1

BusinessLink

Application Intercept Adapter

Jack Digiacomo @ tandsoft.com TANDsoft

BusinessLink Overview More Info Other TANDsoft product offerings

2

BusinessLink

BusinessLink Adapters extend existing Application capabilities to ALL HP NonStop™ applications, with NO source code changes. BusinessLink intercepts application input-output data or transactions and invokes any BusinessLink Adapter, enabling;

 Application Monitoring and Thresholds.  Automatic TMF AUDITing.  File and Transaction Replication to

Tandem or MQSeries platforms.

 FTP host file transfer statistics.  Seamless Integration with ASAP, PROGNOSIS,

Measure, TranSTAT and MQSeries. BusinessLink supports Custom and major applications, such as Base24, LastWord, ATLAS and HLR.

AutoASAP AutoSTAT

Automatic

TMF MQSeries

Alarm

Replicate

FileStat Trace

Custom Adaptor…

Customer, Tandem

• r Major

Application

BusinessLink Library BusinessLink Adapters

3

BusinessLink

I DL Source

Text Process

I DL Compiler

FTP Stats Log

Output File

AutoASAP AutoSTAT

Automatic TMF

MQSeries Alarm Replicate FileStat Trace Custom Adaptor…

ASAP Customer, Tandem

• r Major

Application

BusinessLink Library

Process

Transtat PROGNOSI S Measure TMF

Audited File EMS Collector

Text File Disk file Text file

BusinessLink Adaptors

Other Platform

BusinessLink provides ALL HP NonStop™ applications with extensions to any BusinessLink Adaptor, with NO application source code changes.

4

AutoASAP - CustApp

Seamless Integration with ASAP. Monitors Customer & Third party Application Transactions

and Business metrics.

Interception-based or Log-based. Application Transaction Statistics include;

 Multiple Transaction Types.  TPS, Response Time, Success-Timeout-Declined Percent  Application - Transaction State.

Monitors Application Transaction Service Level Objectives. Logs EMS events when Transaction and Business metrics

are not met.

Presented as ASAP Custom Application/Transaction View. No Application Source Code Changes needed. Supports Custom Applications and Transactions, like Base24.

5

AutoASAP – CustApp

6

AutoASAP – Base24App

7

AutoASAP – Base24App Configuration

 Define Application Transactions for AutoASAP to Monitor.

 Use AutoASAP Intercept Definition Language(IDL).

 ACTION MTDD TYPE STAT-ASAP



DOMAIN Base24App\PTLF\MTDD

 END-ACTION  IF tx^type = "MTDD" THEN 

IF _ptlf_approve(ptlf.auth.resp^cde) THEN



MTDD COUNTER 0 ADD $$VALUE(1)



ELSE …

 Compile IDL CustApp Source File, creating CustApp Library.

 RUN IDL / in idlcustp, out $s.#idl.custp / alibcup

 Run Application with CustApp Library.

 RUN Base24DH / LIB alibcup, name $tcup1 /

8

AutoASAP - Business View

• Monitors Customer & Third party Application Availability and

Performance

Monitors Application specific Entities(Base24 Process,Line). Monitors Application Transactions and Business metrics. Monitors Application & Transaction Service Level Objectives. Logs EMS events when SLOs are not met. Presented as a single consolidated ASAP Business View. No Application Source Code Changes needed. Supports Customer & Third-party Applications. Supports Base24 Application.

9

AutoASAP - Business View

10

Extends PROGNOSIS to all Applications

BusinessLink-AutoSTAT Provides ALL HP NonStop™ applications integration into PROGNOSIS, with NO application source code changes. BusinessLink-AutoSTAT intercepts application input-

• utput operations and uses

PROGNOSIS to record and monitor application quality attributes, transaction statistics and service level objectives.

BusinessLink-AutoSTAT

11

BusinessLink-AutoSTAT for PROGNOSIS

12

BusinessLink – More Info

 BusinessLink Resources

– Software and Manuals available with FREE Software Evaluation – InterNet http://www.tandsoft.com/

 BusinessLink Presentation

– A copy of this presentation is available at;

–http://www.tandsoft.com/businesslink.ppt

13

TANDsoft – HP Nonstop products

 FileSync – Business Continuity.

 Automatically synchronizes Guardian and OSS Files, Tables and Applications

between HP NonStop Servers.

 OPTA2000 – System Clock and Time Zone Simulator.

 Run multiple applications, each with their own simulated System Clock or Time Zone,

• n a single Disaster Recovery, Production or Test system, with NO source changes

to the application. Join other NonStop users who are saving money by consolidating and running multiple Time Zone sensitive applications on a single HP Nonstop Server.

 AutoASAP – Extends ASAP Availability & Performance monitoring.

 Supports Servernet, Communication Lines, TCP/IP, Guardian/OSS File/Process

Measure, Pathway, SQL, Application Transaction & Business State monitoring(interception).

14

TANDsoft – HP Nonstop products

 ASAP Reporter – Extends ASAP Historical Analysis.

 Provides ASAP and SQL (Hourly, Daily, Monthly and Yearly) availability and

performance aggregate statistics for all ASAP and AutoASAP entities.

 BusinessLink – Extends existing Application functionality.

 Using Intercept technology, BusinessLink Plug-In capabilities can be added to

existing applications, with NO application source code changes.

 Extends Application Business State monitoring and alerting to;

 ASAP, Measure, PROGNOSIS and SQL.



Adds Automatic-TMF.

Generates TMF transactions for your UN-Audited files.

 OPTA – Online Process Tracer & Analyzer  With NO application changes, Trace TNS and Native System procedure calls.

15

Source Node

FileSync

Synchronizes Applications and Files between HP Nonstop Servers

SQL Enscribe

Destination Nodes

\ PROD \ PROD2 \ PROD1

Expand TCP/IP for System Upgrades Replication for Business Continuity and Software Distribution

FileSync

Duplicate SQL Enscribe OSS Database

Application Environment

Duplicate

New System Node

Application Environment

SQL Enscribe \ PROD

FileSync

OSS Database

Application Environment

16

OPTA2000 Clock and Time Zone Simulator

OPTA2000 is a Tandem Clock & Time Zone Simulator, not just for Y2K. OPTA2000 Supports >>>

 Multiple simulated System Clock &

Time Zone values for multiple Apps & environments (Test, Dev and QC).

 Multiple DR environments running in

multiple Time Zones can be combined onto one system running OPTA2000 Time Zone simulation.

 All program languages and types,

Native, TNS and Nonstop SQL, with NO source code changes. With OPTA2000, programs "think" it’s the Clock or Time Zone value that you specified.

18

AutoASAP

19

ASAP Reporter - CPU

20

OPTA Online Process Tracer & Analyzer

OPTA is a Program Tracing utility for NSK applications.

 OPTA intercepts and logs Calls to the NSK System Procs.  Procedure information captured by OPTA includes;

 Parameter contents, Condition codes, Return values, File Errors,

$RECEIVE / TMF info, etc. ).

 No application source code changes are required.  Ideal for finding Application DeadLock and Timing related

problems.

 System and Application IPC messages are also intercepted.  Supports all TNS & Native programming languages.

21

For additional information or a FREE software evaluation, please visit;

www.tandsoft.com

Thank You very much
