SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing Giovanni Nardini , Antonio Virdis, Giovanni Stea, Angelo Buono Department of Information Engineering, University of Pisa, Italy OMNeT++ Community Summit 2018, Pisa, Italy Outline

slide-1
SLIDE 1

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Giovanni Nardini, Antonio Virdis, Giovanni Stea, Angelo Buono

Department of Information Engineering, University of Pisa, Italy OMNeT++ Community Summit 2018, Pisa, Italy

slide-2
SLIDE 2

Giovanni Nardini – University of Pisa

Outline

  • Road towards 5G
  • LTE/LTE-A & Multi-access Edge Computing (MEC) technologies
  • Simulating LTE networks with OMNeT++: SimuLTE
  • Modeling MEC within SimuLTE
  • Use case: alerts in a vehicular network scenario
  • Conclusions

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-3
SLIDE 3

Giovanni Nardini – University of Pisa

The road towards 5G

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-4
SLIDE 4

Giovanni Nardini – University of Pisa

The LTE/LTE-Advanced technology

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Internet eNodeB User Equipments (UEs) Downlink (DL) Uplink (UL) Device-to-device (D2D) PGW Core Network

slide-5
SLIDE 5

Giovanni Nardini – University of Pisa

Introducing MEC

Multi-access Edge Computing

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Internet Core Network eNodeB User Equipments (UEs) PGW

ME Host

slide-6
SLIDE 6

Giovanni Nardini – University of Pisa

ETSI MEC Framework

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Keep the status

  • f ME Hosts

Selects a ME Host for allocating a ME App Accomplish a specific task Services that can be exploited by ME Apps Creates/destroys instances of VMs for running ME Apps N ME Hosts

[1] ETSI GS MEC 003, ‘’Mobile Edge Computing (MEC); Framework and reference architecture’’

slide-7
SLIDE 7

Giovanni Nardini – University of Pisa

Simulating LTE+MEC

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Internet

Algorithms for allocation of computing resources

ME Host ME Host

Optimal deployment

  • f ME hosts

Performance evaluation at larger scale w.r.t. real testbeds Migration of ME Applications between ME Hosts Prototyping MEC-based applications and protocols

slide-8
SLIDE 8

Giovanni Nardini – University of Pisa

Simulating cellular networks with OMNeT++

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

http://simulte.com

System-level simulations of LTE/LTE-Advanced networks

  • Developed at the University of Pisa
  • Full protocol stack implementation of the LTE Network

Interface Card (LTE NIC)

  • Extends the INET’s INetworkInterface module
  • Interoperability with INET’s higher-layer protocol modules

PDCP RLC MAC PHY

Scheduler ChannelModel

CoMP Handover

D2D Mode Selection

LTE NIC

slide-9
SLIDE 9

Giovanni Nardini – University of Pisa

SimuLTE basics

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

LTE NIC

IP UDP TCP UDP Apps TCP Apps

LTE NIC

IP

X2

PPP

UE eNodeB Binder LTE NIC Car

UDP GTP

Main components

[2] G. Nardini, A. Virdis, G. Stea, ‘’Simulating cellular communications in Vehicular Networks: making SimuLTE interoperable with Veins’’, OMNeT++ Comm. Summit 2017

Arter ery

[2]

…

slide-10
SLIDE 10

Giovanni Nardini – University of Pisa

SimuLTE basics

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

  • Data-plane only

LTE NIC

IP

X2

PPP

eNodeB

UDP GTP IP PPP

PGW

UDP GTP PPP

The core network

  • GTP tunneling between the eNodeB and the PGW
slide-11
SLIDE 11

Giovanni Nardini – University of Pisa

Modeling the MEC architecture

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

LTE NIC

IP

X2

PPP

eNodeB

UDP GTP IP PPP

MeHost

UDP GTP PPP

  • GTP tunneling between the eNodeB and the ME Host

GtpEndpoint VirtualisationInfrastructure MePlatform

slide-12
SLIDE 12

Giovanni Nardini – University of Pisa

Modeling the MEC architecture

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

IP UDP PPP VirtualisationManager ResourceManager

GtpEndpoint Virtualisation Infrastructure MePlatform

IMeService[0] IMeService[N-1]

… MeHost

slide-13
SLIDE 13

Giovanni Nardini – University of Pisa

Modeling the MEC architecture

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

IP UDP PPP VirtualisationManager ResourceManager

GtpEndpoint Virtualisation Infrastructure MePlatform

IMeService[0] IMeService[N-1]

…

IMeApp[0] IMeApp[M-1]

MeHost …

slide-14
SLIDE 14

Giovanni Nardini – University of Pisa

Data flow

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Definition of MeAppPacket

  • START_MEAPP
  • STOP_MEAPP
  • ACK_START_MEAPP
  • ACK_STOP_MEAPP
  • INFO_UEAPP
  • INFO_MEAPP
slide-15
SLIDE 15

Giovanni Nardini – University of Pisa

Data flow

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Definition of MeAppPacket

  • START_MEAPP
  • STOP_MEAPP
  • ACK_START_MEAPP
  • ACK_STOP_MEAPP
  • INFO_UEAPP
  • INFO_MEAPP
slide-16
SLIDE 16

Giovanni Nardini – University of Pisa

A use case for MEC

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Car alert service

The car is approaching a black ice area:

  • On-board sensors
  • Vehicle-to-vehicle communications (VANETs)
  • Vehicle-to-infrastructure communications (Wi-Fi access to Road-side units)
  • Communication with a remote server
slide-17
SLIDE 17

Giovanni Nardini – University of Pisa

A use case for MEC

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Car alert service Using MEC

slide-18
SLIDE 18

Giovanni Nardini – University of Pisa

A use case for MEC

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

Car alert service Using MEC

slide-19
SLIDE 19

Giovanni Nardini – University of Pisa

Implementing a MEC-based car alert service

  • UEWarningAlertApp – periodically sends position updates to the ME Host
  • MEWarningAlertApp – receives position updates from UEs
  • MEWarningAlertService – keeps the map of danger zones
  • WarningAlertPacket – includes position information

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-20
SLIDE 20

Giovanni Nardini – University of Pisa

Configuring the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-21
SLIDE 21

Giovanni Nardini – University of Pisa

Running the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-22
SLIDE 22

Giovanni Nardini – University of Pisa

Running the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-23
SLIDE 23

Giovanni Nardini – University of Pisa

Running the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-24
SLIDE 24

Giovanni Nardini – University of Pisa

Running the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-25
SLIDE 25

Giovanni Nardini – University of Pisa

Running the simulation

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-26
SLIDE 26

Giovanni Nardini – University of Pisa

Conclusions

  • Multi-access Edge Computing and cellular networks
  • Modeling MEC within SimuLTE
  • Compliance with ETSI specifications
  • Pluggable interface to allow researchers evaluating new apps and services
  • Use case: car alert service
  • Implementation
  • Simulation configuration

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-27
SLIDE 27

Giovanni Nardini – University of Pisa

Future work

  • Additional services as per ETSI specifications, e.g. Location Manager
  • Support for migrating ME Applications between ME Hosts
  • Detailed modeling of ME Applications lifecycle and resource utilization
  • Evaluation of new use cases and scenarios (suggestions are welcome!)

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing

slide-28
SLIDE 28

Thank You!

Giovanni Nardini – University of Pisa g.nardini@ing.unipi.it

SimuLTE-MEC: extending SimuLTE for Multi-access Edge Computing
