SLIDE 1
Security and Privacy Challenges in the Smart Grid
Patrick McDaniel and Stephen McLaughlin CS 598 AB Fall 2016 October 20 Presented by: Simon Kim
1
The Smart Grid
2
Security and Privacy Challenges in the Smart Grid Patrick McDaniel - - PowerPoint PPT Presentation
Security and Privacy Challenges in the Smart Grid Patrick McDaniel - - PowerPoint PPT Presentation
Security and Privacy Challenges in the Smart Grid Patrick McDaniel and Stephen McLaughlin CS 598 AB Fall 2016 October 20 Presented by: Simon Kim 1 The Smart Grid 2 The Smart Grid Modernization of the existing electrical system A
SLIDE 2
SLIDE 3
The Smart Grid
- Modernization of the existing electrical system
○
A vast network of computerized meters and infrastructure
3
SLIDE 4
Power Flow Comparison
4
http://www.slideshare.net/jhasumit/smart-grids-business-case
SLIDE 5
Information Flow Comparison
5
https://www.business.att.com/content/product/images/iot-smart-grid/smart-grid-solution-diagram-120815.png
SLIDE 6
Information Flow in Smart Grid
6
http://www.homepower.com/sites/default/files/uploads/4_HP132_pg50_Hazen-3.jpg
SLIDE 7
The Smart Grid
- Modernization of the existing electrical system
○
A vast network of computerized meters and infrastructure
- Benefits for consumers
○
More control over their energy use/utility costs ○ Improved reliability, outage response, and service convenience
- Benefits for industries
○ Time-of-use pricing (e.g. charging higher fees during peak hours) ○ Better capacity and usage planning ○ More malleable energy markets
7
SLIDE 8
Security and Privacy Concerns
8
SLIDE 9
Meter Manipulation
- Customer frauds
○ Fabricated meter readings (like meter inversion)
- False indictment
9
SLIDE 10
Network
- Bidirectional communications
- Targets include meters and infrastructure
○ Meter bots ○ DDoS
- Communication protocols
10
SLIDE 11
Shared Information
- Energy usage patterns
- Google PowerMeter Service
○ Unclear laws, regulations, and guidelines
11
SLIDE 12
Current State of Smart Grids (Ameren)
- Upgrades in progress
○ “By 2019, more than half (62%) of electric customers will receive [smart] meters”
- Daily usage reports and time-of-use (real-time) pricing option available
- Still rely on meter reading in-person
12
SLIDE 13
Future of Smart Grids
- Long-term vision
○ Global energy management ○ Home area networks that can control smart appliances
13
SLIDE 14
What Now
- Laws, regulations, consumer protections
- More studies to mitigate the concerns
○ Approaches suitable for critical systems
- Plan for failure
○ Resilience ○ Reliability
14
SLIDE 15
Discussion
- Does the smart grid increase resilience to system failures and cyber
physical attacks?
- The smart grid is going to happen. But what about the long-term goals of
the smart grid? Are they realistic? Should we prepare defense strategies? Or do we need more realistic goals?
- Any other security and privacy concerns?
15
