The new FBCT in the SPS Luciana Kolbeck EDMS 2234336 2 10/07/2019 Content New location New FBCT Measurement calibrations Other news EDMS 2234336 3 10/07/2019 New FBCT location Why?: Too much radiation from the new

slide-1
SLIDE 1
slide-2
SLIDE 2

The new FBCT in the SPS

EDMS 2234336

Luciana Kolbeck

10/07/2019 2

slide-3
SLIDE 3

Content

  • New location
  • New FBCT
  • Measurement calibrations
  • Other news

EDMS 2234336 10/07/2019 3

slide-4
SLIDE 4

New FBCT location

  • Why?: Too much radiation from the new dump
  • New location: BA3 319
  • The old FBCT will stay in BA3 314
  • New device names:
  • Old FBCT: SPS.BCTFR.31450
  • New FBCT: SPS.BCTW.31931
  • Aperture issue: due to misalignment, the FBCT is large

enough (76mm diameter)

EDMS 2234336 10/07/2019 4

slide-5
SLIDE 5

The new FBCT

EDMS 2234336 10/07/2019 5

slide-6
SLIDE 6

The new FBCT

  • Wall-current-transformer (as in the LHC)
  • Less dependence on beam position and

bunch length

  • Digital acquisition

EDMS 2234336 10/07/2019 6

slide-7
SLIDE 7

The new FBCT

  • The wall-current

flows through the 8 screws

  • Transformers

(red) around the screws measure the current

EDMS 2234336

Graphic by M. Krupa

10/07/2019 7

slide-8
SLIDE 8

The new FBCT

EDMS 2234336

Graphic by M. Krupa

10/07/2019 8

slide-9
SLIDE 9

The new FBCT

EDMS 2234336

Picture by M. Krupa

10/07/2019 9

slide-10
SLIDE 10

The new FBCT

  • Digital acquisition (also for transfer-line

FBCTs and old FBCT):

  • Self-phasing
  • Parallel acquired gain ranges, automatic switch
  • Baseline correction

EDMS 2234336 10/07/2019 10

slide-11
SLIDE 11

New measurement calibrations

  • Different calibrations for different beam types
  • Zero-suppression modes: uncaptured beam

and accurate intensity

EDMS 2234336 10/07/2019 11

slide-12
SLIDE 12

New measurement calibrations

  • LHC beam type:
  • baseline correction of 25ns buckets

EDMS 2234336

Graphic by

  • T. Levens

10/07/2019 12

slide-13
SLIDE 13

New measurement calibrations

  • Fixed-target beam type: turn-by-turn

baseline correction

EDMS 2234336 10/07/2019 13

Graphic by

  • T. Levens
slide-14
SLIDE 14

New measurement calibrations

  • Last run: automatic detection + PPM setting

for calibration factor

  • After LS2: PPM setting for baseline

correction + calibration factor

EDMS 2234336 10/07/2019 14

slide-15
SLIDE 15

New measurement calibrations

  • Zero-suppression modes:
  • One buffer with zero-suppression for accurate

intensity measurement

  • One buffer without zero-suppression to see

uncaptured beam

EDMS 2234336 10/07/2019 15

slide-16
SLIDE 16

New measurement calibrations

 possible to see both acquisitions at the same time  Total intensity is always using the accurate intensity measurement

EDMS 2234336 10/07/2019 16

slide-17
SLIDE 17

New measurement calibrations

EDMS 2234336 10/07/2019 17

slide-18
SLIDE 18

New measurement calibrations

EDMS 2234336

  • FBCT application:

Left menu → calibration

10/07/2019 18

slide-19
SLIDE 19

Other news

EDMS 2234336

  • Transfer-line FBCTs and the old ring FBCT will get

a new digital acquisition system and a new FESA class

  • The transfer-line FBCT and the old ring FBCT are

based on the same system

  • We will have a live acquisition (10Hz) of the FBCT
  • Improved turn-by-turn acquisition
  • FBCT data will be in the QC

10/07/2019 19

slide-20
SLIDE 20
slide-21
SLIDE 21

FBCT application

EDMS 2234336 10/07/2019 21

slide-22
SLIDE 22

FBCT application

EDMS 2234336 10/07/2019 22

slide-23
SLIDE 23

FBCT application

EDMS 2234336 10/07/2019 23
