SINTEF RFI ACTIVITIES

June 2019, Helsinki Aiden Morrison, Nadia Sokolova

• Brief SINTEF Introduction
• Our motivations for pursuing RFI monitoring
• Past projects covering GNSS interference
• Lessons learned, and knowledge gaps
• Ongoing activities, and upcoming monitoring hardware

2

Outline

3

4

GBAS RFI Monitoring GNSS for ITS Indoor Navigation Custom Navigation HW System Design

Image sources: [3]

Autonomous system Navigation

Navigation Focused Research Areas

• While all GNSS applications are vulnerable to RFI, some have higher potential losses
• If my phone loses GNSS due to RFI, I might be slightly inconvenienced
• If our drone loses GNSS due to RFI, we might lose a very expensive drone or crash in to important infrastructure
• Example of an economic impact
• Some applications have higher risks

5

Our motivation for pursuing RFI monitoring

6

GBAS - Ground Based Augmentation System Concept of operation:

• Similar to differential GNSS but with extras
• Corrections and safety flags are carried from

the ground to the aircraft via a dedicated VHF link called VDB

• There are typically four ground stations

which allow for much more sensitive monitoring for outliers and errors

• But the system is very sensitive to signal

degradation from RFI

CAT III GBAS-based Automatic Landing

7

Precision Approach Requirements

• Category type identifies system capability, indicating the minimum approach height that can be

achieved.

• Hitting these performance metrics is hard under ideal conditions.
• If weak RFI is present on even one of the four antennas it can reduce availability and continuity
• Stronger RFI is an immediate problem – there are several recent examples

GBAS Precision Operation CAT l CAT ll CAT lll Accuracy [m] 95 % Horizontal 16.0 6.9 6.1 Vertical 7.7 2.0 2.0 Integrity Time-to-Alert [s] 3 2 2 Alert Limit [m] H: 40 V: 10-15 H: 17.3 V: 5.3 H: 15.5 V: 5.3 PHMI / approach 2x10-5 2x10-9 2x10-9 Continuity Failure Rate 5x10-5 / approach 5x10-6 / 15 sec 10-7 / 15 sec Availability 0.99 – 0.99999 0.99 – 0.99999 0.99 – 0.99999

8

GBAS and other aircraft events (plus a fancy boat)

• From the point of view of GBAS, we need to know a few pieces of information about RFI
• 1) The occurrence rate
• 2) The relative occurrence rate
• Future GBAS systems are intended to use both the L1/E1 and L5/E5a bands on GPS and Galileo
• In the event of RFI on a single frequency it may be possible to fall back to operation using only the other
• 3) Power levels
• 4) Spectral occupancy
• Unintentionally generated tones are mitigated by the signals themselves
• It may be possible to identify individual emitters over differing events and positions
• Unfortunately real-time analysis at this level can be computationally expensive
• Instead, we take an alternative approach

9

What we need to know

• RFI detection concept – how to detect RFI with minimal processing power?
• It’s not feasible to analyze all signals in real time in terms of C/N0 – that would require a full multifrequency GNSS

receiver and wouldn’t provide us a bitstream for our SDR

• Instead we look for in band power level deviation
• Must allow for site to site variation and slow variability due to thermal effects etc. But rapid increases in power are strong indicators of RFI
• Weak events visible
• Strong events up to -10dBm
• Example of car-borne jammer events

10

Event detection - 1

Event detection - 2

• Mobile Jammer
• Cigarette lighter style
• 'Stepped CW' signal
• Car drove within 10 m
• Test conducted with NKOM and FFI
• Other monitors deployed
• Indra Navia, DFS, NLR, ESTEC
• The monitor at ESTEC triggered frequently on adjacent band pulsed power sources (See Event 000)
• Also caught a delivery truck or taxi with a jammer
• Event 008 is a jamming event
• GNSS satellites cannot be tracked in L1 band for duration
• There are Drawbacks to this approach

11

• Three major factors motivated the design of a second generation monitoring system
• The Manual result collection and analysis required a large amount of user intervention
• Far too many "false alarms"
• E5b, L2, G2, E6, E1PRS, and G1 not collected/analyzed
• These signals all have slightly different characteristics making them more or less suitable to different use cases
• Let’s see what this coverage looks like on a signal map

12

Lessons learned & Knowledge gaps

• A chart is helpful:
• Ignoring the S-band signals, this chart shows the L-band
• Signal plans evolve over time
• Uncertain if the GLONASS CDMA plans are still accurate
• Most of these signals are now turned on and ’healthy’
• The rise of RFI
• As GNSS has risen to solve more and more problems, it has become a larger target
• People are right to be paranoid about being tracked, but jamming GNSS is hazardous
• If usage based road tolling depends on GNSS it will become a target
• This is why we need a radically different front-end
• From 2x24 MHz to 4 x 55 MHz
• This is a nearly 5x increase in the amount of data
• For reasons we will cover later we also want to go from 1 bit to 4 bit
• 4x again so ~20x the data relative to the first system
• A higher dynamic range is also desirable

13

RF signal background - 3 of 3

• Our design needs to tolerate 6 or 7 orders of magnitude
• (Images from wikipedia, Nuand, and Maxim)
• 60-70dB+ dynamic range
• Each bit of ADC range represents 3dB of amplitude dynamic range, 6dB of power
• Each bit of ADC range takes up more data whether or not the signal is using these bits
• Therefore – it’s inefficient to throw bits at the problem outside of processing applications that need or benefit from having a wide dynamic range signal
• E.g. Novatel 7 series receivers have 8 bit quantization but only turn it on when requested for RFI mitigation, otherwise they use 4 bits to save energy
• Instead we need to employ what is called ’gain control’ to feed back from the digitized signal to the analog gain levels
• Dynamic range considerations map back to every stage of the design
• IP3 etc. Of first gain stage
• Maximum power handling of components (SAWs and LNA)
• Representation range of the ADCs
• Gain Control and feedback to use a VGA
• The MAX2120 mixer chip includes a VGA with a 70 dB analog linear range
• Also 15dB of digital control range at the baseband, for a combined 85dB
• Probably not feasible to use the full range, but still a good start
• System block diagram

14

Quantization concepts and requirements - 3 of 3

15

• System automation, and updated hardware capabilities

Hardware: Reconfigurable multiband front-end. Cloud Storage, Archiving and Retrieval Hardware: Embedded computer module (COTS) Software: Online monitoring, analysis and

• notification. Periodic

archiving and reporting. Power In (<90W) GNSS Antenna USB3 Ethernet Notifications (e.g. Email) User configuration options USB3 LNA, Splitter SAW, E1/L1/G1 SAW, E5/L2/E6 LNA, Splitter LNA, Splitters RF Power Meter A RF Power Meter B VGA, Mixer, LPF 1 VGA, Mixer, LPF 2 VGA, Mixer, LPF 3 VGA, Mixer, LPF 4 8x ADC FPGA USB3 FIFO OCXO, Clocking Other Low Level Interfaces RF via USB3 Other Low Level Interfaces to FPGA i.MX8 SOM

• Detection,

and pre- processing software PCIe to SATA2 IC PCIe SATA2 SATA2 SSD Keyboard/Mouse (USB2) Monitor (HDMI) Ethernet Interface RGMII Notifications (e.g. Email) Raw and processed data Indicator LEDs, and Buttons

Design Evolution - Concept

• First version powered up and ran code
• Now in the process of implementing firmware
• Why not just buy an off-the-shelf front-end?
• A few small reasons
• 1) None have integrated power level measurement for environment

characterization and triggering

• 2) Onboard oscillator and clock generators need to be low phase noise

components for GNSS signals

• 3) GNSS Pre-filtering /Sensitivity to adjacent band signals:
• Front-ends like HackRF, bladeRF, and LimeSDR focus on wide bandwidth
• This makes sensitive pre-triggering difficult and pushes up false alarm rates
• 4) Many off the shelf solutions use fractional-N PLLs in their mixers
• Can introduce large residual code-carrier divergence
• Deployment plans...

16

Design Evolution - Hardware

• Multiple locations in Norway and Europe (e.g. research

facilities at ESTEC and NLR).

• Several sites to be operated by the Norwegian Public

Roads Administration. SINTEF monitors will be co- located with monitoring equipment deployed by Nkom.

17

Deployment plans

Patterødkrysset (Busiest intersection in Norway) E8 Kilpisjärvi-Skibotn Road used for autonomous testing

• Starting next year we hope to have phased array based RFI detectors which provide bearing

information to the host system

• These will be tested for drones based detection and tracking of GNSS RFI sources
• I want the drones to be able to ’remove’ the source, but unlikely to get HMS approval

18

Future activities

• If GNSS based road pricing is adoped there will very likely be a large spike in RFI events
• It produces a financial incentive
• It will be necessary to have a comittment to both prevention and response
• Prevent jamming equipment from entering the country
• The credible ability to rapidly detect and localize jamming

19

Policy outlook
