Speckle Imaging with IMAGIN A M ulti A perture Imaging Simulation Arun Surya A good idea is worth more than a large telescope Contents a. Atmosphere, Phase and Speckles b. Speckle Interferometry and Speckle masking c. IMAGIN :

slide-1
SLIDE 1

Speckle Imaging with IMAGIN

A Multi Aperture Imaging Simulation

“A good idea is worth more than a large telescope “

Arun Surya

slide-2
SLIDE 2

Contents

  • a. Atmosphere, Phase and Speckles
  • b. Speckle Interferometry and Speckle

masking

  • c. IMAGIN : Simulations of Speckle imaging

with Multi Apertures

  • d. Hypertelescopes
  • e. Reconstruction Results
  • f. Conclusion
slide-3
SLIDE 3

Two Approaches of Dealing with Turbulence Online Approach Offline Approach Adaptive Optics Speckle Techniques

slide-4
SLIDE 4

Imaging Equation

Transfer Function Cutoff D/λ Spatial Frequency 1 MTF Cutoff r0/λ

slide-5
SLIDE 5

a

Ideal P.S.F

Long exposure Short Exposure Atmospheric Turbulence Cutoff Frequency limited by D Cutoff Frequency limited by r0 r0

slide-6
SLIDE 6
  • A.Labeyrie 1970 : Speckle Interferometry

Attainment of Diffraction Limited resolution in Large Telescopes by Fourier Analyzing Speckle patterns in Star Images, A&A

Object Autocorrelation Power Spectrum Object Fourier Amplitude Object Fourier Phase

Speckle Interferometry Transfer Function : >0 up to diffraction limit

slide-7
SLIDE 7

The curious case of phase dominance ..

  • Alan V Oppenheim

1981 “Importence of phase in signals”

  • Many of the important

features of the signal are preserved if only phase is retained

  • Under variety of

conditions phase information is alone sufficient to reconstruct the signal

slide-8
SLIDE 8
  • G.Weigelt 1977 : Speckle Masking

Modified astronomical speckle interferometry 'speckle masking' ,Optics Communications

Image Triple Correlation Image Bispectrum Object Fourier Amplitude Object Fourier Phase

slide-9
SLIDE 9
  • G.Weigelt 1977 : Speckle Masking

Modified astronomical speckle interferometry 'speckle masking' ,Optics Communications

Image Triple Correlation Image Bispectrum Object Fourier Amplitude Object Fourier Phase

slide-10
SLIDE 10

Bispectrum of 1D Signals

slide-11
SLIDE 11
  • G.Weigelt

1977 : Speckle Masking

Modified astronomical speckle interferometry 'speckle masking' ,Optics Communications

Image Triple Correlation Image Bispectrum Object Fourier Amplitude Object Fourier Phase

slide-12
SLIDE 12
  • G.Weigelt 1977 : Speckle Masking

Modified astronomical speckle interferometry 'speckle masking' ,Optics Communications

Image Triple Correlation Image Bispectrum Object Fourier Amplitude Object Fourier Phase

slide-13
SLIDE 13

Object Phase from Bispectrum

Object Bispectrum Phase Object phase

Recursion Formulae

slide-14
SLIDE 14

“The Code”

1. Get the Short exposure frames 2. Do frame by frame fourier transform 3. Get Object Magnitude by Speckle Interferometry 4. Do frame by frame fourier transform 5. Compute average Bispectrum 6. Use Recursion Formulae to retrieve phase 7. Averaging phasor over many iterations 8. Combining Phase and Amplitude to get signal back

slide-15
SLIDE 15

Specs and Issues

  • Written in IDL(Interactive Data Language)
  • Bispectrum for a 2D signal is 4D
  • Memmory issues
  • Currently Code can process 200x200 pixel data
  • Code is computationaly very expensive
  • 8hrs for processing 500 frames of 200x200 in

Core 2 duo ,4 GB system Computationally efficient Radon Transform versions gave poor reconstruction

slide-16
SLIDE 16

Phase 2

slide-17
SLIDE 17

Speckle Imaging Simulation Package:

IMAGIN

a) Single and Multi Aperture Telescopes b) Fizeau Type Imaging Inteferometers c) Hypertelescopes Written in MATLAB

  • Any Mirror Dimensions , Baselines
  • Night time rotation
  • Photon Limited Interferograms
  • Different Plate Scales, wavelength
slide-18
SLIDE 18

Single Aperture Telescopes

R0 =5 cm D=1m R0 =30 cm D=1m

slide-19
SLIDE 19

Multi Aperture Systems

Based on Simple Algorithm using the correlation function

slide-20
SLIDE 20

Fizeau Imaging Interferometers

ψ1 ψ2 ψ4 ψ5 ψ3 ψ6 ψ4 ψ7 ψ8 ψ9 ψ10

slide-21
SLIDE 21

mirror

Fizeau Mode Imaging

  • 20 mirror aperture
  • Randomly arranged over 10 m disc
  • Individual aperture size of 1 m

Largest Baseline Smallest Baseline

slide-22
SLIDE 22

Fizeau Mode Imaging

slide-23
SLIDE 23

. A.Labeyrie 1996

  • Fizeau Interferometer
  • +
  • Pupil Densification
  • =
  • HyperTelescope

Resolved imaging of extra-solar planets with future 10-100km optical interferometric arrays.

slide-24
SLIDE 24

Hypertelescope

Fizeau Hypertelescope

slide-25
SLIDE 25

Aperture Configuration

20 mirror Aperture 50 mirror Aperture After Densification Aperture Rotation Through Night ..

slide-26
SLIDE 26

Parameters

slide-27
SLIDE 27

Objects

Binary Star Six Star Group Extended Object

slide-28
SLIDE 28

Binary Star Speckle

slide-29
SLIDE 29

Binary Star Six Star Group Extended Object With Photon Noise

slide-30
SLIDE 30

Speckle Interferometry : Binary Star

20 Mirror Aperture

Snapshot

50 Mirror Aperture

Snapshot

20 Mirror Aperture

With Aperture rotation through night

50 Mirror Aperture

With Aperture rotation through night

Autocorrelations

slide-31
SLIDE 31

Six Star Group

50 Mirror Aperture (With Rotation) 50 Mirror Aperture 20 Mirror Aperture (With Rotation) 20 Mirror Aperture

15 000 photon events !

slide-32
SLIDE 32

Extended Object

Object Speckle Recovered

slide-33
SLIDE 33

20 Aperture 20 Aperture (With rotation) 50 Aperture 50 Aperture (With Rotation) Object

slide-34
SLIDE 34

Conclusions

  • Speckle Masking Code
  • Multi Aperture Imaging Simulation
  • Speckle Imaging with Hypertelescopes
  • Real Data
  • Photometric Accuracy and Strehl Ratio

Measurement

slide-35
SLIDE 35

Thank you

Reference

A.Labeyrie 2006 “Optical Stellar Interferometry” Weigelt, Lohman 1983 “Speckle Masking in astronomy” Swapan K Saha 2007 “Diffraction Limited Imaging with Large and Moderate telescopes “ Alan V Openheim 1981“Importance of Phase in signals” Lohmann ,Wirnitzer 1985 “Triple Correlations”

A good idea is worth more than a large telescope : R.O.Redman
