12 th Annual SECA Workshop: July 28, 2011 Invent, Develop, Deliver. Validation of Novel Planar Cell Design for Megawatt-Scale SOFC Power Systems M.J. Day, Principal Investigator 12 th Annual SECA Workshop Pittsburgh, PA July 28, 2011 12 th

slide-1
SLIDE 1

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Validation of Novel Planar Cell Design for Megawatt-Scale SOFC Power Systems

M.J. Day, Principal Investigator 12th Annual SECA Workshop Pittsburgh, PA July 28, 2011

slide-2
SLIDE 2

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

  • Achieved ISO 9001:2008 certification for all

products and processes within NexTech

  • Launched hydrogen safety sensor product(s), and

recently passed UL/ATEX certification tests

  • Launched interconnect coating product
  • Continued progress made on SOFC stack

technology development

NexTech News

slide-3
SLIDE 3

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Outline

  • Project Details, Objectives, Conclusions
  • Introduction to FlexCell
  • Status of NexTech’s SOFC Stack Technology
  • Results of SECA Project
  • Future Work
slide-4
SLIDE 4

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Project Details, Objectives, and Conclusions

slide-5
SLIDE 5

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

U.S. Department of Energy (SECA)

  • DOE Contract Number: DE-NT0004113
  • Project Monitor: Briggs White
  • Phase I: 1-Oct-08 to 31-Mar-10
  • Phase II: 1-Apr-10 to 30-Sep-11

State of Ohio (Third Frontier Program)

  • Cell Manufacturing for 100+ kW SOFC Power Generation Systems
  • ODOD Contract Number: TECH 08-057

NexTech’s Team

  • Principal Investigator: Mick Day
  • NexTech Contributors: Scott Swartz, Lora Thrun, Kellie Chenault
  • Subcontractor: Ohio State University (Professor Mark Walter)

Project Details

slide-6
SLIDE 6

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Overall Project Goal

  • Validate performance, robustness, cost and scalability of

NexTech’s FlexCell planar cell design for coal-based SOFC power systems

Phase I Objectives

  • Demonstrate that high performance can be achieved in

FlexCells made with YSZ as the electrolyte material

  • Demonstrate that FlexCells have sufficient mechanical

robustness for SOFC applications

  • Demonstrate potential of achieving cell manufacturing cost
  • f less than $50/kW

Project Objectives

slide-7
SLIDE 7

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

  • Fabrication methods for ScSZ-based FlexCells were

successfully transferred to YSZ-based FlexCells.

  • YSZ-based FlexCells successfully scaled to 500-cm2

area.

  • High performance in YSZ-based FlexCells has been

demonstrated at the single-cell (and stack) level.

  • Finite element analysis is an effective design tool

for mechanically robust FlexCell architectures.

  • Cell manufacturing cost was estimated to be

$51/kW at 250 MW/year scale

Conclusions

slide-8
SLIDE 8

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Introduction to the FlexCell

slide-9
SLIDE 9

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Attributes

  • Thin-electrolyte for high

performance

  • Small repeat units for high

power density

  • Dense perimeter for ease
  • f sealing
  • Thin electrodes to

facilitate gas diffusion

  • Thin anode for redox

cycling tolerance

  • Electrode material flexibility

Introduction to the FlexCell

slide-10
SLIDE 10

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

High power density and high fuel utilization Internal Methane Reforming

0.0 0.2 0.4 0.6 0.8 0.0 0.3 0.6 0.9 1.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 Power Density (W/cm2) Cell Potential (volts) Current Density (A/cm2)

0.725 W/cm2 (0.701 V @ 1.036 A/cm2) 81% fuel utilization

T = 800ºC (H2/N2)

Performance Attributes

0.0 0.1 0.2 0.3 0.4 0.0 0.2 0.4 0.6 0.8 1.0 1.2 0.0 0.1 0.2 0.3 0.4 0.5 0.6

Power Density (W/cm2) Cell Potential (volts) Current Density (A/cm2)

0.60 V @ 0.53 A/cm2 UF = 95% 60% Efficiency A = 81 cm2, T = 800ºC, H2O/CH4 = 3/1

slide-11
SLIDE 11

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

0.0 0.2 0.4 0.6 0.8 1.0 3,000 6,000 9,000 12,000 15,000

Potential (volts) Time (hours)

T = 750ºC, J = 0.7 A/cm2, H2/air Single-Cell Test with Inconel-601 Manifolds Degradation rate = 0.67 μV/hour (after first 100 hours)

Durability Attributes

0.0 1.0 2.0 3.0 4.0 50 100 150 200 250 300 350

Stack Potential (volts) Time (hours)

100 mV/cell degradation T = 800ºC, J = 350 mA/cm2

Redox Cycling Capability (3-cell stack, Hybrid Cells) Long-Term Durability (Hybrid Cell)

slide-12
SLIDE 12

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

100 200 300 400 500 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 100 200 300 400 500 600 Power (watts) Cell Potential (volts) Current (amps)

426 watts 562 A @ 0.759 V UF = 71% T = 800ºC Anode: 11.0 lpm H2/N2 (50%) Cathode: 40 lpm air

Total Cell Area: 1200 cm2 Active Cell Area: 800 cm2

Scalability to Large Areas for Higher Power Stacks

slide-13
SLIDE 13

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

0.0 1.0 2.0 3.0 4.0 100 200 300 400 500 Potential (volts) Time (hours)

T = 800ºC J = 0.203 A/cm2 UF = 65% 50 pmm H2S Fuel

34.6% H2 8.4% CO 30.0% H2O 8.1% CO2 18.9% N2

Sulfur Tolerant Stack Operation (3-Cell Stack)

Simulated ATR Reformate 50 ppm H2S, UF = 65%

slide-14
SLIDE 14

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Status of NexTech’s SOFC Stack Technology

slide-15
SLIDE 15

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

14.6 by 22.2 cm 18.4 by 29.2 cm

FlexCell for 1-2 kW stacks FlexCell for 5-10 kW stacks

Stack-Intent FlexCells

slide-16
SLIDE 16

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

1-kW Scale Stack Platform

Total Cell Area: 320 cm2 Active Cell Area: 160 cm2 24-Cell Stack

200 400 600 800 1000 1200 5 10 15 20 25 30 10 20 30 40 50 60 Stack Power (watts) Stack Potential (volts) Current (amps) 1.04 kW @ 0.78 V/cell 70% fuel utilization

slide-17
SLIDE 17

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

200 400 600 800 1000 1200 5 10 15 20 25 30 10 20 30 40 50 60 Power (watts) Potential (volts) Current (amps)

Stack #128 Stack #133 Stack #134 Stack #138 Stack #142

Stack Temperature = 800ºC 26.8 lpm H2/N2, 120 lpm air

Reproducibility

  • f 24-Cell Stacks
slide-18
SLIDE 18

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

5-10 kW Scale Stack Platform

Total Cell Area: 540 cm2 Active Cell Area: 300 cm2

100 200 300 400 0.0 1.0 2.0 3.0 4.0 50 100 150 200 Stack Power (watts) Stack Potential (volts) Current (amps) 344 W @ 172 A UF = 91.5 percent 48.5% efficiency

3-Cell Stack

3-Cell Stack

150 300 450 600 750 900 1050 1200 2 4 6 8 10 12 14 25 50 75 100 125 150 Stack Power (watts) Stack Potential (volts) Current (amps) 1033 W @ 132 A 0.782 V/cell UF = 70.1 percent

10-Cell Stack

10-Cell Stack

slide-19
SLIDE 19

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

0.0 1.0 2.0 3.0 4.0 30 60 90 120 150 Stack Potential (volts) Current (amps)

first pole curve after 1st cycle after 2nd cycle UF = 70% (J = 0.441 A/cm2) First pole curve: 2.28 volts After first cycle: 2.24 volts After second cycle: 2.22 volts

T = 790°C Anode: 7.88 lpm H2/N2 Cathode: 28 lpm air

Degradation @ UF = 70% First Cycle: 1.47% Second Cycle: 1.04%

Thermal Cycling (large-area 3-cell stack)

slide-20
SLIDE 20

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

New Stack Design (higher efficiency)

0.0 0.1 0.2 0.3 0.4 0.0 0.2 0.4 0.6 0.8 1.0 1.2 0.0 0.1 0.2 0.3 0.4 0.5 Power Density (W/cm2) Potential (V/cell) Current Density (A/cm2) H2/N2 fuel, T= 800°C 9-Cell Stack (New Design) 10-Cell Stack (Original Design)

UF = 70%

slide-21
SLIDE 21

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

0.60 0.65 0.70 0.75 0.80 0.85 0.90 12 24 36 48 60 72 Potential (volts/cell) Time (hours) Stack: UF = 79.6% LHV Efficiency: 46.0% 9-Cell Stack (160-cm2 active area) T = 800°C, J = 0.30 A/cm2, 330 watts Fuel 42% H2 (2995 sccm) 11% CO (785 sccm) 16% CO2 (1141 sccm) 31% H2O (2210 sccm)

High Efficiency Stack Operation

Simulated Steam Reformate UF = 79.6% LHV Efficiency = 46.0%

slide-22
SLIDE 22

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

  • Developing interconnect coating technology to

enable long-term durability and thermal cycling

  • Completing 1-2 kW stack platform, focusing on

efficiency, durability and thermal cycling

  • Breadboard demonstrations of SOFC power

generation using military logistic fuels

  • Continuing development of 5-10 kW stack

platform

  • Offering 1-kW scale stacks for evaluation by

potential partners

Ongoing Stack Development Activities

slide-23
SLIDE 23

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Fabrication and Testing

  • f YSZ-Based FlexCells

(SECA Project)

slide-24
SLIDE 24

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Fabrication of YSZ-Based FlexCells

Architecture Variables

  • Support thickness: 80-160 μm
  • Membrane thickness: 24-32 μm
  • Percent thin membrane in active

region: 65-75 percent

  • Support mesh pattern/geometry
slide-25
SLIDE 25

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

YSZ Based FlexCell

0.0 0.2 0.4 0.6 0.8 1.0 1.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 0.0 0.3 0.6 0.9 1.2 1.5 Power Density (W/cm2) Cell Potential (volts) Current Density (A/cm2)

850ºC: ASR = 0.20 Ω-cm2 800ºC: ASR = 0.27 Ω-cm2 750ºC: ASR = 0.42 Ω-cm2

A = 28 cm2 Fuel: 450 sccm H2

slide-26
SLIDE 26

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

YSZ versus ScSZ (Identical Geometry)

0.0 0.2 0.4 0.6 0.8 1.0 1.2 0.0 0.4 0.8 1.2 1.6

Cell Potential (volts) Current Density (A/cm2)

ScSZ Electrolyte YSZ Electrolyte YSZ Electrolyte 850ºC 750ºC

slide-27
SLIDE 27

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

0.0 0.2 0.4 0.6 0.8 0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0 1.2

Power Density (W/cm2) Cell Potential (volts) Current Density (A/cm2)

T = 800ºC, UF = 70% 475 mW/cm2 at 0.7 volts 287 mW/cm2 at 0.8 volts

Constant Utilization Pole Curve Data

slide-28
SLIDE 28

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Large-Area YSZ-Based FlexCells

slide-29
SLIDE 29

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

40 80 120 160 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 40 80 120 160 200 Power (watts) Cell Potential (volts) Current (amps)

135 watts (0.70 V @ 190 A) 73% fuel utilization T = 800ºC Fuel: H2/N2

Large-Area YSZ-Based FlexCell

slide-30
SLIDE 30

Invent, Develop, Deliver.

12th Annual SECA Workshop: July 28, 2011

Future Work

  • Fabrication of YSZ-based FlexCells for stack

testing at NexTech

  • Long-term testing of three-cell stacks with

simulated coal gas

  • Testing of full-scale SOFC stacks made with

YSZ-Based FlexCells

  • Preparation of the Final Report
