Promoter Design, Characterization & Consequences

Virginia Commonwealth University Richmond, VA

Craig Alberg Adam Bower Kevin Bussing Richard Crenwelge Maria McClintock Afton Trent

Sunday, November 1, 2009

CONFIDENTIAL

Overview

• Kevin

– Introduction – Project Design

• Maria

–Characterization –Conclusion

Sunday, November 1, 2009

CONFIDENTIAL

Questions

• Can we design novel UP-element sequences to enhance or

attenuate gene expression?

• What is the most streamline and effective method of characterizing

these and other BioBrick parts?

• Can we further characterize existing Registry parts in a way that is

useful to the community?

Sunday, November 1, 2009

CONFIDENTIAL

Libraries of BioBrick Parts

Promoters Backbones UP-elements Sunday, November 1, 2009

CONFIDENTIAL RNA Polymerase

β β' Ϭ α α-CTD

• 35
• 10

UP-element

Transcribed into mRNA

Initiation of Transcription by UP-element and Promoter

Sunday, November 1, 2009

CONFIDENTIAL Naturally occurring UP-element sequences with relative activity listed.

(adapted from Estrem ST, Gaal T, Ross W, Gourse RL, Identification of an UP element consensus sequence for bacterial promoters, PNAS, (1998), 95, 9761-9766 PubMed)

Relative activity in this application is a comparison to the CORE sequence. This is a non-UP- Element sequence

Sunday, November 1, 2009

CONFIDENTIAL

Hypothesis

• The variation of strength of the UP-element is due to different

combinations of nucleotides in the non conserved regions of the UP-element.

• There is some correlation between UP-element strength and the

frequency of bases in the sequence.

• The strength of the UP-element can be tuned by mutating individual

nucleotides of the consensus UP-element sequence using the statistical frequency of occurrence.

Sunday, November 1, 2009

CONFIDENTIAL The frequency of

• ccurrence of each

nucleotide at each position was analyzed for a correlation to UP- element strength.

Sunday, November 1, 2009

CONFIDENTIAL

Variable Regions of the UP-element with Tabulated Base Pair Frequency

Sunday, November 1, 2009

CONFIDENTIAL

The UP-elements Inner Workings

The distal and proximal sequences fall within the consensus region of the UP-element.

Distal Proximal

The alpha carboxy terminal domains of the polymerase bind to these sub sequences.

Sunday, November 1, 2009

CONFIDENTIAL

Nucleotide Mutations to Test Hypothesis

Sunday, November 1, 2009

CONFIDENTIAL

Current Measurement Techniques

Current measurement techniques look only at protein expression, putting the system in a black box.

Sunday, November 1, 2009

CONFIDENTIAL

Removing the Black Box

To fully understand the system we must be able to analyze transcript levels as well as protein levels.

Sunday, November 1, 2009

CONFIDENTIAL

• Methods & Measurements
• Results
• Conclusions
• Future Ideas
• Acknowledgements

Sunday, November 1, 2009

CONFIDENTIAL

Measurements

• Fluorescence by Flow Cytometry
• Measures fluorescence in each individual cell
• Gives cell count
• mRNA Levels by rt-PCR
• Gives the amount of mRNA found in sample
• Eliminates the black box

Sunday, November 1, 2009

CONFIDENTIAL

Minimal Measurement Standard

• Take away the mystery between DNA level and Protein level
• To better characterize transcriptional BioBrick pieces
• Better characterization will aid the development of standard parts
• Make synthetic biology an engineerable process

Sunday, November 1, 2009

CONFIDENTIAL

Methods: Anderson Promoters

• High-copy number plasmid

(pSB1C3)

• Low-copy number plasmid (pSB3K3)
• Additional Characterization and

reproduction of previous characterization

Sunday, November 1, 2009

CONFIDENTIAL Two Scenarios for Testing:

• Constant promoters with variable strength UP-elements
• Constant UP-elements with variable strength promoters

Methods: UP-elements

Sunday, November 1, 2009

CONFIDENTIAL

Anderson Promoter Characterization

Sunday, November 1, 2009

CONFIDENTIAL

Anderson Promoter Characterization

Sunday, November 1, 2009

CONFIDENTIAL

Case 1 - Different UP-elements Same Promoter

Sunday, November 1, 2009

CONFIDENTIAL

Case 2 - Same UP-element with Promoters of Varying Strength

Sunday, November 1, 2009

CONFIDENTIAL

Conclusion

• The UP-element can be too strong in these cases
• Prevents transcription from continuing
• Brings the mRNA production within a specific range
• mRNA levels made it possible for us to come to a more definitive

conclusion

Sunday, November 1, 2009

CONFIDENTIAL

Contributions:

• Addition of a New BioBrick category
• Addition of a New BioBrick
• Additional Characterization of Anderson Promoters
• Proposed Minimal Measurement Standard

Sunday, November 1, 2009

CONFIDENTIAL

Future Work

• Tighter normalization of rt-PCR Data using RecA
• Further develop UP-elements as well-characterized BioBrick parts
• Use previously proposed promoter reference standard (Kelly J.R. et al. 2009)
• Determine the effect of the scarring region on BioBrick UP-elements
• Determine if UP-elements alone can initial transcription
• Look into the delayed expression of the RFP in the E. coli

Sunday, November 1, 2009

CONFIDENTIAL

Acknowledgements

• Dr. Stephen Fong
• Cindy Lovelace
• Dr. John Ryan
• Chris Gowen
• George McArthur IV
• Howard Hughs Medical Institute Summer Scholars Program
• VCU Nucleic Acids Research Facility
• University of Virginia iGEM 2009 Team
