The Natural Fuel for Transportation

1

LNG - Liquefied Natural Gas David Jaskolski Manager, Fuels Pivotal LNG

2

Pivotal LNG – A part of Southern Company Gas

• Pivotal LNG is a wholly owned subsidiary of Southern Company Gas

(Formerly AGL Resources)

• We own and operate natural gas liquefaction facilities that sell LNG as a clean,

safe, economical fuel for transportation and other uses

• Southern Company Gas has a rich history that spans more than 150 years.

Today, we continue to build upon our reputation as a leader in the natural gas

• industry. Based in Atlanta GA, we serve 4.5 million customers in 7 states.
• Southern Company Gas business segments consist of natural gas distribution
• perations, retail operations, wholesale services and midstream operations.

2

3

What is LNG?

• LNG is the same natural gas that 65 million Americans use in

their homes, condensed into liquid form

• Turning natural gas into a liquid gives LNG a very high

energy density

• 1 cubic foot of LNG is equal to 600 cubic feet of natural gas

vapor (600 to 1 ratio)

• LNG is a very pure form of natural gas - pipeline impurities

drop out in the liquefaction process leaving 90% + methane

4

LNG has backed up gas pipeline systems for 50 years

4

5

LNG Plant – Ball Ground, GA

6

LNG is safe and environmentally friendly

• LNG is not flammable – only natural gas vapor in a concentration
• f 5% to 15% gas vapor to air is flammable
• LNG is not toxic or corrosive
• If LNG is spilled, it quickly vaporizes and rises safely into the air
• LNG is not under high pressure - stored at atmospheric pressure

to 200 PSI

• LNG is very cold (-260 degrees at 0 psi) but it is safe to handle

with minimal personal protective equipment.

7

8

LNG Plant Locations

9

Positioned to Serve Major Southeast Freight Corridors

10

Some applications currently served by Pivotal LNG

On-Highway

• UPS - fueling truck fleets

in:

• Nashville, TN
• Knoxville, TN
• Jacksonville, FL

Marine

• Tote Maritime – Two new

container ships now fueling with LNG in Jacksonville, FL

11

LNG and L-CNG stations are simple and can be deployed anywhere, similar to diesel

12

The simplicity of an LNG fuel station

12

13

LNG can also be used for CNG applications

• LNG can be used as a supply for a compressed natural gas (CNG) station

when proximity to a large natural gas pipeline or ample electrical supply for compression is not available

• This is known as L-CNG

13

14

The simplicity of an L-CNG station – It can be deployed anywhere diesel is used

14

15

LNG is used as a fuel in a variety of applications

• Heavy Duty On-Highway Trucks
• Marine Vessels (Ocean and River)
• Rail
• Industrial Process Equipment
• Mining / Aggregate/ Heavy Equipment
• Oil and Gas Drilling Equipment
• Mobile Power Generation

16

UPS is the leader in the deployment of LNG in on highway applications

17

Drayage trucks that use LNG can significantly reduce emissions in non- attainment areas, Already\ successfully deployed in California

18

Florida East Coast Rail is successfully deploying LNG fueled locomotives that run regularly from Jacksonville to Miami

19

LNG fuel tanks are manufactured in Canton, Georgia by Chart Industries

20

Considerable Room for Growth – Natural Gas as a Vehicle Fuel is only 0.13% of the total consumption of natural gas

Source - US DOE Alternative Fuels Data Center

21

Key Takeaways

• LNG is not new, it has been used to backup the natural gas pipeline

system for 50 years

• LNG is a safe, natural, environmentally friendly fuel. The same natural

gas you use at home, but in a portable liquid form.

• LNG can be deployed anywhere diesel is currently used. No pipeline or

electrical infrastructure required

• LNG is successfully being used in the southeast to fuel trucks,

locomotives and ships

Pivotal LNG Liquefied Natural Gas Fuel

• David Jaskolski
• Manager, Fuels
• Pivotal LNG
• 404-783-3550
• djaskols@pivotallng.com
