State of Reliability Report Preview of Key Findings Mark Lauby, Senior Vice President and Chief Reliability Officer Summary of Key Findings Excluding weather, the bulk-power system (BPS) remains within Adequate Level of Reliability (ALR)

SLIDE 1

State of Reliability Report

Preview of Key Findings

Mark Lauby, Senior Vice President and Chief Reliability Officer

SLIDE 2

RELIABILITY | ACCOUNTABILITY 2

Summary of Key Findings

Excluding weather, the bulk-power system (BPS) remains within

Adequate Level of Reliability (ALR) objectives

Weather continues to stress BPS reliability
No load loss due to cyber or physical security events
Average transmission outage severity declined
Significant decrease in transmission forced outages resulting in

loss of load

Stable frequency response trend
Increased risk in protection system misoperations
Continued decline in Energy Emergency Alert Level 3

SLIDE 3

RELIABILITY | ACCOUNTABILITY 3

Weather Stresses BPS Reliability

SLIDE 4

RELIABILITY | ACCOUNTABILITY 4

Continued Decline in Average Transmission Outage Severity

Misoperation Failed AC Substation Equipment Power System Condition Lightning Failed AC Circuit Equipment Weather, Excluding Lightning

0.1 0.11 0.12 0.13 0.14 0.15 0.16 0.17 0.18 0.19 0.2

0.1
0.08
0.06
0.04
0.02

0.02 0.04 0.06 0.08 0.1

Expected Transmission Outage Severity Correlation with Transmission Outage Severity

SLIDE 5

RELIABILITY | ACCOUNTABILITY 5

Significant Decrease in Forced Transmission Outages Resulting in Loss of Load

SLIDE 6

RELIABILITY | ACCOUNTABILITY 6

Frequency Response Trend Stable

Eastern Interconnection Western Interconnection ERCOT Interconnection Québec Interconnection

SLIDE 7

RELIABILITY | ACCOUNTABILITY 7

No Load Loss Due To Physical or Cyber Security Events

BES Security Metric 1: Reportable Cyber Security Incidents
3 Reportable Cyber Security Incidents in 2014
None resulted in loss of load
BES Security Metric 2: Reportable Physical Security Events
47 reports of physical security threat events
9 caused physical damage or destruction
None resulted in loss of load

SLIDE 8

RELIABILITY | ACCOUNTABILITY 8

Use of EEA Level 3 Continues to Decline

5 10 15 20 25 30 35 40 45 2006 2007 2008 2009 2010 2011 2012 2013 2014

Number of EEA3 Events Year

EEA3 Events NERC-Wide

5 10 15 20 25 30 35 40 2006 2007 2008 2009 2010 2011 2012 2013 2014

Number of EEA3 Events

EEA3 Events by Region

FRCC MRO NPCC RF SERC SPP TRE WECC

Steady decline NERC-wide since 2011 Overall regional rate declining

SLIDE 9

RELIABILITY | ACCOUNTABILITY 9
