TCP Goes to Hollywood Stephen McQuistin and Colin Perkins University of Glasgow Marwan Fayed University of Stirling Multimedia Applications and HTTP HTTP-based multimedia delivery protocols (e.g., MPEG- DASH, HLS) are popular They allow

slide-1
SLIDE 1

TCP Goes to Hollywood

Stephen McQuistin and Colin Perkins

University of Glasgow

Marwan Fayed

University of Stirling

slide-2
SLIDE 2

Multimedia Applications and HTTP

2

  • HTTP-based multimedia delivery protocols (e.g., MPEG-

DASH, HLS) are popular

  • They allow applications to make use of the existing HTTP

infrastructure (e.g., CDNs)

  • These protocols can be configured for low latency

applications: smaller segment sizes and buffers, for example

  • … but latency is added at the transport layer
slide-3
SLIDE 3

TCP adds latency

3

  • In-order delivery means buffering out-of-order segments,

waiting for the delivery of earlier data

  • Reliability involves detecting that a segment has been lost,

and retransmitting it

  • Both of these mechanisms add latency, making TCP a poor

choice for real-time multimedia applications

slide-4
SLIDE 4

Introducing TCP Hollywood

4

  • Uses TCP as a substrate, to overcome ossification, but

modified to reduce latency

  • Message-oriented to allow application data units to be sent
  • Unordered delivery of messages, given independent utility
  • Partially reliable based on time and dependency information
slide-5
SLIDE 5

Architecture

  • Functionality split between

user-space intermediary layer, and kernel extensions

  • Intermediary layer works
  • ver either standard TCP or

TCP Hollywood

  • Supports partial

deployments

5

Application TCP Hollywood Intermediary Layer Standard TCP or TCP Hollywood

slide-6
SLIDE 6

Unordered message delivery

  • Builds on standard TCP’s byte stream, so need to frame

messages

  • At sender, applications pass messages to intermediary layer, for

encoding (to escape framing bytes), and framing

  • Nagle’s algorithm disabled — it would add latency
  • At receiver, incoming segments delivered as they arrive,

decoded, and passed to application — no latency added by buffering

  • ACKs generated as with standard TCP

6

slide-7
SLIDE 7

Partial reliability

  • Applications pass metadata with messages: deadline and

dependency information

  • Messages might expire — either they won’t arrive on time to be

played out, or they depend on an undelivered message

  • Expired messages aren’t retransmitted — a live message is sent

instead, as an inconsistent retransmission

  • Payload is different, but with the same TCP sequence number

and length

  • Recovers utility lost by retransmitting expired data

7

slide-8
SLIDE 8

TCP Hollywood in action

8

Sender Receiver

time user kernel user kernel

Tframing

Network

Buffers

slide-9
SLIDE 9

TCP Hollywood in action

9

Sender Receiver

time user kernel user kernel

Network

slide-10
SLIDE 10

TCP Hollywood in action

10

Sender Receiver

time user kernel user kernel

Network

slide-11
SLIDE 11

TCP Hollywood in action

11

Sender Receiver

time user kernel user kernel

Network

slide-12
SLIDE 12

TCP Hollywood in action

12

Sender Receiver

time user kernel user kernel

Tplayout reduces gaps in playback due to jitter

Network

slide-13
SLIDE 13

TCP Hollywood in action

13

Sender Receiver

time user kernel user kernel

Network

Playout begins

slide-14
SLIDE 14

TCP Hollywood in action

14

Sender Receiver

time user kernel user kernel

x

Network

Segment lost

slide-15
SLIDE 15

TCP Hollywood in action

15

Sender Receiver

time user kernel user kernel

x

Network

Segment arrives out-of-

  • rder, but is delivered

under TCP Hollywood

slide-16
SLIDE 16

TCP Hollywood in action

16

Sender Receiver

time user kernel user kernel

x

Network

slide-17
SLIDE 17

TCP Hollywood in action

17

Sender Receiver

time user kernel user kernel

x

Trexmit = 4 × Tframing + Trtt

Network

The original message wouldn’t arrive on time to be played out

slide-18
SLIDE 18

TCP Hollywood in action

18

Sender Receiver

time user kernel user kernel

x

TCP Hollywood sends an inconsistent retransmission: a different message, but with the same TCP sequence number

Network

. . . . . . . . .

slide-19
SLIDE 19

TCP Hollywood in action

19

Sender Receiver

time user kernel user kernel

x

Network

. . . . . . . . .

Gap where segment was lost, but no bandwidth wasted in retransmitting it

slide-20
SLIDE 20

TCP Hollywood in action

20

Sender Receiver

time user kernel user kernel

x

Network

. . . . . . . . .

These segments wouldn’t have arrived on time under standard TCP

slide-21
SLIDE 21

Feasibility Region

Tplayout Trtt

21

TCP Hollywood helps when Tplayout is less than Trexmit

slide-22
SLIDE 22

Feasibility Region

Tplayout Trtt

22

Time between a frame arriving at the receiving application, and being played out

slide-23
SLIDE 23

Feasibility Region

Tplayout Trtt

23

Network round-trip time

slide-24
SLIDE 24

Feasibility Region

Tplayout Trtt

24

Plotting the region of feasible values of Tplayout across round-trip times

slide-25
SLIDE 25

Feasibility Region

Tplayout Trtt

Tframing

25

Duration of media in each message

slide-26
SLIDE 26

Feasibility Region

Tplayout Trtt

Tframing

26

Message needs to be decoded before being played out

slide-27
SLIDE 27

Feasibility Region

Tplayout Trtt

Tframing

T m a x

  • T

f r a m i n g

  • T

r t t / 2

27

Application delay bound

slide-28
SLIDE 28

Feasibility Region

Tplayout Trtt

Tframing

Trtt + 4⋅Tframing

T m a x

  • T

f r a m i n g

  • T

r t t / 2

28

Trexmit

slide-29
SLIDE 29

Feasibility Region

Tplayout Trtt

Tframing

Trtt + 4⋅Tframing

T m a x

  • T

f r a m i n g

  • T

r t t / 2

29

Standard TCP retransmissions are useful, and no head-

  • f-line blocking
slide-30
SLIDE 30

Feasibility Region

Tplayout Trtt

Tframing

Trtt + 4⋅Tframing

T m a x

  • T

f r a m i n g

  • T

r t t / 2

30

Standard TCP retransmissions arrive too late to be used, and head-of-line blocking possible

slide-31
SLIDE 31

Feasibility Region

Tplayout Trtt

Tframing

Trtt + 4⋅Tframing

T m a x

  • T

f r a m i n g

  • T

r t t / 2

31

Standard TCP retransmissions arrive too late to be used, and head-of-line blocking possible TCP Hollywood helps: removes head-of-line blocking, and sends inconsistent retransmissions

slide-32
SLIDE 32

Example Application

32

  • IPTV application, using MPEG-DASH configured for low-

latency delivery

  • Tmax = 1 second, within zap time recommendations
  • Tframing determined by number of frames in message
  • Trade-off between size of Tframing, and utility of standard TCP

retransmissions

slide-33
SLIDE 33

Example

33

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 1 frame

Standard TCP retransmissions are useful when a small number of frames are sent — but overheads are higher

slide-34
SLIDE 34

Example

34

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 2 frames

slide-35
SLIDE 35

Example

35

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 3 frames

slide-36
SLIDE 36

Example

36

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 4 frames

slide-37
SLIDE 37

Example

37

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 5 frames

slide-38
SLIDE 38

Example

38

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 6 frames

slide-39
SLIDE 39

Example

39

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 7 frames

The utility of standard TCP retransmissions decreases as Tframing increases (and

  • verheads become

lower)

slide-40
SLIDE 40

Example

40

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 8 frames

slide-41
SLIDE 41

Example

41

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 9 frames

slide-42
SLIDE 42

Example

42

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 10 frames

slide-43
SLIDE 43

Example

43

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 11 frames

slide-44
SLIDE 44

Example

44

0.2 0.4 0.6 0.8 1 0.5 1 1.5 Tplayout (seconds) Trtt (seconds) Tframing = 12 frames

Standard TCP retransmissions are effectively useless; TCP Hollywood recovers this lost utility

slide-45
SLIDE 45

Deployability

  • Inconsistent retransmissions are the only wire-visible

modification vs. standard TCP — same TCP sequence number, different payload

  • Middleboxes performing payload inspection may interpret the

behaviour as an attack — man on the side

  • Experiments between TCP Hollywood server, and 14 UK

clients

  • 8 fixed-line ISPs, 4 cellular operators - all major UK ISPs

45

slide-46
SLIDE 46

TCP Hollywood is deployable

46

Fixed-line Cellular Port 4001 Port 80

  • Tested on two ports to check

if HTTP traffic treated differently

  • inconsistent

retransmission delivered successfully

  • riginal segment

delivered instead

  • Intermediary layer handles

cases where original delivered - performance no worse than standard TCP

slide-47
SLIDE 47

TCP Hollywood

  • Unordered, partially reliable

message-oriented TCP- based transport protocol

  • Eliminates head-of-line

blocking, reducing latency

  • Prevents retransmission of

expired data, increasing utility

  • Deployable across all major

UK ISPs

47

“Hollywood Sign”, Gnaphron - CC BY-SA 2.0 flickr.com/photos/gnaphron/8485145044
