[TITLE LE] SharePoint Development for ASP .Net Developers Tarek Bohsali Microsoft

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

AGENDA

• SharePoint Basics
• Packaging and Deployment
• Common Artifacts
• Remote Applications
• Demo
• Visual Web Parts
• List Definitions
• Event Receivers
• Client Object Model

SharePoint

.NET

WHY SHAREPOINT?

Data Storage Presentation Security Clustering API‟s Office Integration Features Data Storage Presentation Security Clustering API‟s Office Integration Features

SHAREPOINT TERMINOLOGY

Farm

Feature

Solution Package

Event Receiver Web Application

Web Part

Site Definition

CAML

Feature Receiver

Central Administration

Declarative Workflow

Client Object Model

Timer Job List Definition

List Instance

Content Database

Content Type

Persisted Object

Site Column

Site Collection

Elevated Privileges

Theme Application Page

Safe Control Scope

ONET Publishing Page

Field Control

Layout Page

Team Site

List View

STSADM

SHAREPOINT ARCHITECTURE

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

SERVER FARMS

• A collection of SharePoint role servers and a

SQL database server

• Servers can perform one or more functions

(web front end, search, application, etc.)

• Farm-level features are managed via Central

Administration

• Custom code can be deployed at the Farm level

and managed centrally

• Solution Packages allow custom code to be

automatically deployed across the farm

Server Farm

Web Front Ends Application Database

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

WEB APPLICATIONS AND SITE COLLECTIONS

• Web application = IIS Virtual Server
• Each web application may be assigned its own app

pool

• Web applications may utilize multiple service

applications

• Site collections reside within web applications
• Site collection functionality derived from underlying

site definition

• Special site collection types include My Sites,

Shared Services Provider, Publishing Web

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

SOLUTION PACKAGES

• Solution Packages are “bundles” of functionality

deployed to the farm or site collection (sandbox)

• May contain one or more Features, assemblies,

pages, controls, and other artifacts

• SharePoint framework handles installation and

configuration of solution items automatically across entire farm

• Automated packaging and deployment in Visual

Studio 2010

WSP

Mapped Folders Assemblies Web Parts

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

SANDBOX SOLUTIONS

• Trusted solutions which run in isolated process
• Load balanced execution
• Uploaded to solution directory in site collection
• Administratively controlled via quotas
• Can be automatically disabled
• Subset of OM functionality
• Ability to use trusted proxy for restricted operations

Full Object Model Subset Object Model MyWebPart.dll Proxy

Runtime

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

FEATURES

• A „Feature‟ is a defined set of functionality

encapsulated within a specific format

• Features are the basic building block of WSS v3

and MOSS development

• Features may be comprised of any combination of

code, including web parts, workflows, and site definitions

• Features may be deployed manually or

automatically on a local or global basis

• Features are heavily dependent on CAML

Solution Feature

XML Receiver Assembly

Project Item

Web Part Template Workflow

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

WEB PARTS

• Web Parts are a specific type of server control that

inherit from System.Web.UI.WebPart

• Web Parts contain discreet functionality that is exposed

to the user in the context of a Web Part Page

• Classic Web Parts do not have an IDE; Visual Web

Parts host ASP.NET User Controls

• Web Parts execute in the context of the current user
• Web Parts may be deployed individually or in

conjunction with other artifacts

Page Form Web Part Controls

Web Part Manager

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

LIST ELEMENTS, TYPES AND VIEWS

• Lists are virtual data repositories for unstructured content
• Fields defined by associated content types and user-defined columns
• Common lists types included OOTB
• Custom list types may be created in UI or code
• List data is stored in the content database associated with the site collection
• Maximum limit for list items is 30M+
• Be aware of performance implications and throttling when storing/retrieving large amounts
• f list data
• Lists have associated views defined in UI or CAML
• Custom field types may be created programmatically

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

EVENT RECEIVERS

• Event Receivers are handler assemblies that respond

to events on specific objects (Webs, Lists, Features, etc.)

• Event receivers override built-in methods:
• Adding/Added
• Updating/Updated
• Activated/Deactivated
• Installing/Uninstalling
• Event Receivers have no UI or user feedback

mechanism

• Event Receivers must run with Full Trust in the GAC

Content Database

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

RELATIONAL DATA

• LINQ to SharePoint
• CAML joins

var q = from announcement in dc.announcements where announcement.Expires >= DateTime.Today select new { announcement.Title, announcement.Body };

<Joins> <Join Type='LEFT ListAlias='List1'> <Eq> <FieldRef Name='Field1' RefType='Id' /> <FieldRef Name='ID' List='List1' /> </Eq> </Join> <Join Type='LEFT' ListAlias='List2'> <Eq> <FieldRef List='List1' Name='SomeFieldName' RefType='Id' /> <FieldRef List='List2' Name=‟ID‟ /> </Eq> </Join> </Joins>

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

WORKFLOW

• SharePoint Workflow inherits and builds upon Windows

Workflow Foundation (WF)

• Simple workflows can be created in SharePoint Designer,

advanced workflows require Visual Studio

• Two types of workflow – Sequential and State Machine
• User interaction provided via InfoPath forms or custom

ASPX pages

• Workflows are tied directly to lists and list items
• Built-in history, tasks, and tracking mechanisms

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

WEB SERVICES

• SharePoint Web Services provide remote access to a number of Object Model functions
• Web services are limited in scope to several primary functional areas, such as Farm, Site, Web,

List, List Items, List Views, etc.

• Web services require a great deal of XML manipulation
• Many web service functions require a solid understanding of CAML
• Custom web services should be deployed as WCF solutions
• Can increase load on Web Front End Servers
• Deploy isolated WFE if used heavily

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

REST

• HTTP-based XML data transfer
• Stateless, cacheable,

uniform

• Conforms to Atom Publishing Protocol
• Direct integration with SharePoint Services

(Excel) and Lists

• Sample queries:
• http://myserver/_vti_bin/listdata.svc
• http://myserver/_vti_bin/Ex

celRest.aspx/Docs/Docum ents/sampleWorkbook.xlsx /model/Ranges('Sheet1!A1 |G5')

[PRES ESEN ENTATI TION N TITLE LE] [PRES ESEN ENTATI TION N TITLE LE]

CLIENT OBJECT MODEL

• Subset of server OM

functionality

• .NET, Silverlight,

JavaScript

• Sync and Async

processing

• Request throttling
• Batch object handling

Content Database

Server Object Model

Client Service

JavaScript Controls JavaScript OM

Proxy

Managed Controls Proxy

Managed OM

Browser Client Server
