SIDEWALK TRIP HAZARDS PROJECT EIIA MEMBERS MEETING CHUCK STAIB, PRESENTING DATE LOCATION NOVEMBER 6, 2015 SUNNY ISLES BEACH, FLORIDA EIIA Losses 9/1/2010 9/1/2015 (WC & GL) 41% OF WC LOSSES 21% OF GL LOSSES Falls $16.21M

slide-1
SLIDE 1

PROJECT DATE LOCATION

SIDEWALK TRIP HAZARDS

EIIA MEMBERS MEETING • CHUCK STAIB, PRESENTING NOVEMBER 6, 2015 SUNNY ISLES BEACH, FLORIDA

slide-2
SLIDE 2

Falls $16.21M All Other $47.01M 21% OF GL LOSSES 41% OF WC LOSSES

EIIA Losses

9/1/2010 – 9/1/2015

(WC & GL)

slide-3
SLIDE 3

Falls: Paved Surface & Trip Over Object, $3.54 Falls: All Other Causes $12.67

EIIA Fall Loss Causes

9/1/2010 – 9/1/2015

(WC & GL)

slide-4
SLIDE 4

AGENDA

  • Examples of

Problems

  • Causes
  • Reasons to Repair
  • Program Goals
  • Solutions
  • Effectiveness Metrics
  • Measuring Success
slide-5
SLIDE 5

Examples of Problems 1 2 3

  • a. Las Vegas, NV
  • b. Parker, CO
  • c. Philadelphia, PA
slide-6
SLIDE 6

Examples of Problems 1 2 3

  • a. Las Vegas, NV
  • b. Parker, CO
  • c. Philadelphia, PA

answers: 1a, 2c, 3b

slide-7
SLIDE 7

Examples of Problems 1 2 3

  • a. Orlando, FL
  • b. Salt Lake City, UT
  • c. Boston, MA
slide-8
SLIDE 8

Examples of Problems 1 2 3

  • a. Orlando, FL
  • b. Salt Lake City, UT
  • c. Boston, MA

answers: 1c, 2b, 3a

slide-9
SLIDE 9

Causes

slide-10
SLIDE 10

Causes

Tree Roots Root pruning often kills trees and most municipalities don’t consider removing trees as a viable solution.

slide-11
SLIDE 11

Causes

Tree Roots Root pruning often kills trees and most municipalities don’t consider removing trees as a viable solution. Ground Settling Improper compaction upon install.

slide-12
SLIDE 12

Causes

Tree Roots Root pruning often kills trees and most municipalities don’t consider removing trees as a viable solution. Ground Settling Improper compaction upon install. Freeze / Thaw Typically in areas with heavy water concentration: near ponds, broken sprinklers, etc. Reverts to the natural state. Clay soils expand due to positive ions that attract water.

slide-13
SLIDE 13

Reasons to Repair

slide-14
SLIDE 14

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility.

slide-15
SLIDE 15

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility. Note: 12.6%, 7.1%, 5.6%

slide-16
SLIDE 16

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility. Aesthetics Make sidewalks attractive and enjoyable.

slide-17
SLIDE 17

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility. Aesthetics Make sidewalks attractive and enjoyable. Safety Keep sidewalks a safe and healthy alternative to other transportation choices.

slide-18
SLIDE 18

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility. Aesthetics Make sidewalks attractive and enjoyable. Safety Keep sidewalks a safe and healthy alternative to other transportation choices. Minimize Liability Avoid costly litigation or settlements for injuries on sidewalks; reduce insurance costs.

slide-19
SLIDE 19

Reasons to Repair

ADA Compliance Bring sidewalks into compliance with The Americans with Disabilities Act and increase sidewalk accessibility. Aesthetics Make sidewalks attractive and enjoyable. Safety Keep sidewalks a safe and healthy alternative to other transportation choices. Minimize Liability Avoid costly litigation or settlements for injuries on sidewalks; reduce insurance costs. Prolong Life of Assets Proactively maintain sidewalk infrastructure to prolong usable life and save money.

slide-20
SLIDE 20

Reasons to Repair- ADA

slide-21
SLIDE 21

Reasons to Repair- ADA

slide-22
SLIDE 22

Reasons to Repair- ADA

slide-23
SLIDE 23

Program Goals

slide-24
SLIDE 24

Program Goals

  • 1. The Americans With Disabilities Act Compliance
  • Consistent Slope Conforming to the ADA
  • Zero Point of Differential Between Slabs at Joints
  • Consistent Edge to Edge Fix
  • Static Co-Efficient of Friction (an OSHA requirement)
slide-25
SLIDE 25

Program Goals

  • 1. The Americans With Disabilities Act Compliance
  • Consistent Slope Conforming to the ADA
  • Zero Point of Differential Between Slabs at Joints
  • Consistent Edge to Edge Fix
  • Static Co-Efficient of Friction (an OSHA requirement)
  • 2. Aesthetically Pleasing & Minimally Invasive to Students
slide-26
SLIDE 26

Program Goals

  • 1. The Americans With Disabilities Act Compliance
  • Consistent Slope Conforming to the ADA
  • Zero Point of Differential Between Slabs at Joints
  • Consistent Edge to Edge Fix
  • Static Co-Efficient of Friction (an OSHA requirement)
  • 2. Aesthetically Pleasing & Minimally Invasive to Students
  • 3. Preemptive Cure of Liability
slide-27
SLIDE 27

Program Goals

  • 1. The Americans With Disabilities Act Compliance
  • Consistent Slope Conforming to the ADA
  • Zero Point of Differential Between Slabs at Joints
  • Consistent Edge to Edge Fix
  • Static Co-Efficient of Friction (an OSHA requirement)
  • 2. Aesthetically Pleasing & Minimally Invasive to Students
  • 3. Preemptive Cure of Liability
  • 4. Environmentally Friendly Solution
slide-28
SLIDE 28

Program Goals

  • 1. The Americans With Disabilities Act Compliance
  • Consistent Slope Conforming to the ADA
  • Zero Point of Differential Between Slabs at Joints
  • Consistent Edge to Edge Fix
  • Static Co-Efficient of Friction (an OSHA requirement)
  • 2. Aesthetically Pleasing & Minimally Invasive to Students
  • 3. Preemptive Cure of Liability
  • 4. Environmentally Friendly Solution
  • 5. Cost-Effective
  • Detailed Report of Work / Proposal
  • Easy to Audit Work / Integrates into GIS System
slide-29
SLIDE 29

Solutions – Repair Methods

slide-30
SLIDE 30

Solutions – Repair Methods

Asphalt Patch - Ramp up to the higher panel using asphalt

slide-31
SLIDE 31

Solutions – Repair Methods

Asphalt Patch - Ramp up to the higher panel using asphalt Scabbler/Scarifier/Planer - Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure

  • r scraping of the surface
slide-32
SLIDE 32

Solutions – Repair Methods

Asphalt Patch - Ramp up to the higher panel using asphalt Scabbler/Scarifier/Planer - Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure

  • r scraping of the surface

Pumping - Drill holes, inject soil or a polyurethane blend including portland cement

slide-33
SLIDE 33

Solutions – Repair Methods

Asphalt Patch - Ramp up to the higher panel using asphalt Scabbler/Scarifier/Planer - Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure

  • r scraping of the surface

Pumping - Drill holes, inject soil or a polyurethane blend including portland cement Replacement - Break up, remove debris, form up and re-pour

slide-34
SLIDE 34

Solutions – Repair Methods

Asphalt Patch - Ramp up to the higher panel using asphalt Scabbler/Scarifier/Planer - Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure

  • r scraping of the surface

Pumping - Drill holes, inject soil or a polyurethane blend including portland cement Replacement - Break up, remove debris, form up and re-pour Saw Cutting - Horizontal slice, tapered or ramped transition at the joint

slide-35
SLIDE 35

Solutions - Pros & Cons

Asphalt Patch (or other patching materials) Ramp up to the higher panel using asphalt Pros:

  • Quick & Easy
  • Low Skill
  • Inexpensive
slide-36
SLIDE 36

Solutions - Pros & Cons

Asphalt Patch (or other patching materials) Ramp up to the higher panel using asphalt Pros:

  • Quick & Easy
  • Low Skill
  • Inexpensive

Cons:

  • Temporary
  • Aesthetically Poor
  • ADA Compliance
  • Breaks Up (thermal coefficient of expansion)
slide-37
SLIDE 37

Solutions - Pros & Cons

Scabbler/Scarifier/Planer (Grinder) Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure or scraping of the surface Pros:

  • Commercially Available
  • Environmentally Friendly
  • Other Uses
slide-38
SLIDE 38

Solutions - Pros & Cons

Scabbler/Scarifier/Planer (Grinder) Pounding steel, carbide rods or bits, rotating drum, pulverizes the surface with downward pressure or scraping of the surface Pros:

  • Commercially Available
  • Environmentally Friendly
  • Other Uses

Cons:

  • ADA Compliance (domed, width)
  • Damages Concrete
  • Incidental Damage
  • Staff Avoids It
  • Aesthetically Poor
slide-39
SLIDE 39

Solutions - Pros & Cons

Pumping Drill holes, inject soil or a polyurethane blend including portland cement Pros:

  • Commercially Available
  • Environmentally Friendly
  • Less Mess / Time
  • ADA Compliance
  • Aesthetics
  • Good For Large Slabs
slide-40
SLIDE 40

Solutions - Pros & Cons

Pumping Drill holes, inject soil or a polyurethane blend including portland cement Pros:

  • Commercially Available
  • Environmentally Friendly
  • Less Mess / Time
  • ADA Compliance
  • Aesthetics
  • Good For Large Slabs

Cons:

  • Expensive (Often Close to

R&R Cost)

  • Not Accurate (Can Still Leave

A Hazard)

  • 3rd Party Contractor
  • Speed
  • Incidentals
  • Not As Effective on Sidewalks

Lifts

slide-41
SLIDE 41

Solutions - Pros & Cons

Remove & Replace Break up, remove debris, form up and re-pour Pros:

  • Crew Experience
  • ADA Compliance
  • Aesthetics
  • Liability Avoidance
slide-42
SLIDE 42

Solutions - Pros & Cons

Remove & Replace Break up, remove debris, form up and re-pour Pros:

  • Crew Experience
  • ADA Compliance
  • Aesthetics
  • Liability Avoidance

Cons:

  • Expensive
  • Time / Labor
  • Incidentals
  • Speed (Poor for High Traffic

Areas)

  • Environmental Effects
slide-43
SLIDE 43

Solutions - Pros & Cons

Saw Cutting Horizontal slice, tapered or ramped transition at the joint Pros:

  • Speed
  • Low impact / Minimal Disruption
  • ADA Compliance
  • Aesthetics
  • Liability Avoidance
  • Inexpensive
  • Environmentally Friendly
  • Cost Savings
slide-44
SLIDE 44

Solutions - Pros & Cons

Saw Cutting Horizontal slice, tapered or ramped transition at the joint Pros:

  • Speed
  • Low impact / Minimal Disruption
  • ADA Compliance
  • Aesthetics
  • Liability Avoidance
  • Inexpensive
  • Environmentally Friendly
  • Cost Savings

Cons:

  • Offered as a Service
  • Unfamiliarity
  • Not Commercially Available
slide-45
SLIDE 45

Solutions - Pros & Cons

slide-46
SLIDE 46

Solutions - Pros & Cons

slide-47
SLIDE 47

Scale of Effectiveness

2 4 6 8 10

slide-48
SLIDE 48

Scale of Effectiveness - ADA

2 4 6 8 10

slide-49
SLIDE 49

Scale of Effectiveness - Aesthetics

2 4 6 8 10

slide-50
SLIDE 50

Scale of Effectiveness - Longevity

2 4 6 8 10

slide-51
SLIDE 51

Scale of Effectiveness - Environment

2 4 6 8 10

slide-52
SLIDE 52

Scale of Effectiveness - Cost

2 4 6 8 10

slide-53
SLIDE 53

Scale of Effectiveness - Value

Pump Remove & Replace Saw Cut Grind Asphalt Patch

ADA Compliance Longevity Aesthetics Cost Environmental Impact

slide-54
SLIDE 54

Measuring Success

GOAL OF PROGRAM

slide-55
SLIDE 55

Measuring Success

  • 1. Compliant with the ADA in all aspects?

Legal GOAL OF PROGRAM

slide-56
SLIDE 56

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?

Legal Legal GOAL OF PROGRAM

slide-57
SLIDE 57

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?

Legal Legal Students/Faculty GOAL OF PROGRAM

slide-58
SLIDE 58

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?
  • 4. Minimally Invasive to Residents?

Legal Legal Students/Faculty Students/Faculty GOAL OF PROGRAM

slide-59
SLIDE 59

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?
  • 4. Minimally Invasive to Residents?
  • 5. Easy to Audit Work?

Legal Legal Students/Faculty Students/Faculty Administration GOAL OF PROGRAM

slide-60
SLIDE 60

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?
  • 4. Minimally Invasive to Residents?
  • 5. Easy to Audit Work?
  • 6. Integrates into GIS System?

Legal Legal Students/Faculty Students/Faculty Administration Administration GOAL OF PROGRAM

slide-61
SLIDE 61

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?
  • 4. Minimally Invasive to Residents?
  • 5. Easy to Audit Work?
  • 6. Integrates into GIS System?
  • 7. Environmentally Friendly Solution?

Legal Legal Students/Faculty Students/Faculty Administration Administration Sustainability GOAL OF PROGRAM

slide-62
SLIDE 62

Measuring Success

  • 1. Compliant with the ADA in all aspects?
  • 2. Does it Reduce your Liability?
  • 3. Aesthetically Pleasing?
  • 4. Minimally Invasive to Residents?
  • 5. Easy to Audit Work?
  • 6. Integrates into GIS System?
  • 7. Environmentally Friendly Solution?
  • 8. What’s the Cost?

Legal Legal Students/Faculty Students/Faculty Administration Administration Sustainability

Financial Stakeholders

GOAL OF PROGRAM

slide-63
SLIDE 63

Measuring Success

  • 1. Contract amount was $200K (6,932 Inch Feet)
  • 2. Specs of the contract (1/4” to 2”)
  • 3. Total removed hazards (4,791)
  • 4. Average height/length of the hazard (5/8” x 3.1’)
  • 5. Average panel size (4 x 6 panel)
  • 6. Total lineal feet repaired (5.44 miles)
  • 7. Cost per square foot ($1.19 compared to $8.00 R&R)
  • 8. Overall savings 80.74%

Highlights of Trip Hazard Removal Program - 2009-2010

slide-64
SLIDE 64

Measuring Success -

Proposals

slide-65
SLIDE 65

Measuring Success -

Proposals

slide-66
SLIDE 66

Measuring Success -

Proposals

slide-67
SLIDE 67

Measuring Success -

Proposals

slide-68
SLIDE 68

Measuring Success -

Proposals

slide-69
SLIDE 69

Measuring Success - Results

slide-70
SLIDE 70

Measuring Success - Results

slide-71
SLIDE 71

Measuring Success - Results

slide-72
SLIDE 72

Measuring Success

slide-73
SLIDE 73

Safe Step: WI, IL, MN Always Safe Sidewalks: PA, NJ Georgia Safe Sidewalks: GA Precision Safe Sidewalks: NC, TX, VA, WV Precision Sidewalk Safety:

  • N. FL, SC

Florida Sidewalk Solutions:

  • S. FL

Precision Concrete Cutting: AL, AZ, AR, CA, CO, CT, DE, ID, IN, IA, KS, KY, LA, ME, MD, MA, MI, MS, MO, MT, NH, NM, NY, ND, OH, OK, OR, RI, SD, TN, UT, VT, WA, WY

slide-74
SLIDE 74

www.SafeSidewalks.c For more information c Matt Haney (877) 224-0025
