The Collaboration Game Niels van Dijk, Technical Product Manager SURFnet Topics - Identity federations 2010 - The Collaboration Game - A distributed landscape - Enter Domestication - The future of Domestication Identity federations 101


slide-1
SLIDE 1

The Collaboration Game

Niels van Dijk, Technical Product Manager SURFnet

slide-2
SLIDE 2

Topics

  • Identity federations 2010
  • The Collaboration Game
  • A distributed landscape
  • Enter Domestication
  • The future of Domestication
slide-3
SLIDE 3

Identity federations 101

Source: David Simonsen, WAYF

slide-4
SLIDE 4

Identity federations

Source: David Simonsen, WAYF

slide-5
SLIDE 5

Identity federations

Source: David Simonsen, WAYF

slide-6
SLIDE 6

Identity federations

Source: David Simonsen, WAYF

slide-7
SLIDE 7

Federations 2010

By now Identity Federations in edu have become mature:

  • 27 federations (EU, US, Asia)
  • Interfederation (Kalmar, eduGAIN, REFEDs)
  • Interdomain (US, Denmark)
  • SAML 2 (Shibboleth, SimpleSAMLphp)
  • Vendor supported (Microsoft, Google, Cisco,

Atlassian) and many OpenSource products

slide-8
SLIDE 8

Stuff federations provide

Or they will, shortly ;)

  • Is that your “staff” attribute?
  • Level of assurance (LOA)
  • Get interfederation working!
  • WAYF
  • Getting the GUI sorted out

Core building block for trusted relations

slide-9
SLIDE 9

Mature?

Source: http://xkcd.com/806/

slide-10
SLIDE 10

The Collaboration game

Modern universities are developing towards loose conglomerates of (inter)discipline expertise → Collaboration is therefor core business Collaboration involves people in multiple institutions in multiple countries Collaboration is about using shared resources People + resources = Virtual Organization

slide-11
SLIDE 11

Collab usecases - 1

“Student Thesis”

  • Group of students
  • University staff
  • Employee at Commercial Company

Tools

  • Generic collaboration tools

Example

  • Every university campus
slide-12
SLIDE 12

Collab usecases - 2

Sharing 'data'

  • Groups of (inter)discipline scientists in several

countries

  • Staff at multiple universities
  • Employees at multiple commercial companies

Tools

  • (Webbased) generic collaboration tools
  • (Webbased) shared data resources

Examples

  • Lifewatch, Clarin, Knowledge Exchange, Terena
slide-13
SLIDE 13

Collab usecases - 3

Sharing (expensive) eScience infrastructures

  • VERY Large groups of international scientists
  • Staff at multiple universities

Tools

  • generic collaboration tools
  • Shared infrastructure & data resources

Examples

  • LHC, LIGO, LOFAR, eVLBI
slide-14
SLIDE 14

LOFAR: distributed low frequency array

  • A distributed multibeam array for radioastronomy
  • Large number of very simple antennas, with very

high bandwidth connections

slide-15
SLIDE 15

E-VLBI: a global radiotelescope

slide-16
SLIDE 16

LHC Computing Grid and LHCOPN

slide-17
SLIDE 17

A distributed landscape

Modern science combines eScience resources from multiple sources with generic collaboration

  • The core resources are within the R&E domain
  • Some activities already moving off campus

(MyExperiment, Mendeley) Collaboration is already in 'the cloud' Twitter, Facebook, Linkedin, Wikis, Blogs →

slide-18
SLIDE 18

(C) 2009 SURFnet B.V. 18

slide-19
SLIDE 19
slide-20
SLIDE 20

COIN vision

slide-21
SLIDE 21

Dealing with a distributed landscape

NRENs can play a vital role as trusted third parties:

  • Provide collaboration services

SURFgroepen →

  • Provide 'putty'

the COIN Project → What is our putty made off?

  • Trust framework
  • Attributes
  • Externalized Groups
  • Roles and Rights
  • Coherence
slide-22
SLIDE 22

Applying putty

  • Trust framework

Identity Federations →

  • Attributes

Identity Federations + aggregation →

  • Groups

Group management tools →

  • Roles and Rights

? →

  • Coherence

VO Platfoms → Domestication is the process of applying putty to applications and services

slide-23
SLIDE 23

Domestication

  • Domestication can be described as the process of

externalizing authentication, authorization and group management from services

  • Domestication fits nicely in the Service Oriented

Architecture paradigm where a platform is created for reusable services and service components

  • It becomes easier to share (generic) information

among services and to replace similar services

  • It is only useful in multi-domain collaboration or

enterprise environments, hence (delegation of) trust is a point of concern

slide-24
SLIDE 24

Domestication (2)

  • Domesticated applications enable single sign-on

features for users, as well as the ability to share group context between multiple applications

  • Main Candidates
  • Identity and access control
  • Group management
  • Events like presence and activities
  • Perhaps Monitoring and Reporting and

messaging?

slide-25
SLIDE 25

End User Perspective

  • Pro
  • Single Sign On
  • One password (and identity) for multiple

services

  • Cons
  • WAYF – where are you from
  • Service might ask again and again your profile

information etc.

slide-26
SLIDE 26

Organizational Perspective

  • Pros
  • In control – one set of credentials for all

services

  • Happy and secure users
  • Cons
  • None?
  • Prerequisites
  • Get your Identity Management on track
  • Get organized – convince service providers to

become domesticated

slide-27
SLIDE 27

Service Provider Perspective

  • Pros
  • Validated and up-to-date (user) information
  • Focus on core business
  • Reduction of administrative overhead – no more “I

lost my password”

  • Economy of scale (after initial investment – adding

new organizations is easy

  • Cons
  • Most services already provide a solution for the

generic functionality (needs to combined with legacy generic functionality)

  • Invest in APIs in an unknown technology territory
slide-28
SLIDE 28

NREN Strategy

  • Create economy of scale to create a valid

business case for Service Providers

  • Do it yourself (maintainable?!)
  • Need for standardized interfaces, APIs and

availability of libraries

  • Need to deal with trust
slide-29
SLIDE 29

Doing it yourself

slide-30
SLIDE 30

Doing it yourself -2

slide-31
SLIDE 31

External systems - AuthN

Authentication SAML →

  • Use an already SAML enabled application
  • Modify an application to handle SAML based

authentication (Shibboleth, SimpleSAMLphp, OIOsaml, etc)

  • Use a 'proxy' if the

application has an API

slide-32
SLIDE 32

External systems - Attributes

Getting Attributes

  • SAML assertion

Often a SAML assertions contains → attributes, which are mostly standardized (eduPerson, SCHAC)

  • SAML Attribute Query

not widely implemented →

  • Attribute Query

via other means, e.g. LDAP, → Webservice API

  • Let user fill in missing attributes
slide-33
SLIDE 33

External systems - Groups

Getting Groups – Nothing here yet....

  • SAML assertion

Only at login, cumbersome at IdP →

  • SAML Attribute Query

not widely implemented →

  • Attribute Query

LDAP, SPML, Webservice API → What if an application needs group memberschip before login?

slide-34
SLIDE 34

External systems - Roles

Getting Roles – Again, nothing here yet....

  • SAML assertion

Only at login, cumbersome at IdP →

  • SAML Attribute Query

not widely implemented →

  • Attribute Query

LDAP, SPML, Webservice API → (Ab)using groups as roles? What if an application needs to set roles before login?

slide-35
SLIDE 35

Provisioning

Provisioning is application specific

  • Preferably done by the vendor
  • Else, use APIs
  • Or hack the app...

The amount of effort, and the most optimum way of provisioning depends on the functional requirements of the application. See: Provisioning scenarios in identity federations

slide-36
SLIDE 36

Deprovisioning

  • This page was intentionally left blank -
slide-37
SLIDE 37

The Future of Domestication

Standardize

  • Settle on standards
  • Reduce and standardize the number of

implementations What other stuff would we like externalized

  • Events
  • Messaging
  • Monitoring and Reporting

How will domestication beyond the web?

slide-38
SLIDE 38

Domestication Wiki

https://wiki.surfnetlabs.nl/display/domestication

slide-39
SLIDE 39

Questions? Niels.vanDijk@SURFnet.nl
