beam1@Turn@2018 11 03@01 38 04 244.sdds X 1.15 · 10−3 ± 1.5 · 10−4 1.66 · 10−2 ± 7.44 · 10−3 1.04 · 10−3 ± 3.64 · 10−5 Beam1@Turn@2018 11 03@01 38 04 244.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 4.15 · 10−3 ± 1.60 · 10−3 9.18 · 10−4 ± 1.33 · 10−5 Beam1@Turn@2018 11 03@01 38 04 244.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.31 · 10−3 ± 7.49 · 10−4 1.13 · 10−3 ± 6.72 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds X 0.85 · 10−3 ± 1.5 · 10−4 7.10 · 10−3 ± 3.42 · 10−3 8.48 · 10−4 ± 3.52 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds X 1.15 · 10−3 ± 1.5 · 10−4 2.18 · 10−2 ± 9.78 · 10−3 1.03 · 10−3 ± 1.56 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.84 · 10−3 ± 1.12 · 10−3 7.94 · 10−4 ± 0.11 · 10−5 Beam2@Turn@2018 11 03@01 35 06 976.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.73 · 10−3 ± 8.67 · 10−4 1.21 · 10−3 ± 7.84 · 10−5 Beam1@Turn@2018 06 16@15 37 05 144.sdds X 1.00 · 10−3 ± 1.5 · 10−4 5.90 · 10−3 ± 2.61 · 10−3 1.01 · 10−3 ± 2.52 · 10−5 Beam1@Turn@2018 06 16@15 37 05 144.sdds Y 1.00 · 10−3 ± 1.5 · 10−4 1.76 · 10−3 ± 5.08 · 10−4 9.79 · 10−4 ± 6.73 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds X 0.85 · 10−3 ± 1.5 · 10−4 2.70 · 10−3 ± 2.99 · 10−3 8.68 · 10−4 ± 7.31 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds X 1.15 · 10−3 ± 1.5 · 10−4 7.29 · 10−3 ± 3.66 · 10−3 1.04 · 10−3 ± 2.21 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.38 · 10−3 ± 4.49 · 10−4 7.62 · 10−4 ± 2.62 · 10−5 Beam2@Turn@2018 06 16@15 38 07 781.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 1.95 · 10−3 ± 1.14 · 10−3 1.10 · 10−3 ± 2.82 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds X 0.85 · 10−3 ± 1.5 · 10−4 1.18 · 10−2 ± 4.49 · 10−3 9.00 · 10−4 ± 3.38 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds X 1.15 · 10−3 ± 1.5 · 10−4 6.91 · 10−3 ± 2.84 · 10−3 1.05 · 10−3 ± 3.72 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds Y 0.85 · 10−3 ± 1.5 · 10−4 2.21 · 10−3 ± 1.97 · 10−3 8.00 · 10−4 ± 6.95 · 10−5 Beam1@Turn@2018 10 30@13 04 27 548.sdds Y 1.15 · 10−3 ± 1.5 · 10−4 2.03 · 10−3 ± 1.22 · 10−3 1.20 · 10−3 ± 4.45 · 10−5 Beam2@Turn@2018 10 30@13 04 06 462.sdds X 1.00 · 10−3 ± 1.5 · 10−4 1.28 · 10−2 ± 4.22 · 10−3 1.00 · 10−3 ± 1.85 · 10−5 Beam2@Turn@2018 10 30@13 04 06 462.sdds Y 1.00 · 10−3 ± 1.5 · 10−4 2.45 · 10−3 ± 6.52 · 10−4 1.00 · 10−3 ± 5.92 · 10−5

10Hz Spectral Lines 30
