Stratford Coal CCC Meeting Presentation - Company Report & Overview of Activities November 2015 Michael Plain Environment & Community Coordinator Table of Contents 1. Agenda Item 7a (Progress at Mine) 2. Agenda Item 7b

slide-1
SLIDE 1

Stratford Coal CCC Meeting

Michael Plain

Environment & Community Coordinator

November 2015

Presentation - Company Report & Overview of Activities

slide-2
SLIDE 2

Table of Contents

1. Agenda Item 7a (Progress at Mine) 2. Agenda Item 7b (Environmental Projects/Activities) 3. Agenda Item 7c (Environmental monitoring performance) 4. Agenda Item 7d (Community complaints) 5. Agenda Item 7e – (Other matters)

2

slide-3
SLIDE 3

16 October 2015

3

  • 1. Progress at the Mine

Mining 3rd Quarter 2015

  • Waste BCM

0 BCM

  • Coal tonnes

51,520 tonnes

  • Total BCM

42,933 BCM *Reclaim from codam only.

3

slide-4
SLIDE 4

16 October 2015

4

4

  • 2. Environmental Projects/Activities

Management Area Project Status Reporting

  • EPL5161
  • Annual Review
  • NPI & NGERS
  • Independent Environmental

Audit 2014

  • EPL 5161 Annual Return submitted in August 2015.
  • SCM Annual Review completed and submitted in October 2015. Copies provided to

CCC and on Stratford Coal website.

  • 2015 NPI and NGERS reporting has been completed and submitted.
  • IEA Report 2014 revised again with DP&E and awaiting acceptance.

Regulator

  • Site Visits
  • DP&E site visit during September 2015.
  • EPA site visit during September 2015.

Air Quality

  • Pollution Reduction Programs
  • Real-Time Dust Management
  • Coal mine wind erosion exposed area assessment completed and submitted to EPA

as per requirement under Environmental Protection Licence.

  • One alarm received during the quarter, no operations were occurring at the time.

Generally hazy conditions were present due to a southerly change. Flora

  • Weeds Management Program
  • Reviewing proposal received from DPI to trial GPG bio-control on Yancoal land.

Noise

  • Quarterly Noise Assessment
  • Real-Time Noise
  • Continuous improvement

Projects

  • Monitoring completed in June and September 2015. No non-compliances. Report

available on Stratford Coal website. Next scheduled in December.

  • System operational for period 8pm to 8am. Noise profiles continue to be monitored

and generally indicate no exceedence of the performance criteria due to mining/CHPP activities.

  • Several alarms were received during the quarter generally between the hours of

6am-8am. Investigation generally found the main noise contributions to be from birds & insects, traffic and freight trains. Occasionally dull noise from the plant and export train was audible.

  • No changes during the last quarter.
slide-5
SLIDE 5

16 October 2015

5

5

  • 2. Environmental Projects/Activities cont.

Management Area Project Status Water

  • Annual Water Balance
  • Annual water balance for the 2014 calendar year was completed.
  • Routine water sampling continued
  • Irrigation activities continued

Rehabilitation

  • Rehabilitation Monitoring
  • Mining Operations Plan
  • Annual rehabilitation monitoring report completed 2015.
  • Landscape function remains generally high across the Stratford rehabilitation.
  • Stratford MOP approved in June 2015 and the rehabilitation cost estimate was

revised with Department of Resources & Energy. Lighting Biological

  • Macro-invertebrates
  • Macro-invertebrates monitoring completed in September 2015. No evidence of

adverse impacts from mining on in-stream ecology. Bushfire Management

  • Bushfire Management
  • Planning is continuing for hazard reduction burning around ML’s and offset areas

during Spring 2015. Community

  • Community Support Program
  • Meetings
  • Community support payments made including visits to community groups.
  • Review of Community Support Program to be undertaken
  • Attendance at Advance Gloucester meeting planned.
slide-6
SLIDE 6

16 October 2015

6

  • 3. Environmental Monitoring Performance

1.

Rainfall

2.

Surface Water a. Total Suspended Solids b. pH c. Electrical Conductivity

3.

Main Pit Water Quality

4.

Reject Monitoring

5.

Air Quality a. Dust Deposition b. Dust Deposition – Petrographic Analysis c. High Volume Air Sampler d. High Volume Air Sampler-Rolling Average e. Real Time Dust Monitoring (TEOM) – PM2.5/PM 10

6

slide-7
SLIDE 7

16 October 2015

7

Rainfall

7

  • 2015 Year to September: 642.4 mm
  • 2015 Q2 above average, Q3 below average

50 100 150 200 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC

Rainfall (mm)

Month

Stratford Monthly Rainfall

2015 2014 2013 Average 1908-2007

slide-8
SLIDE 8

16 October 2015

8

Surface Water – Total Suspended Solids

8

  • All sites returned generally low TSS results.
  • Gaps indicate no flow

5 10 15 20 25 30 35 40 45 50

Jan-15 Feb-15 Mar-15 Apr-15 May-15 Jun-15 Jul-15 Aug-15 Sep-15

TSS (mg/L)

TSS - Avon River/Avondale Creek 12 Months to Sep 2015

W1 W2 W4 W5 W6

slide-9
SLIDE 9

16 October 2015

9

Surface Water - pH

9

  • All sites generally within ANZECC Guideline range (pH 6.5 - 8.0).
  • Gaps indicate no flow

4 4.5 5 5.5 6 6.5 7 7.5 8 8.5

18-Sep-14 7-Nov-14 27-Dec-14 15-Feb-15 6-Apr-15 26-May-15 15-Jul-15 3-Sep-15 23-Oct-15

pH

pH - Avon River & Avondale Creek 12 Months to September 2015

W1 W2 W4 W5 W6

slide-10
SLIDE 10

16 October 2015

10

Surface Water – Electrical Conductivity

10

  • Generally low EC during high flows (April-May) and high EC during low flows (August-September).
  • Gaps indicate no flow

200 400 600 800 1000 1200 1400

18-Sep-14 7-Nov-14 27-Dec-14 15-Feb-15 6-Apr-15 26-May-15 15-Jul-15 3-Sep-15 23-Oct-15

EC (uS/cm)

EC - Avon River & Avondale Creek 12 Months to September 2015

W1 W2 W4 W5 W6

slide-11
SLIDE 11

16 October 2015

11

Main Pit – Water Quality

11

  • All results within expected range.

5.00 5.50 6.00 6.50 7.00 7.50 8.00 8.50 9.00 9.50 500 1000 1500 2000 2500 3000 3500 4000 4500 18-Sep-14 7-Nov-14 27-Dec-14 15-Feb-15 6-Apr-15 26-May-15 15-Jul-15 3-Sep-15 23-Oct-15

pH EC (uS/cm) , Sulphate (mg/L)

Stratford Main Pit Water Quality 12 months to September 2015

EC (uS/cm) Sulphate (mg/L) pH

slide-12
SLIDE 12

16 October 2015

12

Reject Sampling

12

  • pH within expected range
  • No monitoring in May 2015
  • Reject Beach limed routinely

1 2 3 4 5 6 7 8 9 10

Oct-14 Nov-14 Dec-14 Jan-15 Feb-15 Mar-15 Apr-15 May-15 Jun-15 Jul-15 Aug-15 Sep-15

pH

Stratford Main Pit Reject Beach Monitoring 12 months to Sep 2015

Sample 1 Samples 2 Sample 3 Sample 4 Sample 5 Average

slide-13
SLIDE 13

16 October 2015

13

Air Quality – Dust Deposition

13

  • All sites are well below EPA limit of 4g/m2/month
  • Samples with significant contamination excluded

0.0 1.0 2.0 3.0 4.0 5.0

Oct-14 Nov-14 Dec-14 Jan-15 Feb-15 Mar-15 Apr-15 May-15 Jun-15 Jul-15 Aug-15 Sep-15

Dust (g/m2/month)

Stratford Dust Deposition - Annual Rolling Average 12 Months to September 2015

D5 Straford Village D6 Mine D7 Isaac D8 Bramley D9 Craven D10 Williams D11 Ellis EPA Limit

slide-14
SLIDE 14

16 October 2015

14

Air Quality – Petrographic Analysis

14

Petrographic Analysis Month Sample Number Insoluble Matter Deposition Visual Description - Insoluble Matter (g/m2/month) Jul-15 D5-Petro 0.3 Light 30% Minerals, 10% Coal, 30% Vegetation, 20% Insects,10% Polysaccharide slime D6-Petro 0.5 Light 30% Minerals, 10% Coal, 30% Vegetation, 20% Insects,10% Polysaccharide slime Aug-15 D5-Petro 0.3 Light 60% Minerals, 10% Coal, 20% Vegetation, 10% Insects, 0% Polysaccharide slime D6-Petro 0.4 Light 70% Minerals, 10% Coal, 10% Vegetation, 10% Insects, 0% Polysaccharide slime Sep-15 D5-Petro 0.3 Very Light 60% Minerals, 0% Coal, 30% Vegetation, 10% Insects, 0% Polysaccharide slime D6-Petro 0.4 Very Light 40% Minerals, 0% Coal, 40% Vegetation, 20% Insects, 0% Polysaccharide slime

Visual Description Guide

*Insoluble Matter is viewed under a microscope, major constituents are estimated, examples of each category are as follows: Dirt/minerals: Subhedral to euhedral crystalline grains including fine sand, clay and other fine mineral particulates. Coal: Black sharp angled grains with glossy conchoidal fractures or dull with cellular feature. Insects: Whole insects eg spiders, ants, moths or outer parts of insects including wings, legs and exoskeletons. Polysaccharide Slime: Slimy gelatinous material including decomposed soft body parts of insects and vegetation. Vegetation: Plant debris and algae including trichomes, decomposed organic matter and charred particulates showing characteristic cellular plant structures.

slide-15
SLIDE 15

16 October 2015

15

Air Quality – High Volume Air Sampler

15

  • All sites generally well below NEPM 24hr average level.
  • Spike in October 2014 is due to fires to the west and south of the mine site. Not considered a breach of

licence criteria as the Development consents exclude extraordinary events such as bushfires.

0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0

1-Oct-14 15-Oct-14 29-Oct-14 12-Nov-14 26-Nov-14 10-Dec-14 24-Dec-14 7-Jan-15 21-Jan-15 4-Feb-15 18-Feb-15 4-Mar-15 18-Mar-15 1-Apr-15 15-Apr-15 29-Apr-15 13-May-15 27-May-15 10-Jun-15 24-Jun-15 8-Jul-15 22-Jul-15 5-Aug-15 19-Aug-15 2-Sep-15 16-Sep-15

PM10 (µg/m³)

Stratford HVAS Monitoring - Particulate Matter (PM10) 12 Months to September 2015

Stratford Craven Ellis Clarke NEPM 24 hr Avg

slide-16
SLIDE 16

16 October 2015

16

Air Quality – HVAS Rolling Average

16

  • All site averages well below EPA Limit

5 10 15 20 25 30 35

1-Oct-14 15-Oct-14 29-Oct-14 12-Nov-14 26-Nov-14 10-Dec-14 24-Dec-14 7-Jan-15 21-Jan-15 4-Feb-15 18-Feb-15 4-Mar-15 18-Mar-15 1-Apr-15 15-Apr-15 29-Apr-15 13-May-15 27-May-15 10-Jun-15 24-Jun-15 8-Jul-15 22-Jul-15 5-Aug-15 19-Aug-15 2-Sep-15 16-Sep-15

PM10 (ug/m3)

Stratford HVAS Monitoring (PM10) Annual Rolling Average - 12 Months to September 2015

Stratford Craven Ellis Clarke NEPM 24 hr Avg

slide-17
SLIDE 17

16 October 2015

17

Air Quality – TEOM (Real Time) Monitoring

17

  • Several alarms received from the Real-time dust unit (TEOM) in November 2014 resulting from local bushfires

and hazy conditions in the valley, particularly 1-5 November 2015. No operations and wind direction not consistent with contribution from the mine.

  • Zero/negative values are due to moisture vapour/dew drying on filter creating small negative mass readings.
  • A power outage occurred during December 2014 and May 2015.

10 20 30 40 50 60 70

1/10/2014 1/11/2014 1/12/2014 1/01/2015 1/02/2015 1/03/2015 1/04/2015 1/05/2015 1/06/2015 1/07/2015 1/08/2015 1/09/2015

µg/m³

Date

TEOM (Real Time) Dust Monitoring - Hourly averaged PM2.5/PM10 Oct 2014 - Sep 2015

PM2.5 MC_24 PM10 MC_24

slide-18
SLIDE 18

16 October 2015

18

  • 4. Community Complaints - Summary

18

Stratford Complaint Summary

Period: 1/04/2015 - 30/9/2015 Period: 6 Months Total No. of Complaints: 3 (noise) Total No. of Complainants: 3 Date/Time of Complaint Complainant Location Method of Complaint Nature of Complaint Investigation/Outcome

00:27hrs 4/05/15 Stratford (Approx. 4.2km NNW of CHPP) Community hotline Noise 1) Complainant Stated: 'Humming noise'. 2) CHPP running from 11:30 to approx. 5:00am, dozer was operating on stockpile. Overcast and light southerly wind most of the night. Weak inversion present. 3) Review of audio files confirmed background humming noise from the CHPP however below real-time noise alarm levels. 13:00hrs 29/05/2015 Stratford Approx. 2.5km west of source Direct to phone Noise Phone call received notifying of a 'banging' sound that was different to usual. Environmental representatives attended residence at approximately 1:30pm to determine if could identify the potential noise and source. Contacted CHPP to understand activities. CHPP operating, dozer on stockpile, train unloading on loop prior to phone call from

  • resident. Further investigation and review believes it could be attributed to dozer
  • perator dropping blade on ground to remove/clean build up. Advised CHPP to

communicate this noise source audible off site & adjust operating protocol. 07:41hrs 3/06/2015 Stratford village Community Hotline Noise Noise complaint received, however no other details left and no call back requested. 2) CHPP supervisor investigated operations, the stockpile dozer was pushing off V4. Supervisor listened to real-time noise audio file and commented there seems to be no dominant mine noise. No call back requested. No further change to current controls for

  • perations.
