The Boxer The Latest Innovation A New Body Maker from SLAC Richard Moore, SLAC International www.slac.com.cn 630 DWI Beverage Can lines worldwide About 4500 Bodymakers in place worldwide Total Worldwide Capacity: 424 billion cans

slide-1
SLIDE 1

www.slac.com.cn

‘The Boxer’ The Latest Innovation A New Body Maker from SLAC

Richard Moore, SLAC International

slide-2
SLIDE 2

www.slac.com.cn

630 DWI Beverage Can lines worldwide

114 147 52 91 30

17

84 53

5 15

On average: Capacity of 700 million cans per line 2.1 lines per location Total Worldwide Capacity: 424 billion cans Total Sales: 350 billion cans (82%) Total Asia: 231 lines

About 4500 Bodymakers in place worldwide

slide-3
SLIDE 3

www.slac.com.cn www.slac.com.cn Ed Maeder

1963: the birth of DWI

The first DWI can, for Hamm’s Brewery, 1964

slide-4
SLIDE 4

www.slac.com.cn

Ragsdale: the first commercial DWI bodymaker, 1970

slide-5
SLIDE 5

www.slac.com.cn

Standun bodymaker patent, 1973

slide-6
SLIDE 6

www.slac.com.cn www.slac.com.cn Ed Maeder

All use the same basic technology

slide-7
SLIDE 7

www.slac.com.cn www.slac.com.cn

Conventional production line for Beverage Cans 2100 cpm, annual capacity 900m cans

slide-8
SLIDE 8

www.slac.com.cn www.slac.com.cn

Conventional production line for Beverage Cans 2100 cpm, annual capacity 900m cans

UNCOILER CUPPER

BODYMAKER TRIMMER DECORATOR VISION SYSTEM INSIDE SPRAY LIGHT TESTER NECKER PALLETIZER

slide-9
SLIDE 9

www.slac.com.cn

Bodymakers: the heart of the process

slide-10
SLIDE 10

www.slac.com.cn www.slac.com.cn

The cup is delivered into the bodymaker toolset Brief reminder of the DWI technology The toolset starts with a redraw tool (in green)

slide-11
SLIDE 11

www.slac.com.cn www.slac.com.cn

The ram pushes the cup through the re-draw tool and gives it its new, final diameter

slide-12
SLIDE 12

www.slac.com.cn www.slac.com.cn

The ram then pushes the can through three or four successive dies, each getting smaller in diameter until the final wall thickness is arrived at through a process known as thinning or ‘ironing’ The metal flows back up the can wall and increases the can height

slide-13
SLIDE 13

www.slac.com.cn www.slac.com.cn

The ram pushes the can

  • nto the base forming

tool, which gives the end a pressure resistant and stackable ‘dome’ shape

slide-14
SLIDE 14

www.slac.com.cn www.slac.com.cn

The ram reverses movement and the can is taken away from the punch with a mixture of air pressure from the ram and mechanical stripping by a ring of fingers, depositing the can

  • nto pickup fingers on the the

discharge unit

slide-15
SLIDE 15

www.slac.com.cn www.slac.com.cn

Base 0.250 mm Top wall 0.144 mm Thin wall 0.09mm Starting gauge 0.250 mm

slide-16
SLIDE 16

www.slac.com.cn

The Boxer

slide-17
SLIDE 17

www.slac.com.cn www.slac.com.cn

slide-18
SLIDE 18

www.slac.com.cn

The Boxer uses a ‘contra’ power drive

Karl Benz

slide-19
SLIDE 19

www.slac.com.cn www.slac.com.cn

slide-20
SLIDE 20

www.slac.com.cn

Dynamic Balance

  • Two cans from each stroke
  • Two reciprocating rams on a single

flywheel, with toolpacks at either end

  • Driven by a single central motor and

crankshaft

The Boxer

  • Working like a ‘contra

engine’, the rams operate in opposite directions, counteracting horizontal vibration force and creating an almost perfect dynamic balance.

slide-21
SLIDE 21

www.slac.com.cn

Very little vibration and noise is created and there is no need for floor installations with deep foundations.

Simple fixing mechanisms Even at 350cpm, vibration is only 0.011mm, ten times less than conventional bodymakers, this is almost not discernible

slide-22
SLIDE 22

www.slac.com.cn

Smaller footprint than 2 conventional Bodymakers

Footprint 14.1 m² Footprint 17.0 m²

slide-23
SLIDE 23

www.slac.com.cn

The Boxer

  • Twice the output of a conventional Bodymaker
  • Reduced floor space
  • Energy use per can reduced by at least 40%
  • Energy use per can reduced by at least 40%
  • Very low vibration
  • Commercial: the first machine has been delivered to a customer in

Europe

  • The List Price is less than 2 conventional SLAC Bodymakers and no

more than a single competitive Bodymaker.

  • Maintaining SLAC’s vision of offering the industry the best possible

Return on Investment

  • The Boxer will be on view in Metpack
slide-24
SLIDE 24

www.slac.com.cn

SLAC now offers three bodymaker types

SC-8824L-BM

Ragsdale type Bodymaker

slide-25
SLIDE 25

www.slac.com.cn

Thank you!

The Future is Here
