Rule Development Workshop December 20, 2018

Minimum Flows for the

• St. Marks River Rise

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

What is an MFL?

Limit at which further withdrawals will cause significant harm to the water resources or ecology of the area.

Purpose:

To protect water resources and associated

• ecology. Provides information to support

water supply planning and water use permitting evaluations.

2

Statutory Requirements s.373.042, F.S.

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

3

Priority Waterbodies

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

4

• St. Marks River Rise Study Area

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

• St. Marks River Rise

5

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

237 cfs 689 cfs Spring Flow 452 cfs

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Enhanced Data Collection

• More than 60 sites
• Hydrology

– Aquifer levels – River stage and flow – Spring flow

• Water Quality

– Salinity – Temperature

6

Insert picture of person collecting data

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Enhanced Data Collection

• Elevation Data

– River channel – Floodplain

• Ecological Data

– Vegetation Communities – Instream Habitat

7

Elevation Data

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Baseline Time Series

• No measurable impacts from withdrawals
• Baseline is period of record:

– (October 1, 1956 – November 27, 2017)

8 250 500 750 1000 1250 1500 1750 2000 1/1/1956 1/1/1961 1/1/1966 1/1/1971 1/1/1976 1/1/1981 1/1/1986 1/1/1991 1/1/1996 1/1/2001 1/1/2006 1/1/2011 1/1/2016 Flow (cfs) Date

• St. Marks Rise Spring Discharge

500 1,000 1,500 2,000 0% 25% 50% 75% 100% River Rise spring Discharge (cfs) Exceedance Frequency

Baseline Spring Flow (cfs)

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Florida Administrative Code (F.A.C.) Requirements

Chapter 62-40.473(1), F.A.C.

• 1. Natural seasonal fluctuations in water flows or levels,
• 2. Non-consumptive uses, and
• 3. Environmental values associated with coastal, estuarine,

riverine, spring, aquatic, and wetland ecology, including:

9

• 1. Natural seasonal fluctuations in water flows or levels,
• 2. Non-consumptive uses, and
• 3. Environmental values associated with coastal, estuarine,

riverine, spring, aquatic, and wetland ecology, including:

(a) Recreation in and on the water (b) Fish and wildlife habitats and the passage of fish (c) Estuarine resources (d) Transfer of detrital material (e) Maintenance of freshwater storage and supply (f) Aesthetic and scenic attributes (g) Filtration and absorption of nutrients and other pollutants; (h) Sediment loads (i) Water quality (j) Navigation

“Water Resource Values” (WRVs)

}

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Water Resource Value Metrics

10

• Recreation

– Safe Power Boat Passage (2 ft x 30 ft) – Safe Canoe/Kayak Passage (1.5 ft Depth)

• Fish and Wildlife Habitats

– Fish Passage (0.6 ft Depth) – Manatee Passage (3.8 ft x 3.8 ft) – Floodplain Wetland Inundation – Instream Woody Habitat Inundation

• Estuarine Resources

– Low Salinity Habitats (Volume, Surface Area, Shoreline Length)

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Hydrology Models

11

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

• Models used to quantify

changes in spring flow and WRV metrics

– River hydraulic model – spring flow effects on river stage and flow – Estuarine Model – spring flow effects on salinity

• Significant harm threshold:

15% reduction in metric

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Results

12

Spring Flow Range Limiting Metrics Allowable Flow Reduction (cfs) Low (<400 cfs) Dead Woody Debris Habitat 67 Medium (400 - 600 cfs) Live Roots Habitat 42 Hardwood Hammock 33 Cypress Hardwood Swamp 34 Boat Passage 40 Manatee Passage 50 High (>600 cfs) Ironwood Hammock 50 Ash Swamp 101

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Results

13

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Minimum Flow

14

• Most limiting metric protective of full range of flows
• Hardwood Hammock inundation: 33 cfs reduction when

spring flow is 447 cfs

• Applied to long-term average daily spring flow (452 cfs)

14

Long-term Daily Average Minimum Spring Flow (cfs) Allowable Flow Reduction (cfs) Percent Allowable Flow Reduction (%) 419 33 7.3%

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Peer Review

• Independent experts in

Hydrology, Ecology, and Environmental Flows

• Scope of Peer Review

– Supporting Data and Information – Technical assumptions – Procedures and Analyses

15

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Peer Review Comments

16

“…The Panel supports and endorses the District’s approach to determining the minimum flow and final selection of the minimum flow for the St. Marks River Rise and Spring Run.”

Key Revisions

• Improved riverine model and provided additional documentation
• Removed boat launching metric
• Reduced boat passage depth

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Evaluation of Need for Prevention

• r Recovery Strategy

17

• St. Marks River Rise currently

meets the proposed minimum flow

– No recovery strategy needed

• Effects of projected withdrawals

through 2040 do not exceed available spring flow of 33 cfs

– No prevention strategy needed

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

MFL Assessment

18

• MFL status anticipated to be assessed every 5 years
• Difference between 30-year average flow and the baseline flow

compared to the available water of 33 cfs

• MFL anticipated to be reevaluated in 10 years

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Rulemaking Schedule

19

November 1, 2018 Notice of Rule Development was published December 20, 2018 Rule Development public workshop followed by 14 day public comment period February 28, 2019 Anticipated Board review and approval of draft rule language April 1, 2019 Deadline to publish Notice of Proposed Rule End of May, Anticipated effective date of Proposed Rule beginning of June, 2019

NORTHWEST FLORIDA WATER MANAGEMENT DISTRICT

Thank You

20

Insert background photo
