State of the Union: DWU Capital Improvement Program WEAT North Texas Section November Luncheon Richard Wagner, P.E. Assistant Director Dallas Water Utilities Outline DWU Background Organization One Water Capital

slide-1
SLIDE 1

State of the Union: DWU Capital Improvement Program

WEAT North Texas Section November Luncheon Richard Wagner, P.E. Assistant Director Dallas Water Utilities

slide-2
SLIDE 2

Outline

  • DWU Background
  • Organization
  • “One Water”
  • Capital Improvement Program
  • Water & Wastewater
  • Storm Water & Erosion Control
  • Future Challenges

2

slide-3
SLIDE 3

BACKGROUND

3

slide-4
SLIDE 4

4

Dallas Water Utilities Fact Sheet

  • Founded in 1881
  • Funded from wholesale and retail

water and wastewater revenues (receives no tax dollars)

  • 699 square mile service area
  • Approximately 1,400 employees
  • 2.5 million treated water

customers

  • 1.3 million – Retail (City of Dallas)
  • 1.2 million – Wholesale
  • 300,000 retail customer accounts
  • 23 treated water
  • 3 untreated water
  • 11 wastewater
slide-5
SLIDE 5

Dallas Water System

5

  • 7 reservoirs (6 connected)
  • 4,983 miles of water mains
  • 3 water treatment plants with a

combined capacity of 900 MGD

  • 23 pump stations
  • 9 elevated and 12 ground

storage tanks

  • Value of water assets $3.6

Billion

  • Treated 136 BG of water in

FY17

slide-6
SLIDE 6

Dallas Wastewater System

6

  • 2 wastewater treatment

plants with a combined capacity of 260 MGD

  • 15 wastewater pump

stations

  • 4,040 miles of wastewater

main

  • Value of wastewater assets

$2.4 Billion

  • Treated 59 BG of

wastewater in FY17

slide-7
SLIDE 7

(1955) (1952) (1973) (1964) (1981) (1971) (1990) 7

Dallas’ Regional System Current Water Supply

slide-8
SLIDE 8

Dallas Storm Drainage System

8 Southside WWTP

  • 8 storm water pump

stations with a combined capacity of 2,800 MGD

  • 1,963 miles of storm

sewers

  • 30 miles of levees
  • 39,000 acres of floodplain
slide-9
SLIDE 9

ORGANIZATION

9

slide-10
SLIDE 10

Management Team & Programs

10

Terry Lowery Director

Richard Wagner Assistant Director Business Operations Sally Mills-Wright Assistant Director Water Production Matthew Penk Assistant Director Capital Improvements Zachary Peoples Assistant Director Wastewater Operations Rishi Bhattarai (I)
  • Sr. Program Manager
Pipeline Project Mgmt. 7124 Mark Williams
  • Sr. Program Manager
Capital Services 7123 Regina Stencel
  • Sr. Program Manager
WW Project Mgmt. 7125 Eduardo Valerio
  • Sr. Program Manager
Engineering Services 7122 Marc Cottingame
  • Sr. Program Manager
Water Project Mgmt. 7126 Sunil King
  • Sr. Program Manager
Financial Planning 7221 Denise Wallace
  • Sr. Program Manager
  • Rev. & Bus. Systems
7230 Sandra Wright Manager II Administrative Systems 7020 Peter Stencel
  • Sr. Program Manager
East Side Purification 7330 Chaise Holmgren
  • Sr. Program Manager
Bachman Purification 7270 Steve Golhar
  • Sr. Program Manager
Utility Autom. & Integrat. 7050 Pat Donovan
  • Sr. Program Manager
Pumping 7310 Denis Qualls
  • Sr. Program Manager
Planning 7030 Joel Tillery
  • Sr. Program Manager
Distribution 7420 Nosa Irenumaagho
  • Sr. Program Manager
WWT – Southside 7450 Sophia Harvey (I)
  • Sr. Program Manager
Wastewater Collection 7410 Maurice Akech
  • Sr. Program Manager
PALS 7040 Dan Halter
  • Sr. Program Manager
WWT – Central 7320

Majed Al-Ghafry Assistant City Manager

Trinita Houser
  • Sr. Program Manager
SAP Bus. Consulting 7019 Sheila Delgado Assistant Director Customer Operations 311/WCS Liaison CIS/SAP Liaison Jim Crowley (I)
  • Sr. Program Manager
Elm Fork Purification 7240 Randy Payton Assistant Director Water Delivery Alfonso Morua Manager III Water Quality 7460 Meigan Collins (I) Manager III Watershed-Reservoirs 7338 1874
  • C. Thomas Varghese
  • Sr. Program Manager
Utility Manage. Services 7446 Abidur Khan (I)
  • Sr. Program Manager
StormWat Proj. Mgmt. 4791 Sarah Standifer Assistant Director Stormwater Operations SDM Rick McRay
  • Sr. Program Manager
Dallas Floodway 4792 Gehan Asaad Manager III
  • Dall. Floodway Rec GF
3009
  • Sr. Program Manager
Neighborhood Drainage Systems 1875 Steve Parker
  • Sr. Program Manager
Floodway Regulatory 4790 Veronica Vaughn Manager III Material Services 7360

Original DWU Program New SDM Program DWU/SDM Combined Program

Alex Land
  • Sr. Program Manager
Meter Services 7470 Ade Williams Assistant Director Change Management Advisor Dhruv Pandya Assistant Director Change Management Advisor
slide-11
SLIDE 11

Benefits Of A “One Water” Approach

  • Greater resilience and reliability;
  • Opportunities to optimize regional

infrastructure;

  • Sustainable community development;
  • New regulatory flexibility or opportunity;
  • Economic growth opportunity; and
  • Increased coordination among

agencies/departments.

11

slide-12
SLIDE 12

CAPITAL IMPROVEMENTS

12

slide-13
SLIDE 13

Capital Improvements Organizational Structure

Matt Penk Assistant Director Capital Improvements Abidur Khan (I) Stormwater Project Management Rishi Bhattarai Pipeline Project Management Regina Stencel Wastewater Facilities Project Management Marc Cottingame Water Facilities Project Management Mark Williams Capital Services

slide-14
SLIDE 14
  • FY18-19 CIP budget is $300M (Water & WW)

 Regulatory ($15.0M)

  • EPA Requirements, TCEQ Requirements

 Growth ($52.0M)

  • To meet future customer needs
  • Long Range Plans, Master Plans and Studies

 Rehab and Replacement ($233.0M)

  • Projects requested by Operations programs
  • Areas of concern and excessive maintenance
  • Work with Others (DOT, DART, County, NTTA, PBW)

14

DWU Capital Improvement Program

slide-15
SLIDE 15

15

Aging Infrastructure

Water Lines Sanitary Sewer Lines

Less than 10 years 8% 10‐20 years 12% 20‐30 years 7% 30‐40 years 12% 40‐50 years 13% Greater than 50 years 48% Less than 10 years 9% 10‐20 years 15% 20‐30 years 8% 30‐40 years 14% 40‐50 years 12% Greater than 50 years 42%

slide-16
SLIDE 16

16

5 Year CIP - Expenditures By Fiscal Year (Water & Wastewater)

50 100 150 200 250 300 350 400 450 FY18-19 FY19-20 FY20-21 FY21-22 FY22-23

Pipeline Construction Plan/Maj. Maint./Other Eng/Relo/Develop. WW Facilities Construction Water Facilities Construction

$ Millions

slide-17
SLIDE 17

Programs

  • Main Replacement Program
  • Needs inventory of approximately 526 miles
  • Replacement rate is 0.9% of system (~72 miles/year)
  • Large Valve & Meter Vault Assessments
  • Cathodic Protection Evaluations
  • Leak Detection Program
  • Cleaning & Televising Sewers
  • TCEQ SSO Initiative Program

17

slide-18
SLIDE 18

TWDB Financing

  • May 2017 – 5 year funding commitment from TWDB
  • DWU will receive $66M annually with a loan repayment

period of 30 years

  • Total savings could total $82.5M
  • May 14, 2018 – Loan closed
  • DWSRF & CWSRF
  • Begin awarding contracts for pipeline replacement in FY

18-19

18

slide-19
SLIDE 19

Replace & Rehab Focus = Results

  • Goals and Benefits
  • Efficient use of water supply
  • Recovers production capacity and costs
  • Reduced liability and damage to property
  • Improved environmental quality
  • Unaccounted For Water was 6.62% for FY17 and

6.37% for FY18 with an industry goal of 10%

  • Sanitary sewer overflows per 100 miles of main were

3.1 in FY18 compared to 5.4 in FY 07 (42% reduction)

  • Water main repairs per 100 miles of main - 29 in FY 18

compared to 42 in FY 07 (31% reduction)

19

slide-20
SLIDE 20

Storm Drainage Management CIP

  • Erosion Control – structures threatened by creek or

channel bank erosion

  • Flood Management – projects recommended by master

plans and hydrologic studies; bridge and culverts, channelization, detention, levee flood protection

  • Storm Drainage Relief – storm drainage system

improvements; pump stations

  • Storm Drainage Management – provides funding for

projects thru monthly storm water utility fees.

20

slide-21
SLIDE 21

21

5 Year CIP - Expenditures By Fiscal Year (Stormwater)

5 10 15 20 25 30 35 40 45 FY18-19 FY19-20 FY20-21 FY21-22 FY22-23

Erosion Control Stormwater Drainage Mngmt Storm Drainage Relief Flood Management

$ Millions

slide-22
SLIDE 22

FUTURE CHALLENGES

22

slide-23
SLIDE 23

Top 5 Issues Facing the Water Industry

  • 1. Renewal & replacement (R&R) of aging

infrastructure

  • 2. Financing for capital improvements
  • 3. Public understanding of the value of water

systems and services

  • 4. Long-term water supply availability
  • 5. Public understanding of the value of water

resources

23

Water systems are the cornerstone of modern society, and their continuous renewal and replacement should be made a higher priority and not dealt with in reaction to emergencies resulting from years of neglect and poor decisions by the uninformed.

Kenneth Mercer, Journal AWWA, July 2016

Source: 2018 State of the Water Industry Report, AWWA

slide-24
SLIDE 24

Future Challenges

  • Prioritizing needs and planning to manage impacts
  • Developing sustainable capital program for stormwater
  • Implementing large scale improvements within funding

limitations without impacting service delivery

  • Managing and using data to make replacement and

rehabilitation decisions

  • Aging workforce and staffing needs

24

slide-25
SLIDE 25

25

Capital Planning

slide-26
SLIDE 26

26

Proposed Water Supply Strategies

slide-27
SLIDE 27

27

Social Media

Facebook

  • Kickoff – August 1, 2018
  • Please Follow:

@DallasWaterUtilities

slide-28
SLIDE 28

Questions?

Matt Penk, P.E. Assistant Director – Capital Improvements Dallas Water Utilities matthew.penk@dallascityhall.com Richard Wagner, P.E. Assistant Director – Business Operations Dallas Water Utilities richard.wagner@dallascityhall.com

28
