Tensor what?

An introduction to AI on mobile Luke Sleeman - Freelance Android developer

http://lukesleeman.com luke.sleeman@gmail.com @LukeSleeman

Agenda

• Intro - History of AI, Recent breakthroughs, why AI on mobile is important
• Part 1 - Key AI tech - Neural networks, image recognition, voice

recognition, and Siri work

• Part 2 - TensorFlow - What TensorFlow does, Server side use, embedding

TensorFlow in a mobile app, models built with TensorFlow

• Part 3 - Demo - We recognise a banana with my phone!
• Closing thoughts - Strong AI, Why all this is important.
• Questions

Intro - A bit of history

Hal 9000 is a great example of “Strong AI”. Hal can:

• Reason (use strategy, solve puzzles, and make

judgments under uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

10 Print “Good morning Dave, I am HAL 9000”

10 Print “Good morning Dave, I am HAL 9000” 20 Input “What can I do for you?”, R$

10 Print “Good morning Dave, I am HAL 9000” 20 Input “What can I do for you?”, R$ ???

10 Print “Good morning Dave, I am HAL 9000” 20 Input “What can I do for you?”, R$ 30 Print “I'm sorry, Dave. I'm afraid I can't do that.”

10 Print “Good morning Dave, I am HAL 9000” 20 Input “What can I do for you?”, R$ 30 Print “I'm sorry, Dave. I'm afraid I can't do that.” 40 Goto 20

The First AI Winter

"within ten years a digital computer will be the world's chess champion" and "within ten years a digital computer will discover and prove an important new mathematical theorem.” - 1958, H. A. Simon and Allen Newell "Within a generation ... the problem of creating 'artificial intelligence' will substantially be solved.” - 1967, Marvin Minsky

Present Day

• IBM’s Deep blue beats Kasparov - 1997
• DARPA self driving car challenge - 2005, 2007
• IBM’s Watson wins jeopardy - 2011
• Googles AlphaGo beats GO champion - 2015

AI + Mobile = A great combo

Why AI on mobile is important

Constrained input + limited interaction means intelligence is important

Part 1 - Key AI Tech

Key AI Tech - Neural Networks

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if(x1 + x2 > 0){ … we are in! } else { … we are out! }

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if(x1 + x2 > 0){ … we are in! } else { … we are out! }

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if(x1 + x2 > 0){ … we are in! } else { … we are out! }

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if(x1 + x2 > b){ … we are in! } else { … we are out! }

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if((w1 * x1) + (w2 * x2) > b){ … we are in! } else { … we are out! }

Neural Networks - Classification problem

• 2 dimensions to our data - x1, x2
• Can draw it helpfully on a graph!

if((w1 *x1) + (w2 * x2) > b){ return 1.0; } else { return 0.0; }

Neural Networks - Classification problem

Neural Networks - Classification problem

Lets do a demo!

Neural networks - Summary

• They learn to recognise patterns from training data!
• Work for complex patterns
• Can take a long time to train
• You have to choose the right hyper-parameters (number of nodes,

how they are laid out, activation function, input transformation, etc)

Key AI Tech - Image search and Deep belief networks

Image search

Deep belief networks

• Stack a number of layers together to make a

DBN

• Early layers learn to recognise simple features
• Later use features to recognise larger objects
• A type of ‘auto-encoder’ - learns from input
• Early unsupervised training to recognise

features

• Later supervised training to learn what they

‘mean’

Deep belief network layers

Unsupervised Learning of Hierarchical Representations with Convolutional Deep Belief Networks Honglak Lee, Roger Grosse, Rajesh Ranganath, and Andrew Y. Ng

Deep belief networks

• Stack a number of layers together to make a

DBN

• Early layers learn to recognise simple features
• Later use features to recognise larger objects
• A type of ‘auto-encoder’ - learns from input
• Early unsupervised training to recognise

features

• Later supervised training to learn what they

‘mean’

Key AI Tech - Speech recognition and Recurrent Neural Networks

Speech Recognition

Speech recognition and Recurrent Neural Networks (RNNs)

• Everything up to now is a feed

forward network

• In RNN’s output is fed back in as

input

• Feedback serves as a type of short

term memory!

• Takes a sequence of inputs
• Supplies results over time

Key AI Tech - Ok Google, Siri and Recursive Neural Tensor Networks

Ok Google, Hey Siri

Sentence parsing

Alice drove down the street in her car

Recursive Neural Tensor Networks (RNTN’s)

• Good for recognising hierarchal

structures

• Tree like structure - root node + left and

right

• Just like RNN’s, the complexity is in how

they are invoked

Root Leaf Leaf

Recursive Neural Tensor Networks

The car is fast

Recursive Neural Tensor Networks

The car

Recursive Neural Tensor Networks

The car Class, Score

Recursive Neural Tensor Networks

The car is

Recursive Neural Tensor Networks

The car is fast

Recursive Neural Tensor Networks

The car is fast

Part 2 - TensorFlow

Tensor What?

TensorFlow - some code

$ python ... >>> import tensorflow as tf >>> hello = tf.constant('Hello, TensorFlow!') >>> sess = tf.Session() >>> print(sess.run(hello)) Hello, TensorFlow! >>> a = tf.constant(10) >>> b = tf.constant(32) >>> print(sess.run(a + b)) 42 >>>

TensorFlow - some code

$ python ... >>> import tensorflow as tf >>> hello = tf.constant('Hello, TensorFlow!') >>> sess = tf.Session() >>> print(sess.run(hello)) Hello, TensorFlow! >>> a = tf.constant(10) >>> b = tf.constant(32) >>> print(sess.run(a + b)) 42 >>>

TensorFlow - some code

$ python ... >>> import tensorflow as tf >>> hello = tf.constant('Hello, TensorFlow!') >>> sess = tf.Session() >>> print(sess.run(hello)) Hello, TensorFlow! >>> a = tf.constant(10) >>> b = tf.constant(32) >>> print(sess.run(a + b)) 42 >>>

TensorFlow - some code

$ python ... >>> import tensorflow as tf >>> hello = tf.constant('Hello, TensorFlow!') >>> sess = tf.Session() >>> print(sess.run(hello)) Hello, TensorFlow! >>> a = tf.constant(10) >>> b = tf.constant(32) >>> print(sess.run(a + b)) 42 >>>

TensorFlow - some code

$ python ... >>> import tensorflow as tf >>> hello = tf.constant('Hello, TensorFlow!') >>> sess = tf.Session() >>> print(sess.run(hello)) Hello, TensorFlow! >>> a = tf.constant(10) >>> b = tf.constant(32) >>> print(sess.run(a + b)) 42 >>>

TensorFlow - some code

dnnc = tf.contrib.learn.DNNClassifier( feature_columns=feature_columns, hidden_units=[20, 20, 20, 20], n_classes=2) dnnc.fit(x=latlng_train, y=is_mt_train, steps=200) accuracy = dnnc.evaluate(x=latlng_test, y=is_mt_test)["accuracy"] print('Accuracy: {:.2%}'.format(accuracy))

TensorFlow - some code

dnnc = tf.contrib.learn.DNNClassifier( feature_columns=feature_columns, hidden_units=[20, 20, 20, 20], n_classes=2) dnnc.fit(x=latlng_train, y=is_mt_train, steps=200) accuracy = dnnc.evaluate(x=latlng_test, y=is_mt_test)["accuracy"] print('Accuracy: {:.2%}'.format(accuracy))

TensorFlow - some code

dnnc = tf.contrib.learn.DNNClassifier( feature_columns=feature_columns, hidden_units=[20, 20, 20, 20], n_classes=2) dnnc.fit(x=latlng_train, y=is_mt_train, steps=200) accuracy = dnnc.evaluate(x=latlng_test, y=is_mt_test)["accuracy"] print('Accuracy: {:.2%}'.format(accuracy))

TensorFlow - some code

dnnc = tf.contrib.learn.DNNClassifier( feature_columns=feature_columns, hidden_units=[20, 20, 20, 20], n_classes=2) dnnc.fit(x=latlng_train, y=is_mt_train, steps=200) accuracy = dnnc.evaluate(x=latlng_test, y=is_mt_test)["accuracy"] print('Accuracy: {:.2%}'.format(accuracy))

Building an app with TensorFlow

TensorNo

TensorNo - Use existing APIs

• Cloud Vision - https://cloud.google.com/vision/
• Cloud Natural language - https://cloud.google.com/natural-language/
• Cloud speech - https://cloud.google.com/speech/
• Cloud Machine Learning Engine - https://cloud.google.com/ml-engine/
• Amazon Machine Learning - https://aws.amazon.com/machine-

learning/

• Algorithmia - algorithm marketplace - https://algorithmia.com/algorithms

TensorFlow on the Server side - DIY

echo 'Bob brought the pizza to Alice.' | syntaxnet/demo.sh Input: Bob brought the pizza to Alice . Parse: brought VBD ROOT +-- Bob NNP nsubj +-- pizza NN dobj | +-- the DT det +-- to IN prep | +-- Alice NNP pobj +-- . . punct

TensorFlow on the Server side - gRPC

Roll your own - Client side

• Use the tensor flow C++ library with Android NDK or for iOS in

Xcode

• Load up a prebuilt model, and feed data into it
• Need to use the Bazel build system for Android!
• Nasty mix of C, C++, Python, Java, SWIG, etc, various build

systems, etc

• Google is working on making it nicer

But what about the model?

• Build your own? You need:
• A LARGE data set - MINST has 50k images. ImageNet has 500gb
• f thumbnails
• A HUGE computer - 8 Tesla K40 GPU’s ($4216 each), 40GB

memory, etc

• A lot of time - Weeks! Months!
• Some PHD’s to run it all for you.

But what about the model?

• Use an existing one!
• SyntaxNet and Parsey McParseface - Parse text, Parse english

text to extract structure

• TextSum - Text Summarisation
• Show and Tell - Image caption generator
• Inception - Image recognition

Part 3 - Demo

Recognising a banana!

TensorFlow example app

The DEMO

Closing thoughts

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

• Reason (use strategy, solve puzzles, and make judgments under

uncertainty)

• Represent knowledge, including commonsense

knowledge

• Plan
• Learn
• Communicate in natural language
• Integrate all these skills towards common goals
• Kill All Humans

https://en.wikipedia.org/wiki/Artificial_general_intelligence

Are we any closer to strong AI?

AI needs to be for everyone!

… especially for mobile!

Questions
