The National Ignition Facility Integrated Computer Control System - - PowerPoint PPT Presentation

John P. Woodruff NIF Project Software Architect Lawrence Livermore National Lab Presented at Stanford Linear Accelerator Center 13 April 2000

The National Ignition Facility Integrated Computer Control System

NIF-0046265

2-jpw/jj

The National Ignition Facility is a high-energy laser for inertial confinement fusion research

Optics assembly building Amplifier power conditioning modules Cavity mirror mount assembly Periscope polarizer mount assembly Target chamber Beam control & laser diagnostic systems Pre-amplifier modules Diagnostics building Final optics system Transport turning mirrors Pockels cell assembly Power conditioning transmission lines Amplifier Spatial filters Switchyard support structure Control room Master oscillator room

NIF Project Team

Lawrence Livermore National Lab Los Alamos National Lab Sandia National Lab Univ.. of Rochester/Lab for Laser Energetics

NIF-0046265

3-jpw/jj

Agenda for Presentation

Requirements for NIF Computer Controls

– Subsystems and operational scenarios – Typical user interface

Integrated Timing System requirements and performance ICCS Software Architecture

– Distributed computational resources – Frameworks – Reusable abstractions – Construction of executable processes from generic templates

CORBA communication infrastructure

– Role of interoperable distributed objects – Performance measurements

NIF-0046265

4-jpw/jj

Computer control system functional requirements

Centralized control and monitoring of laser equipment Maintain machine configuration and operational history Coordinate shot countdown and data archiving Conduct shot in ‘real-time’ over 2 second period Conduct automated shot every 8 hours with 7 by 24 operation

NIF-0046265

5-jpw/jj

ICCS is a distributed system that does not have hard real time requirements

Supervisory software is event driven

– Operator-initiated actions and scripted sequences do not require specific response times – Speed requirements derive from operator needs for interactive response – Status information is propagated from the laser to updates on graphic user screens

No process-related hard deadlines must be met

– Several hours of preparation precede shot – Shot executes in microseconds, controlled by dedicated hardware – Data gathering and reporting occurs in minutes after the shot

Some process controls are encapsulated in front-ends

– Automatic alignment – Capacitor charging

NIF-0046265

6-jpw/jj

The functional system description of the control system maps to distributed architecture

Front-end Processors and Controllers (Distributed Hardware) Supervisor System (Distributed Software) Distribution Infrastructure NIF Cable Plant and Control Points

Increasing Integration

NIF-0046265

7-jpw/jj

Functionality is partitioned into subsystems

Shot Director

Beam Control Optical Switch Power Conditioning Target Diagnostics Optical Pulse Generation Laser Diagnostics

Shot Integration

Deformable Mirror Plasma Pulser Power Conditioning Laser Power Master Oscillator Laser Energy Automatic Alignment Preamplifier Module Target Diagnostics Industrial Controls Alignment Controls Timing Digital Video

Service FEPs

Shot Services Precision Diagnostics

Supervisory Subsystems Application FEPs

Switch Pulser Pulse Diagnostics High Resolution Video Wavefront Image Processor Beam Transport

Vertical subsystems

NIF-0046265

8-jpw/jj

The hardware boundary is the solid ground

• n which we build our software architecture

The control points are relatively inflexible

– NIF equipment will evolve only slowly – Changes to equipment will be expensive – Therefore the software can expect to evolve slowly along with equipment evolution

By contrast, the user interfaces and experimental execution

plans will evolve more rapidly – The user community will learn innovative ways to use the facility – Experimental campaigns will arise in response to researchers’ creativity

NIF-0046265

9-jpw/jj

A typical user interface shows broad-view status and offers pop-up control panels

NIF-0046265

10-jpw/jj

Activities that constitute a shot cycle are defined as abstract state transitions

3–7 hours 30 minutes Concurrent System Maintenance Activities VI Archive Target Shot Secondary Shot I Begin Shot Cycle II Populate Plan III Implement Plan Ready IV Interlock & Verify V Countdown Post Countdown Shot! ~10 minutes (variable) Cleanup Activities End Shot Cycle Analyze Shot & Update System Primary Shot Retry

NIF-0046265

11-jpw/jj

NIF shot in ‘real-time’ lasts 2 seconds under control of dedicated hardware

1 µs 1 ms 1 s 1 s 1 µs 1 ms

PRE-SHOT POST-SHOT

Lamp drivers Transient Digitizers Framing Cameras Trigger Examples

The Shot

T-1 Abort System - suspend wavefront control

PEPC Arm video PEPC Simmer Stop PEPC switch digitizers Simmer Start

Fast Timing ±10 ms (1 ns) Computer Network Extended Range Fast Timing ±5 s (100 ns) Precision Timing ±1 µs (30 ps) Computer Network Computer Network Target T0

NIF-0046265

12-jpw/jj

Optical Pulse Generation Amplifier Lamps Optical Switch Target Diagnostics

Integrated Timing System

Power Conditioning Laser Diagnostics Energy Power Imaging Optical Path Triggers (to 30 psec resolution)

Beginning

• f time

The timing system orchestrates laser firing and triggering of diagnostics

NIF-0046265

13-jpw/jj

Trigger System Requirements

Extended Range Fast units Precision units # of channels 150 1900 50 Minimum range +/- 1 sec. +/- 55 msec. +/- 10 usec. Resolution (setting) <100 ns < 1 ns 20 ps Stability (jitter) <1 ms (jitter & wander) <100 ps RMS (over 10 sec) <20 ps RMS (over 10 sec) Stability (wander) See above < 500 ps - pk to pk (over 7 days) <100 ps 95 % (over 7 days)

NIF-0046265

14-jpw/jj

ITS Trigger system is divided into two functional sub-systems

Facility Timing Sub-system Located in one area of NIF Local Timing Sub- systems located in 14 areas of NIF

Trigger system architecture

NIF Control Network Master Timing Transmitter Master Timing Measurement sub-system Fan

• ut

Rcvrs Facility Timing FEP

14 ea.. 14 ea..

14 Zones

8 ch Delay Generators Up to 32 per Zone

Local Timing FEP

1x8 FO Splitters Up to 4 per Zone

16 outputs.

1 unassigned Ref.

Single mode Fiber Optics components connects Facility and Local Timing hardware Trigger System parameters set via users using computers, GUI and NIF Controls Network

NIF-0046265

15-jpw/jj

First-article timing components have been demonstrated to exceed NIF requirements

Precision delay generator Timing transmitter Measurement system

Parameter Specification Verified Delay range 2 sec 2 sec Resolution < 20 ps 7 ps Short-term stability < 20 ps RMS 5 ps RMS Long-term stability < 100 ps < 50 ps

NIF-0046265

16-jpw/jj

Servers

Remote Workstations

24 Video Digitizers ATM 155 M b/s Switch

8 Supervisory Consoles

Core 1 G b/s Ethernet Switch Edge Ethernet Switch

The computer network employs switching technology to assure performance

Automatic Alignment Servers

ATM OC-3 155 Mb/s (Fiber) Ethernet 100 Mb/s Ethernet 10 and 100 Mb/s

Legend Edge Ethernet Switch Front End Processors Front End Processors

200 Edge Switches 300 FEPs 500 TV Cameras 2,000 loops Two Dual-Monitor Workstations per Console

Firewall Users & External Databases

NIF-0046265

17-jpw/jj

Software applications are built upon a framework of distributed services

Integration Services Supervisory Console Front End Processor Status Monitor Device Control

• System manager
• Device hierarchy
• Access control

Status Display Operator Controls

Database

• History
• Shots
• Configuration

Event Log

Interface Driver

Software Distribution Bus (exists on network)

Controller Object Request Broker

Software objects representing control points “plug in” to the software distribution bus

300 front-end processors interface to NIF equipment

CORBA Server Workstation

NIF-0046265

18-jpw/jj

The ICCS software architecture centers on widely used “Framework” components

Our frameworks have been discovered by domain analysis

– Experience with similar experimental facilities – System requirements that span subsystems – Abstractions of services

The dozen frameworks fall into three categories

– Abstract services – “System Manager” starts processes, observes performance – Architecture - specific services – “Configuration” initializes the state of persistent objects – “Sequence control” embeds a scripting language into control objects – NIF - specific operational services – “Shot life cycle” abstracts the states that all subsystems enact in an experiment

NIF-0046265

19-jpw/jj

These abstract frameworks are being built with prospective reuse in mind

Managing the lives of processes and application objects

– System manager – Generic main programs – Configuration: delivers database services

Organizing operational records

– Message Log – Machine history – Shot Data archive

Distributing up-to-date device status

– Status monitor: polls locally and pushes updates

Managing interactions with operators

– Graphic user interface – Reservation – Sequence control language – Alert notification

Implementing the state transitions in an experiment

NIF-0046265

20-jpw/jj

All supervisor and FEP programs are built by elaborating a generic template

Configuration Server Central System Manager

Private Application Objects

Local System Manager

Public Application Objects Main

Private Factory Public Factory

DBMS Generic Application

Controller Objects

Local System Manager

Device Objects Main

Controller Factory Device Factory

Generic FEP

NIF-0046265

21-jpw/jj

Abstract frameworks are (largely) independent of each other

Four frameworks provide distinct information services

– Configuration: data to start devices – Example: signal level addresses, instrument calibration – Message log: audit trail of operator action and system responses – Machine history: service records of device performance – Shot archive: results of physics experiments

The different information services share common features

– Devices are named consistently in each data record – Records can be correlated, for example by time stamp

But the Policies that connect them are not inherent in the frameworks

themselves

Additional templates (for innovative frameworks) can be introduced

without disturbing components already in place.

NIF-0046265

22-jpw/jj

Frameworks are constructed in layers to permit retargeting

Framework Templates Layer Abstract classes for control systems Abstract devices, Configuration, Monitor, etc Devices, Shot phases, etc NIF Building blocks Classes that model equipment

Support layer

COTS and components Oracle DBMS, ORBexpress, etc Framework Services Customized for a specific system Configuration Server, System Manager, GUI’s, etc ICCS Programs Client and server mainlines Supervisor applications, Front End Processors, Database servers, etc

NIF-0046265

23-jpw/jj

The framework services layer is specific to NIF, built by extending reusable framework abstractions

The Framework Services are delivered when dispatching operations

defined in the template are applied to concrete classes. – The “Device” class is an abstract superclass – This base class defines interfaces applicable to all devices – for naming – for reserving on behalf of an operator – for multi-task safety – Several dozen derived classes control physical equipment – Diverse actions defined for motors, power supplies, diagnostic instruments, precision timing and triggering – Initialization from a central database – Descendents of the abstract device class provide actual operations to control physical NIF parts

NIF-0046265

24-jpw/jj

Dependencies between levels are strictly hierarchic

Subsystems within a particular layer can only depend upon

subsystems at the same or a lower layer – This allows classes at a given layer to be replaced or extended – Only layers above the replacement are affected

Replacement of the all the concrete classes derived from Device could

make the “Application services” frameworks available for a different kind of experimental facility – Adding new subclasses of Device enables evolution of the NIF – Replacement of state transition actions would produce new operational services

NIF-0046265

25-jpw/jj

Numerous GUI’s receive status updates from Supervisors

Separate the operator interaction from system behavior Provide a consistent multi-display view of the system state Economize on message traffic by “pushing” status changes

Logical Control Unit Front End Processor

Commands

Graphical User Interface 1 Graphical User Interface 2

Updates Commands Commands Updates Updates

NIF-0046265

26-jpw/jj

Efforts to economize on message traffic

Status of every Device must be observable at multiple consoles

– Some status reports require latency as small as 0.1 second – Monitor objects are co-located with Devices – Local polling in the FEP – Notification of “significant” change

Supervisory objects collect and collate change reports

– GUI’s that display “broad view” status subscribe to these supervisors – GUI’s receive their status updates via “data push” from the supervisor

NIF-0046265

27-jpw/jj

CORBA provides decentralized distribution services

A standard model of distributed objects resolves a major development

risk – ICCS software engineers are freed from building a “homebrew”communication infrastructure – Anticipate 30-year life of the standard

CORBA defines loose coupling between objects

– Communication becomes nearly invisible – Neither clients nor servers depend directly on communication infrastructure – Names of communicating objects hide locations – Transparent interoperability – IDL specifications are language-neutral interfaces – Data marshalling hides differences between hosts

Allocation of object implementations to processes can be deferred

NIF-0046265

28-jpw/jj

ICCS uses CORBA to distribute Ada-95 objects

Each of the 60,000 control points is controlled by one of the Front-End

processors – Each is implemented as an instance of a class derived from Device – These derived classes are specified using Interface Definition Language (IDL)

The ORBexpress IDL compiler translates the IDL to an Ada interface

package and an implementation package

“Abstract” classes that are defined by IDL translate to a concrete

interface defining a classwide reference

Framework objects perform their operations by dispatching calls on

these classwide references

ORBexpress produces invocations of the methods in the

corresponding implementation

NIF-0046265

29-jpw/jj

The majority of NIF’s CORBA objects are long-lived

60_000 objects implement the class Device in Front-End Processors

– About 130 subclasses – Each instance is initialized at system start-up – A framework manages data and naming – Oracle database maintains configuration – Persistence broker objects implement SQL queries on behalf of CORBA clients

A dead server is an error to be diagnosed and recovered

– Failover to a replacement of the same class is not automated

NIF-0046265

30-jpw/jj

Using IDL to define interfaces implies some compromises

Interfaces must be declared in terms of IDL types

– These types “diffuse” into the rest of the system – IDL type model is less strict than Ada’s – No range constraints – No initial values for record components – No default parameter values – No operator overloading in interfaces

Configuration management must accommodate to the possibility that

implementation details might be loaded into client processes

NIF-0046265

31-jpw/jj

Measurements of ORBexpress 2.0.1 confirm adequate performance

Network is 100 Megabit ethernet Both client and server are 2-processor Sun Enterprise 3000’s

– Client runs 40 Ada tasks; server runs 5 – Runtime is Apex 3.0 – GNAT 3.11 is roughly 10% faster

300 600 900 1200 1500 1800 2100 2400 2700 3000

Message Size (Bytes)

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

Msg Rate (100Mbit) % Client CPU % Server CPU % Network

NIF-0046265

32-jpw/jj

The ICCS strategy rests on two main decisions

Single unified architecture unites all subsystems

– Frameworks implement abstractions for widespread use – Distributed object-oriented system exploits CORBA – Design patterns embody programming choices – Publisher-subscriber relationships – Model-view-controller idiom for user interface

Managed process guides development

– Ada is the principle programming language – Documents are written and reviewed – Development proceeds incrementally – Code walkthroughs catch errors early in cycle – Each cycle of development is reviewed – Process is adjusted to incorporate lessons learned

NIF-0046265

33-jpw/jj

A disciplined engineering process manages incremental construction and release of code

Unix Target Object-Oriented Design Tool Requirement Specification Design Description

NIF Software

Ada Host Compiler Ada Cross Compiler Ada Language Editor

Interface Specification

Object Model Real-time Target

Reverse Engineering Automatic Code Generation

• f Specifications

Engineers write code details

Object Request Broker Distribution

Target Architectures Sun Sparc VxWorks PowerPC Engineers model software framew ork Architecture Neutral

CORBA

NIF-0046265

34-jpw/jj

DISCLAIMER UCRL-VG-138473

This document was prepared as an account of work sponsored by an

agency of the United States Government. Neither the United States Government nor the University of California nor any of their employees, makes any warranty, express or implied, or assumes any legal liability or responsibility for the accuracy, completeness, or usefulness of any information, apparatus, product, or process disclosed, or represents that its use would not infringe privately owned rights. Reference herein to any specific commercial product, process, or service by trade name, trademark, manufacturer, or otherwise, does not necessarily constitute or imply its endorsement, recommendation, or favoring by the United States Government or the University of California. The views and opinions of authors expressed herein do not necessarily state or reflect those of the United States Government or the University of California, and shall not be used for advertising or product endorsement purposes.

This work was performed under the auspices of the U.S. Department of

Energy by University of California Lawrence Livermore National Laboratory under contract No. W-7405-Eng-48.
