CATHI Marie Curie Initial Training Network Cryogenics, Accelerators and Targets at HIE-ISOLDE Target Unit Design Study SERENA CIMMINO(EN-STI/RBS)* * The research project has been supported by a Marie Curie Early Initial Training Network

slide-1
SLIDE 1

* The research project has been supported by a Marie Curie Early

Initial Training Network Fellowship of the European Community’s Seventh Programme under contract number (PITN-GA-2010- 264330-CATHI)

CATHI

Marie Curie Initial Training Network Cryogenics, Accelerators and Targets at HIE-ISOLDE

SERENA CIMMINO(EN-STI/RBS)*

Target Unit Design Study

slide-2
SLIDE 2

Outline

Target Container Optimization Standard Temperature Calibration Cold Line – Alternative Cooling Solution Study Neutron Converter Design Study Outlook

slide-3
SLIDE 3

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop Target Container Ion Source Feed- Through Cold Line

*ISOLDE Target Unit

Active Cooling

  • Outlet Temperature: 24-25°C
  • Pressure: Approx. 5 bars
  • Flow rate: 180 L/h
  • Inlet Temperature: 15°C

Vacuum (10 -7 mbar) Ohmic Heat (2000 °C)

Systems

slide-4
SLIDE 4

Standard Temperature Calibration

slide-5
SLIDE 5

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

Calibration Chart

*

Preserve the target during operation Avoid excessive stress

5

Icont [A] Vcont [A] Isource [A] Tcont [°C] Tsource [°C] 450 3.01 270 1717 1294 500 3.38 270 1740 1294 550 3.68 270 1850 1294

slide-6
SLIDE 6

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*

Precision

6

Reproducibility Intensive Test Campaign Diagnostic Instrumentation Study Laboratoire national de métrologie et d’essais

Calibration Cell

slide-7
SLIDE 7

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*

7

Measurement Conditions

Pyrometer to use Thermocouple Installation

slide-8
SLIDE 8

Target Container Optimization

slide-9
SLIDE 9

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

9

*Conventional ISOLDE Container

Uniform Thermal Field Release Efficiency Increase Target Container Optimization

slide-10
SLIDE 10

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

10

*New Graphite Heater Prototype

slide-11
SLIDE 11

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

11

*New Graphite Heater Prototype

Ohmic Heat / Containement Thermocouple

slide-12
SLIDE 12

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

12

*Graphite Prototype Study

Graphite Heater Tests

Graphite Heater Tests and Simulations Graphite Heater – Sigratherm Shielding : Tests and Simulations Total Graphite

Graphite Heater Simulations Sigratherm Screen Tests Sigratherm screen Simulations

slide-13
SLIDE 13

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

13

*Parts Collection

slide-14
SLIDE 14

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

14

*Prototype

slide-15
SLIDE 15

Cold Line – Alternative Cooling Solution Study

slide-16
SLIDE 16

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

16

*Water Leaks Investigation

Brazing Electron Bombardment welding It resists up to 500 bar

slide-17
SLIDE 17

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

17

*Alternative Cooling Solutions

750W to dissipate No cooling Water

Load Container heat 1370 [W] Source heat 1250 [W] Radiation 1 enclosure Film Coefficient Convection 3500 W/m2

Thermal Contact Flange Heat Flux Optimization Heat Pipes Integration

slide-18
SLIDE 18

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

18

*Heat Flux Optimization

Thickness Increase Connection Hot-Cold

slide-19
SLIDE 19

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

19

*Heat Pipes

slide-20
SLIDE 20

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

20

*Heat Pipes Integration

Material: Copper nickel plated; Wick Type: Sintered; Fluid: water; Active Length: 100mm; Total Length: 130mm; Diameter: 10mm; Heat Transport 65 W; Thermal Resistance: 0.015 ~ 0.0769.

slide-21
SLIDE 21

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

21

*Feed Through Solution

slide-22
SLIDE 22

Neutron Converter Design Study

slide-23
SLIDE 23

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Neutron Spallation Source

23

Z=50, N = 82 double nuclear shell closure (132Sn) Z=28, N = 50 double nuclear shell closure (78Ni) Energy Deposition

Neutron Converter

Isobaric Contaminant

slide-24
SLIDE 24

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

  • R. Catherall et al., NIMB, 204 (2003) 235.
  • R. Luis et al., European Physics Journal A, 48 (2012) 90

*ISOLDE Conventional Converter

24 Proton Distribution(p/cm2/μC) Neutron Distribution(n/cm2/μC)

slide-25
SLIDE 25

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Simulation Validation

25

  • A. Gottberg et al., to be submitted to NIM B

60 70 80 90 100 110 10

2

10

3

10

4

10

5

10

6

10

7

10

8

10

9

10

10

Zn Prototype In-Target Production Zn Experimental Yield Rb Prototype In-Target Production Rb Experimental Yield

In Target Production Yield (1/µ) Mass Number (A)

slide-26
SLIDE 26

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Production Comparison

26

100 105 110 115 120 125 130 135 140 145 150 155 10

3

10

4

10

5

10

6

10

7

10

8

10

9

10

10

10

11

Cd conventional converter (2µA) Cs conventional converter (2µA) In Target Production Yield [s

  • 1]

Isotope Mass

slide-27
SLIDE 27

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Production Comparison

27

100 105 110 115 120 125 130 135 140 145 150 155 10

3

10

4

10

5

10

6

10

7

10

8

10

9

10

10

10

11

Cd conventional converter (2µA) Cd prototype converter (2µA) Cs conventional converter (2µA) Cs prototype converter (2µA) In Target Production Yield [s-1] Isotope Mass

slide-28
SLIDE 28

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Design Study

28

  • Beam Energy: 500 MeV;
  • Beam Intensity: 100μA;
  • FWHM: 3mm;
  • Particles per second: 6.242

E14;

  • UCx density: 3.63g/cm3
slide-29
SLIDE 29

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Production Comparison

29

105 110 115 120 125 130 135 140 145 150 10

7

10

8

10

9

10

10

10

11

10

12

Cs TRIUMF Standard (10µA) Cd TRIUMF Standard (10µA) In Target Production Yield [s

  • 1]

Isotope Mass

slide-30
SLIDE 30

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Production Comparison

30

105 110 115 120 125 130 135 140 145 150 10

7

10

8

10

9

10

10

10

11

10

12

Cs TRIUMF Standard (10µA) Cs Converter Concept (100µA) Cd TRIUMF Standard (10µA) Cd Converter Concept (100µA) In Target Production Yield [s

  • 1]

Isotope Mass

slide-31
SLIDE 31

S.Cimmino - EN-STI/RBS - Target Unit Design Study – HIE ISOLDE Workshop

*Preliminary Thermal Analysis

31

slide-32
SLIDE 32

Outlook

Calibration Cellule Development Graphyte Protoptype Experimental Tests Design Optimization Test and Simulations Neutron Converter Design Finalization Converter Online Tests

slide-33
SLIDE 33

THANK YOU FOR THE ATTENTION
