TDOT IT Transforming Tennessees ITS Infrastructure Where We Were Where We Want to Be Full Center to Center connectivity to improve site resiliency. Ability to test emerging ITS technology in a network that is both state

SLIDE 1

TDOT IT ‐ Transforming Tennessee’s ITS Infrastructure

SLIDE 2

Where We Were

SLIDE 3

Where We Want to Be

 Full Center‐to‐Center connectivity to improve site

resiliency.

 Ability to test emerging ITS technology in a network

that is both state and federally accredited.

 Data at the network edge

 Sensors on vehicles and roadside connected to network

devices capable of running analytics software

 Vehicle Diagnostics from OBD‐II  Temperature/Visibility/Reflectometry  DSRC/5G

SLIDE 4

Where We Want to Be

SLIDE 5

How Do We Get There?

SLIDE 6

How Do We Get There?

SLIDE 7

Where We Are Now

 Installing cellular routers capable of running

applications into HELP trucks and RWIS stations

 Redesigning ITS networks using industry standards

and best practices

 Additional features to TMC sites

 Multicast over MPLS (CCTV control),  IWAN for dynamic routing for mobile routers  Additional internet circuit for redundancy

 Upgrading ITS network hardware

 Field switches

SLIDE 8

Security Model

SLIDE 9

Security Model

SLIDE 10

Vulnerability Management

Attack on Confidentiality Disclosure Attack on Availability Denial of Service Attack on Integrity Dishonesty
