SLIDE 1

Irene Parada Extending Simple Drawings

Extending Simple Drawings

Alan Arroyo1, Martin Derka2, and Irene Parada3

1 IST Austria 2 Carleton University, Canada 3 Graz University of Technology, Austria

SLIDE 2

Irene Parada Extending Simple Drawings

Simple drawings

SLIDE 3

Irene Parada Extending Simple Drawings

Simple drawings

Not simple drawings:

SLIDE 4

Irene Parada Extending Simple Drawings

Simple drawings

Locally fixed: now they are!

SLIDE 5

Irene Parada Extending Simple Drawings

Simple drawings

Locally fixed: now they are! Drawings that minimize the total number of crossings are simple.

SLIDE 6

Irene Parada Extending Simple Drawings

Extending a partial representation

Abstract graph G (Partial) representation of a subgraph of G

SLIDE 7

Irene Parada Extending Simple Drawings

Extending a partial representation

Abstract graph G (Partial) representation of a subgraph of G

SLIDE 8

Irene Parada Extending Simple Drawings

Extending a partial representation

Abstract graph G (Partial) representation of a subgraph of G

SLIDE 9

Irene Parada Extending Simple Drawings

Extending a partial representation

[Bagheri, Razzazi ’10]
[Jel´

ınek, Kratochv´ ıl, Rutter ’13]

[Angelini et. al. ’15]
[Mchedlidze, N¨
llenburg,

Rutter ’15]

[Br¨

uckner, Rutter ’17]

[Da Lozzo, Di Battista,

Frati ’19]

[Patrignani ’06]
[Klav´

ık, Kratochv´ ıl, Krawczyk, Walczak ’12]

[Chaplick et. al. ’14]
[Klav´

ık, Kratochv´ ıl, Otachi, Saitoh ’15]

[Klav´

ık et. al. ’17]

[Klav´

ık et. al. ’17]

[Chaplick et. al. ’18]
[Chaplick, Fulek, Klav´

ık ’19] Extending partial drawings

f planar graphs:

Extending partial rep. that are not drawings:

SLIDE 10

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

Given a simple drawing D(G) of a graph G = (V, E) we want to insert a set of edges (of the complement of G) s.t. the result is a simple drawing with D(G) as a subdrawing.

SLIDE 11

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

In straight-line drawings trivially YES

SLIDE 12

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

In pseudolinear drawings YES by Levis enlargement lemma

SLIDE 13

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v

SLIDE 14

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v

SLIDE 15

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] uv cannot be added

SLIDE 16

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] uv cannot be added

SLIDE 17

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] u v ... ... uv cannot be added Km,n

SLIDE 18

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] u v ... ... uv cannot be added u v ... Km,n Kn \ uv

SLIDE 19

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] u v ... ... uv cannot be added u v ... Km,n Kn \ uv What about matchings?

SLIDE 20

Irene Parada Extending Simple Drawings

Can we always insert the remaining edges?

u v [Kynˇ cl ’13] u v ... ... uv cannot be added u v ... Km,n Kn \ uv What about matchings? [Kynˇ cl, Pach, Radoiˇ ci´ c, T´

th ’14]

u v u v

SLIDE 21

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

SLIDE 22

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

Variable gadget u v

SLIDE 23

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

Variable gadget u v

SLIDE 24

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

Variable gadget u v v u Clause gadget

SLIDE 25

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

Variable gadget u v v u Clause gadget Wire gadget u v

SLIDE 26

Irene Parada Extending Simple Drawings

Inserting a set of edges is NP-complete

Reduction from monotone 3SAT.

true false Clause gadgets Wire gadgets Variable gadget

SLIDE 27

Irene Parada Extending Simple Drawings

Finding the largest extension is APX-hard

Reduction from maximum indep. set in max. deg. ≤ 3.

SLIDE 28

Irene Parada Extending Simple Drawings

Finding the largest extension is APX-hard

Reduction from maximum indep. set in max. deg. ≤ 3.

v u Vertex gadget

SLIDE 29

Irene Parada Extending Simple Drawings

Finding the largest extension is APX-hard

Reduction from maximum indep. set in max. deg. ≤ 3.

v u Vertex gadget u v Edge gadget

SLIDE 30

Irene Parada Extending Simple Drawings

Finding the largest extension is APX-hard

Reduction from maximum indep. set in max. deg. ≤ 3.

v u Vertex gadget u v Edge gadget

SLIDE 31

Irene Parada Extending Simple Drawings

Finding the largest extension is APX-hard

Reduction from maximum indep. set in max. deg. ≤ 3.

SLIDE 32

Irene Parada Extending Simple Drawings

Inserting one single edge

...

u v An edge may be added in exponentially many ways.

SLIDE 33

Irene Parada Extending Simple Drawings

Inserting one single edge

...

u v An edge may be added in exponentially many ways. View in the dual: Heterochromatic path.

SLIDE 34

Irene Parada Extending Simple Drawings

Inserting one single edge

...

u v An edge may be added in exponentially many ways. View in the dual: Heterochromatic path.

SLIDE 35

Irene Parada Extending Simple Drawings

Inserting one single edge

...

u v An edge may be added in exponentially many ways. Theorem: If {u, v} is a dominating set for G then the problem of extending D(G) with the edge uv can be decided in polynomial time. View in the dual: Heterochromatic path.

SLIDE 36

Irene Parada Extending Simple Drawings

Conclusions

Results:

Deciding if we can insert a set of k edges is NP-complete.
Maximizing the number of edges from a given set that we can

insert is APX-hard.

Under certain conditions we can decide in polynomial time if we

can insert a particular edge.

SLIDE 37

Irene Parada Extending Simple Drawings

Conclusions

Results:

Deciding if we can insert a set of k edges is NP-complete.
Maximizing the number of edges from a given set that we can

insert is APX-hard.

Under certain conditions we can decide in polynomial time if we

can insert a particular edge. Question:

Computational complexity of deciding whether a given edge can

be inserted?

SLIDE 38

Irene Parada Extending Simple Drawings

Conclusions

A. Arroyo, F. Klute, I. Parada, R. Seidel, B. Vogtenhuber, T. Wiedera.

Extending simple drawings with one edge is hard. arXiv:1909.07347. Results:

Deciding if we can insert a set of k edges is NP-complete.
Maximizing the number of edges from a given set that we can

insert is APX-hard.

Under certain conditions we can decide in polynomial time if we

can insert a particular edge. Question:

Computational complexity of deciding whether a given edge can

be inserted?

S

l

v e d

SLIDE 39

Irene Parada Extending Simple Drawings

Conclusions

A. Arroyo, F. Klute, I. Parada, R. Seidel, B. Vogtenhuber, T. Wiedera.

Extending simple drawings with one edge is hard. arXiv:1909.07347. Results:

Deciding if we can insert a set of k edges is NP-complete.
Maximizing the number of edges from a given set that we can

insert is APX-hard.

Under certain conditions we can decide in polynomial time if we

can insert a particular edge.

Thank you!

Question:

Computational complexity of deciding whether a given edge can

be inserted?

S

l
