SLIDE 1
The Wrist
Articulations:
The radiocarpal joint The midcarpal joint Motions: Flexion & Extension Radial & Ulnar Deviation
Structure and Function of the Wrist 8 small bones in 2 rows that - - PowerPoint PPT Presentation
Structure and Function of the Wrist 8 small bones in 2 rows that - - PowerPoint PPT Presentation
Structure and Function of the Wrist 8 small bones in 2 rows that articulate with the distal radius, ulna and proximal metacarpals The Wrist Articulations: The radiocarpal joint The midcarpal joint Motions: Flexion &
SLIDE 2
SLIDE 3
The Wrist
Palmar = anterior aspect of the wrist and hand Dorsal = posterior aspect of the wrist and hand
SLIDE 4
Distal Ulna & Radius
Ulna Radius Head Styloid Process Styloid Processes
SLIDE 5
Carpals
Left Hand Palmar Aspect (Anterior Aspect)
SLIDE 6
The Wrist with the Carpals
SLIDE 7
Carpal Tunnel Syndrome
The Transverse Carpal Ligament
SLIDE 8
Arthrology of the Wrist
Radiocarpal Joint
Accepts approximately 80% of
the force that crosses the wrist
Concave radial surface & articular
disc
Convex carpals: scaphoid (7) & lunate
(8)
Midcarpal
SLIDE 9
Intrinsic versus Extrinsic to the Wrist
Intrinsic-
Originating within the area and
inserting in the area
Extrinsic-
Originating outside of the area but
inserting in the area
Triangular fibrocartilage (TFC) Lunotriquetral Ligament (L T Lig) Scaphoid Lunate (S L Lig)
SLIDE 10
Myology of the Wrist
Extensor Carpi Radialis Brevis Origin Lateral epicondyle of the humerus- common extensor tendon Insertion Base of the 3rd metacarpal-dorsal aspect Innervation Radial n. Action Wrist extension, radial deviation “tidbit” What’s in a name? Common origin?
SLIDE 11
Myology of the Wrist
Extensor Carpi Radialis Longus Origin Lateral epicondyle of the humerus, common extensor tendon Insertion Base of the second metacarpal- dorsal aspect Innervation Radial n. Action Wrist extension, radial deviation “tidbit” What’s in a name? Common origin?
SLIDE 12
Myology of the Wrist
Extensor Carpi Ulnaris Origin Lateral epicondyle of the humerus-common extensor tendon and posterior border of the middle 1/3 of the ulna Insertion Base of the 5th metacarpal-dorsal surface Innervation Radial n. Action Wrist extension, ulnar deviation “tidbit” What’s in a name? Common origin?
SLIDE 13
Myology of the Wrist
Flexor Carpi Radialis Origin Medial epicondyle of the humerus- common flexor tendon Insertion Base of the 2nd metacarpal-palmar aspect Innervation Median n. Action Wrist flexion, radial deviation “tidbit” What’s in a name? Common origin?
SLIDE 14
Myology of the Wrist
Flexor Carpi Ulnaris Origin Medial epicondyle of the humerus- common flexor tendon and posterior border of the middle 1/3
- f the ulna
Insertion Base of the 5th metacarpal and pisiform- palmar aspect Innervation Ulnar n. Action Wrist flexion, ulnar deviation “tidbit” What’s in a name? Common origin?
SLIDE 15
Myology of the Wrist
Palmaris Longus Origin Medial epicondyle of the humerus- common flexor tendon Insertion Transverse carpal ligament and the palmar fascia Innervation Median n. Action Wrist flexion “tidbit” Approximately 10% of the population will NOT have this muscle
SLIDE 16
Identify!
Wrist extensors Wrist flexors Radial deviators Ulnar deviators
SLIDE 17
Identify!
Flexor Carpi Ulnaris Palmaris Longus Flexor Carpi Radials
SLIDE 18
