SLIDE 2
SLIDE 3
RECALL... HAZARDS
- Data Hazards
- Control Hazards
Dukes of Hazzard
SLIDE 4
DATA HAZARD
Hardware solution: Include forwarding paths in the machine’s datapath. Even though results have not yet reached the writeback stage, the needed information is forwarded from a pipeline register to the input of the ALU (for example).
SLIDE 5
HAZARD “DETECTION”
- Control logic inspects instruction registers used by
neighboring stages.
- eg, “If EX/MEM’s Rd = ID/EX’s Rs and EX/MEM’s Rd = ID/
EX’s Rt”
SLIDE 6
HAZARD
SLIDE 7
FORWARDING
SLIDE 8
“FORWARDING UNIT”
SLIDE 9
DATA HAZARD
Can’t always solve this w/ hardware. For example: lw followed by add
SLIDE 10
DATA HAZARD
SLIDE 11
DATA HAZARD
One solution: Rearrange the assembly instructions so the instruction following a load is not one that uses the value fetched from memory. (Pipelined loads are often called “delayed loads.”)
SLIDE 12
DATA HAZARD
What if the instructions can’t be rearranged? Then we insert a nop instruction. (“No Operation”)
SLIDE 13
NOP
0000 0000 0000 0000 0000 0000 0000 0000 (sll $0, $0, 0)
SLIDE 14
STALLING
SLIDE 15
HAZARD DETECTION
SLIDE 16
CONTROL HAZARDS
Associated with every branch/jump instruction.
SLIDE 17
ONE SOLUTION
Assume the branch is not taken. (If it is, then we must flush the instructions that have already begun flowing through the pipeline.)
SLIDE 18
AN IMPROVED SOLUTION
Determine the branch condition earlier (using additional logic circuitry.) The goal is to slightly reduce the number of “wasted” instructions (and cycles) that have entered the pipeline.
SLIDE 19
DELAY SLOT
At the assembly level, organize the instructions such that the instruction immediately following a branch instruction is a useful one.
Loop: add $t0, $t0, $v0 addi $v0, $v0, -1 bnez $v0, Loop li $v0, 4 ... Loop: addi $v0, $v0, -1 bnez $v0, Loop add $t0, $t0, $v0 li $v0, 4 ...
SLIDE 20
DYNAMIC BRANCH PREDICTION
In a nutshell: Keeping track of branch instruction histories, and consulting previous branch decisions to best predict the current one.
SLIDE 21
EXCEPTIONS
aka “Interrupts” Important when considering pipelined architectures! I/O device request Invoke the OS Overflow HW Malfunction
SLIDE 22
WHAT HAPPENS?
Save the address of the exceptional instruction (in the EPC, exception program counter). Transfer control to the OS at some specified address. OS can terminate the program or continue.
SLIDE 23
OS EXCEPTION HANDLING
- What was the reason? (MIPS uses a “cause register”)
- Which instruction was the culprit? (EPC)
SLIDE 24
EXCEPTIONS & PIPELINING
In essence, an exception is treated like a control hazard.
SLIDE 25
SLIDE 26
NEXT....
Parallelism
SLIDE 27
HOMEWORK
- Reading 30
- Project 8: “Flip
