SPS PRESENTATION COBETTER DRUM SPD 200L WWW.SPS-EUROPE.COM WWW.SPS-AMERICA.COM WWW.SPS-ASIA.COM www.sps-europe.com | www.sps-america.com | www.sps-asia.com
2 C O B E T T E R I N T R O D U C T I O N C4 C5 R&D, Lab and Factory C C 1 2 C6 C 3 SET UP C1 Factory Membrane Filter Manufacturing 9400 SQM C2 Factory Depth Filter Manufacturing 9000 SQM C3 Factory Semiconductor Filter Manufacturring 13600 SQM, 2019 Building C4 Factory C6 Factory C5 Factory Sustainless Filter Manufacturing & Fluoroplastics Resurtech R&D Lab center 41000 SQM, 2020 Life Center 25000 SQM, 2020 Manufacturing & Housing Manufacturing 28000 SQM www.sps-europe.com | www.sps-america.com | www.sps-asia.com
3 APPROVED DETECTION & VALIDATION CAPABILITY They have 9 Labs 80+ Scientists & technicians More than 54 Testing Items and 1200+ Reports per Year
4 Double O-rings Effectively Eliminate Risk of Leakage Applications • !"#$% '"%$ (%") *+ ,$+*-.$, /0% $1$23%0.*2 4 -%5,$ +#$2*5136 27$)*251+8 +"27 5+ 9'!!!8 9'!!8 :;!<=8 :><?8 :@8 A<BC8 DEF:8 GEG $32H • !'( 25. I$ "+$, /0% G53$-0%6 JJ 27$)*251+ K7$%$ ,$.+*36 *+ 1$++ 375. CHL-M2)? (%") #%$++"%$ 25. %$527 ;NO P#5H Features and benefits Integrated filter sealing • Patented: Double sealing design structure Double Sealing • @001#%00/ ($+*-.Q R5+ 25# 5,0#3 B"%0#$5.4+361$ 37%$5, S(J>TOUNVW X*Y"*, ,*#4 Design (Patent) 3"I$ 5,0#3 F)$%*25.4+361$ 37%$5, SA"33%$++VH S'%$25"3*0.+ Z (J'4D"I$ *,$.3*/*253*0. 5%$ )5%P$, 53 ,*#43"I$ +*,$HV • Low residual bottom design with Cobetter unique dip-tube, can reduce residual liquid and improves chemicals utilization. • G"+30)*\$, #52P5-*.- 15I$1Q 15+$% #%*.3*.- ]^ G0,$ 0. 37$ 30# 0/ ,%")H _0" 25. +25. ]^ 20,$ *./0%)53*0. K7*27 20..$23+ K*37 E$+ *./0%)53*0. +6+3$)H • COOO 215++ 21$5.1*.$++ K0%P+70#H J..$% 156$% "+$+ "13%5 #"%$ )53$%*51H • Standard UN testing equipment, double reviewed by customs and quality supervision bureau. Double O-rings Effectively Eliminate Risk of Leakage www.sps-europe.com | www.sps-america.com | www.sps-asia.com
5 Product Specifications Material Outer layer HDPE1+Color Master Batch+ Aging Resistance, 20% Middle layer HDPE2+Color Master Batch, 60% Inner layer HDPE3, 20% Weight 13kg±0.03kg Volume 208L±2L Metal ion <5ppt Particle >0.3µm, ≤ 10 EA/ml Pressure rating 250kpa+ Dimensions (mm) Diameter 582 mm Height 892 mm Upper L-ring Height 35 mm Lower L-ring Height 24 mm Drum Hole Spacing 360 mm 5
6 Ordering information Model SPDS Block 1 Block 2 Block 3 Block 4 Block 3 Block 4 Block 1 Block 2 Code O-ring Number Code Type of Drum Hole Sealing Code Liquid Thread+ Air Thread Code O-ring Material 1 No radial sealing CC Double airtight Cap 0 BUTTRESS+DIN 0 POE 2 Double sealing (patent) CT Airtight Cap+Dip-Tube A DIN+DIN F FFKM CA Venting Cap+Airtight Cap B BUTTRESS+BUTTRESS V FKM AA Venting Cap+Venting Cap C DIN+BUTTRESS E EPDM
7 Pallet dimension (mm) Pallet Size 1100mm•1100mm•120mm www.sps-europe.com | www.sps-america.com | www.sps-asia.com
8 CDT Series Superpure Dip Tube Material Name Specific A Company Connect Dispenser; one shaped and QR code injection molding technology. Insert Key Code Tabs matching for visual fool-proof connection. Laser QR code for easy identification and trace. Customized dip tube length minimizes residual effectively. For semiconductor chemicals, Shipping Cap and Dip-tube are made by ultra- pure HDPE, manufactured and assembled in clean room. Optional Color insert Key Code Tabs Red (Standard) Different chemicals with different color insert key code tabs www.sps-europe.com | www.sps-america.com | www.sps-asia.com
9 Product Specifications Thread Size S62•5 Material High-purity HDPE Seal Material POE/PE/FKM Dip Tube Length Customixed Lengte (lower residual) Part Number Laser Print On Body of Drum Key Code Compatible with A company, Germany Dip Tube Length Insert Key Code Red(standard) (optional, details in ordering info Seal Size ¾ ” Accessory Universal Wrench, Dust Cover Dimensions – Torque Value Definition Size Torque (Nm) S62*5 30+5 ¾ ” Dispense Shipping cap 5-6 www.sps-europe.com | www.sps-america.com | www.sps-asia.com
10 Ordering information Dip Tube – Model CDT Block 1 Block 2 Block 3 Block 4 Block 5 Block 4 Block 5 Block 1 Block 3 Block 2 Code O-ring Material Code Thread Code Cleanliness Code Dip Tube Length (under seal) Code Chemicals O POE O DIN S Super Pure HDPE for UPSSS Chemicals 1* L 915 mm 00 Standard F FFKM F Buttress N Normal HDPE for UPS Chemicals M 910 mm HC HCL V FKM V DIN double seal I Normal HDPE for industrial Chemicals C Customizable HF HF E EPDM E Buttress double C Customizable NO HNO3 seal SO H2SO4 HO H2O2 1* Ultra-pure HDPE material was manufactured and BE BOE1 assembled in clean room, transformed to specific design EC EKC 265 of semiconductor ultra-pure chemicals EA Etching Mixure Swap
11 Common Chemical Product Code Number Part Number Key Code Ring Dispenser- Inser Code Key* Contents Code Number head Number Color HC 135 246ABC ORANGE Hydrochloric acid (HCI) HF 235 146ABC GREEN Hydrochloric acid 20%-60% (HF) NO 123 456ABC GREY Nitric acid (HNO3) SO 124 356ABC BLUE Sulfuric acid (H2SO4) HO 134 256ABC YELLOW Ammoninum fluoride solution (NH4F) BE 245 136ABC BLACK BOE1 EC 14B 2356AC RED EKC265 EA 2AB 13456C RED Etching mixture Awap 00 N/A N/A RED * *: Part numbers in combination with all codes are not available. Please contact us for the part number availability
12 CAC Series Superpure Cap Model CAC • Ultrapure HDPE injection molding • Venting PTFE Membrane (optional): for different kinds of chemicals • O-ring: adopt ultra pure material POE Block 1 Block 2 Block 3 Block 4 Block 4 Block 1 Block 2 Block 3 Code Thread Code Cleanliness Code Venting Performance Code O-ring Material A DIN S Super Pure HDPE for UPSS, UPSSS Chemicals 1* 00 Airtight O POE B Buttress N Normal HDPE for UPS chemicals 01 One-layer venting membrane F FFKM C DIN double seal C Customizable 02 Double-layer venting membrane O FKM D Buttress double seal F EPDM 1* Ultra-pure HDPE material was manufactured and assembled in clean room, transformed to specific design of semiconductor ultra-pure chemicals
SPS Products Handling Shipping Wetprocess / CMP Thin film Photolithograpy Offices: S.P.S. bvba S.P.S. bvba S.P.S. S.R.L. SPS-Asia Technology Pte. Ltd. SPS-Europe B.V. SPS-Europe GmbH S.P.S. Ltd. Steenweg op Withof 5 9, Rue du Pont Via Pietro Mascagni 31 10 Ubi Crescent Midden Engweg 41 Weisbergerstraße 3 Aghmhor Annex B-2960 St. Job in ’t Goor 69390 VOURLES 20122 Milano Ubi Techpark Lobby B, #06-18 NL-3882 TS Putten D-85053 Ingolstadt Whitmuir, Selkrik Belgium France Italy Singapore 408564 The Netherlands Germany TD7 4PZ United Kingdom Tel.: (32) 3 440 0895 Tel.: (33) 4 72 31 78 35 Tel.: (39) 3 457 357 177 Tel.: (65) 911 30 172 Tel.: (31) 341 360 590 Tel.: (49) 841 370 530 Tel.: (44) 1750 725 712
T H E E N D F O R M O R E I N F O R M A T I O N WWW.SPS-EUROPE.COM WWW.SPS-AMERICA.COM WWW.SPS-ASIA.COM www.sps-europe.com | www.sps-america.com | www.sps-asia.com
