Erik Ruiter, Sr. Network Specialist, SURFsara

SURFsara NOC Flash talk

TF-NOC Meeting Cambridge UK, 20-3-2014

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

Services

National supercomputer Cartesius (capability computing) National compute cluster Lisa (capacity computing) Grid compute & storage Gina (middleware services) HPC Cloud IaaS (Do-it-yourself) Hadoop – Data processing (map-reduce algorithm) GPU cluster (Computing on a video card) Collaboratorium Remote collaboration (video wall) Render cluster (Data visualization) Beehub / SURFDrive (Dropbox unlimited)

2

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

Fully redundant topology Core routers: 2x Juniper MX960 Internal firewall cluster: 2x Fortigate 311b + 5x Cisco 3750 External firewall cluster: 2x Fortigate 3040 + 2x Juniper EX4550

Core Network: High level overview

3

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

SURFsara E-infra Network infrastructure

• Connects the HPC

environments in SURFsara

• High capacity (160 Gbps

Between QNodes)

• Used for East - West traffic
• Low latency
• High scalability (upto 786 x

10Gbps)

• Easy scaling
• Single CLI management
• Based on Juniper QFabric

Core Network: E-infra compute and storage network

4

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

NOC Tools: Monitoring

Monitoring:

• Icinga
• Currently monitoring 149 hosts, with 379 services
• Nconf is used for configuration (no manual text editing)
• Cacti
• Syslog daemon
• Syslog-ng -> looking for better solution (logstash)

5

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

NOC Tools: NFSen

Netflow Is enabled on

• ur 2 core routers

Nfsen is used for:

• Intrusion detection
• Using alert triggers when

suspicious traffic patterns are detected. (only a few rules in place at the moment)

• Traffic monitoring for
• ur main uplinks:
• SURFnet (10 Gbps)
• LHCOPN (10 Gbps)

6

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

NOC Tools: Management

Network management:

• All elements reachable on SSH via management infrastructure
• All elements reachable through console port (on centralized console servers)
• All elements Authenticated by TACACS+
• All elements have SNMP v2 READ-ONLY access (limited to single IP address)

Configuration management:

• Rancid + SVNWEB
• Small in-house developed web interface to easily find configs

7

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

NOC Ticketing system

Ticketing system:

• Trac
• Combined issue tracking and wiki system
• Used for software development projects, can interface with SVN, GIT

,etc.

• All departments within SURFsara use Trac, Having their own Trac wiki

and Ticket queue.

• Network access requests also have a separate Trac queue:

Request is first validated by Security team. Then assigned to NOC team.

8

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

NOC Documentation

Documentation

• MediaWiki / Trac
• Stores all project and operational related information
• Currently looking into moving all documentation from MediaWiki to Trac.
• Exporting is difficult (different markup Language, Trac supports less functions)
• Racktables
• Rackspace
• VLANs
• IP space
• Looking into storing cabling information
• Racktables custom added features:
• Daily script that does reverse DNS lookups to determine IP subnet occupation
• Daily script that reads IP information from routers (SNMP) to document ‘routed by’

information.

• Racktables API is used to create lightweight IP / VLAN overview

9

NOC Structure

• Small team
• 5 Network Engineers
• 1 Team Leader
• All engineers work on support, implementation and innovation projects
• Rotated NOC duty days (once per week)
• answering mail
• Small operational requests
• handling incidents
• Only working hours support

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

10

NOC Frontend / Communication

• Customers
• Mainly internal -> system administrators of HPC systems
• No real SLA’s, however providing redundant connectivity is getting more attention
• Internal communications are mainly done through email and Trac tickets
• For external communications we have a mailing list noc@surfsara.nl
• There is no helpdesk phone number

TF-NOC meeting Cambridge 2014 – NOC Flash Talk

11

www.surfsara.nl Erik Ruiter Erik.Ruiter@surfsara.nl
