VIRSHKE research&development Your printing numbers are too small? Tired of making cliches? The client asks for partial varnishing? Printing with white colour? Then Foil Print 106 is designed specially for you! Stamping without cliche
research&development
Your printing numbers are too small? Tired of making cliches? The client asks for partial varnishing? Printing with white colour? Then Foil Print 106 is designed specially for you!
virshke.com
Foil Print 106 is a thermic transfering printer that mostly can replace a hot stamping press. Not completely but it can ease a lot of operations and make small and peace printing profitable. It is explained by that Foil Print 106 doesn`t demand an expensive cliché, it is like an ordinary printer makes stamping from the computer directly – you just prepare the image and press the button “Print”. The image is produced by the special thermic head making a local heating. In the process of printing the glue included in the band melts and sticks to the material with the foil. As a result you get a nice and resistant image. The high resolution – 600 dpi- allows to stamp fine elements and even photos. The printer can be used with such materials as paper, laser printers prints, plastic, natural and artificial leather, films, acryl, silk, laminated paper and many
You can see the presentation of Foil Print 106 in You Tube
(with English subtitles)
Resolutin Maximal printing size with 57 mm head Maximal printing size with 106 mm head Maximal height of material OS Interface Power Weight 600dpi 300x57 мм 300x106 мм 48 мм Windows XP, 7, 8 (32, 64 бит) USB 2.0 220 В 23 кг
Foil Print with printhead and cartridge 57 or 106 mm Foil ribbon (silver) Power cable 220 V Cable USB Manual (in English) Sheet of testing results Package 1 piece 1 roll 1 piece 1 piece 1 piece 1 piece 1 piece
To facilitate to you the choice, we suggest to look at the comparative table of characteristics of the folgirators presented at the market. Models were selected so that to have the closest key parameters.
Foil Print 106 Resolution Maximal printing width Maximal length System of simplification of positioning Country of origin Foil Print 106 600 dpi 106 mm 300 (500*) mm Laser Russia ADL3050A 300 dpi 57 mm 150 mm No China Foil Xpress 300 dpi 57 mm 150 mm No USA
* Maximal length 500 mm is possible in special modification.
The cartridge with 57 mm head is installed Loosen the locking nut Slide aside and remove the cartridge Take the cartridge with 106 mm head Insert it into the printer Tighten the locking nut. Ready!
The peculiarity of Foil Print 106 is ability to use the printing heads of two types: 57 and 106 mm wide. The head is installed in a special cartridge that can be replaced in depend on the task. The procedure of replacement is shown below Also you can see it in You Tube
For convenience of positioning, at the edges of a printhead are laser indexes. They show the place from where the print will begin that simplifies work of the
Printing head Foil Print 106 is a ceramic plate with a band of thermic
the heating within a pixel. The service life of the printing head guaranteed by the producer is not less 50 km, in fact in can reach 150 km.
Heating element Resisting coating Electrodes Ceramic base Aluminum radiator Printing line 0,06 mm
Foil Print 106 can stamp with foil on different even surfaces. It can decorate post cards, business cards, organizers, folders, invitations, souvenirs and many other things.
Besides foil Foil Print 106 provides special bands: white and varnish for partial
Besides printing Foil Print 106 is used for nail decorating. For this purpose the special decal paper with varnish coating is used, Foil Print 106 prints on it easily. After printing the image is damped with water and transferred onto the nails and other
Foil Print 106 is designed and being produced by the company “Virshke” Ltd, located in Nizhnevartovsk, Russia. The company has a great experience of designing foil-printing machines. Foil Print 106 is the third generation of printers including features of the previous ones. “Virshke” Ltd is a partner of supplies producers from Japan and Germany. It has its own modern producing equipment that allows keep to the high level of quality. Permanent quality control and inner control of production provides the production of printers of high quality and at competing prices.
research&development
Company name Address: Tel.: ”Virshke” LLC +7 982 536 05 69 Russia, Nizhnevartovsk, Neftanikov 74, office 1002. e-Mail: info@virshke.ru www: virshke.com
