Shipping Solution & Technology for Mini LNG Carrier Capt. Heru Prasetyo K COO of GTS Internasional The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Gas infrastructure project in Indonesia to meet growing demand SOURCE: Pertamina; Litsearch; company reports; company websites The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Type of LNG Carrier The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Mini LNG as Solution – Supply Chain Coastal LNG Terminal Liquefaction Plan FSRU LNG Shuttle LNG Shuttle Mini LNG Shuttle End User Power Plan Industry The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Mini LNG as Solution - Requirement Limitation of Ship’s Draft Mini LNG LNG Limitation of Limitation of Regulation Regulation Air Draft Carrier End User Demand in Range of 3 to 30 MMSCFD The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Mini LNG as Solution – LNG Barge as Virtual Pipeline LNG Ship FSRU Loading Loading LNG Storage Terminal Terminal LNG Barge as LNG Barge as LNG Barge as LNG Barge as Unloading Unloading Virtual Pipeline Virtual Pipeline Terminal Terminal (Regasification (Regasification TUG Onboard Barge) Onboard Barge) Gas Pipeline Power Plant (Floating) LNG Storage LNG Trucks The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology Spherical / Moss Tank Type C Tank Type C Tank Membrane Tank The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology Spherical / Moss Tank Type C Tank Type C Tank Membrane Tank The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology – Spherical / Moss Tank Advantages: � Good in stability � No restriction for level and quantity remain (for partial discharging) � No sloshing effect issue The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology Spherical / Moss Tank Type C Tank Type C Tank Membrane Tank The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology –Type C Tank Advantages: Advantages: � Type C LNG carriers do not need a liquefaction plant. � More flexible in operation: no sloshing issues, partial fillings and pressure-build-up operations are possible”. � Max. allowable tank pressure 2000 mbar The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology Spherical / Moss Tank Type-C Tank Type-C Tank Membrane Tank The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology – Membrane Tank Advantages: � Membrane system permits to design for any capacity, LNG capacities (m 3 ) 20,000 / 15,000 / 10,000 � Compact & efficient vessel design: � Best ratio of Cargo-volume vs Gross-tonnage � Low harbour and operating � Low harbour and operating costs � Safe access to restricted areas, harbours and channels � Full cargo-range: any LNG quantity can be delivered � Pressure-rise (up to 0.7 bar) can be implemented on request The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Technology – Membrane Tank Advantages: � Cargo-tank design for operational advantages: � Always adequate draught & trim conditions � Minimum ballast water requirements � Low Boil-Off rate � Cargo volume distribution with � Cargo volume distribution with full flexibility � Major advantages through Full Double hull (bottom, sides and deck): � Safe operation even in damaged situation of the double hull � No flooding of cargo hold in case of minor damage The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

A G E N D A A G E N D A Gas Projection Type of LNG Carrier Mini LNG as Solution Mini LNG as Solution Technology Conclusion The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014

Conclusion Solution for LNG Transportation • Mini LNG Carrier • LNG Barge • LNG Truck Technology for LNG Carrier • Type C Tank • Membrane Tank PT. GTS Internasional (subsidiary company of PT. Humpuss Intermoda Transportasi Tbk.) • As Reliable Partner • More than 34 years experience in LNG transportation • Surely provides best expertise and experiences seafarer to lead LNG Transportation The 7 th International Indonesian Gas Conference and Exhibition – Jakarta , 28 January 2014
