Section 7: Lab 2 & Authentication CSE 484 / CSE M 584 - - PowerPoint PPT Presentation

▶
section 7 lab 2 authentication
SMART_READER_LITE
LIVE PREVIEW

Section 7: Lab 2 & Authentication CSE 484 / CSE M 584 - - PowerPoint PPT Presentation

Mar 29, 2023 527 likes •873 views

Section 7: Lab 2 & Authentication CSE 484 / CSE M 584 Administrivia May 15 th May 25 th Final Project Checkpoint 1 Due @ Memorial Day: No Lecture 11:59pm Lab 2 Due @ 11:59pm Homework 3 Due @ 11:59pm May 22 nd May 29 th More Lab 2 Hints

slide-1
SLIDE 1

Section 7: Lab 2 & Authentication

CSE 484 / CSE M 584

slide-2
SLIDE 2

Administrivia

Final Project Checkpoint 1 Due @ 11:59pm

May 15th

Lab 2 Due @ 11:59pm

May 22nd

Memorial Day: No Lecture

May 25th

Homework 3 Due @ 11:59pm

May 29th

slide-3
SLIDE 3

More Lab 2 Hints

slide-4
SLIDE 4

Lab 2 Hints: Web Requests

There are usually multiple ways to do the XSS exploits!

  • Example: In Problem 1, window.open may fail because of popup

blocking

  • What other JavaScript APIs or HTML elements can cause a web

request from a page?

slide-5
SLIDE 5

There are different ways to run JS on a page:

Inline JS

(event handlers as strings inside HTML tags, <script> tags with embedded JS)

External JS files

(attached <script> with src in HTML <head> or <body>)

Extensions

(not in Lab 2, but becoming very popular for web users)

From the console

(mostly for testing, doesn’t save state on page refresh) You don’t need to know all of them for Lab 2, but you will need to use different approaches for different filters!

slide-6
SLIDE 6

Lab 2 Hints: Executing JS

Mixing HTML, JavaScript and URLs… which syntax are you using?

<script> alert('hi'); </script> <body onload="alert('hi');"></body> <iframe src="example.com/?id=<script>alert('hi');</script>"/>

HTML JavaScript For event handler attributes, the value is interpreted as JavaScript code and inserted into a function:

> console.log(myImg.onload.toString()); "function onload(e) { alert('hi'); }"

This is a URL which means it must be URL encoded This is JS embedded in a URL Because the URL is loaded in an iframe, the code will be executed in the context of the page within the iframe (if it has an XSS vulnerability) Will this iframe execute the script? Which language’s escape characters do we need to use?

slide-7
SLIDE 7

Lab 2 Hints: Encoding Schemes

Text can be encoded in different forms on web pages. Why do you think this is useful? See XSS Intro resource for a great overview of different schemes

slide-8
SLIDE 8

Lab 2 Hints: SQL

Recall that SQL is a language used to manage and query databases Each database contains tables of data. The SELECT keyword is used to query tables and retrieve data. What can possibly go wrong? CREATE TABLE students ( id int, name varchar(255) ); INSERT INTO students VALUES (1, 'Sam Wolfson'); SELECT * FROM students WHERE id = 1; DELETE FROM students WHERE id = 1; OR 1 = 1; -- ;

slide-9
SLIDE 9

Authentication

slide-10
SLIDE 10

Improving (?) Passwords

  • For example, keystroke dynamics or voiceprint

Add biometrics

  • Goal: easier to remember? no need to write down?

Graphical passwords

  • Examples: LastPass, KeePass, etc. (built into

browsers)

  • Can have security vulnerabilities…

Password managers

  • Leverage phone (or other device for authentication)

Two-factor authentication

slide-11
SLIDE 11

Password Manager Vulnerabilities

Automatic autofill (a feature

  • f many password

managers) is convenient, but hard to make secure Subject to sweep attacks: stealing multiple passwords without user interaction

https://www.usenix.org/node/184476

slide-12
SLIDE 12

Redirect Sweep Attack Demo

https://www.youtube.com/watch?v=qiiSuIE79No

slide-13
SLIDE 13

Defenses Against Sweep Attacks

Manual autofill (as secure as manual entry)

  • Don’t let JavaScript read autofilled passwords
  • Site must submit form using HTTPS
  • Let form submit only if action matches action when

password was saved Secure filling (more secure than manual entry)

slide-14
SLIDE 14

Two-factor Authentication

To log in, you need to provide your credentials, and something else Examples of 2nd factors:

  • Security questions
  • Text, phone call, or email with temporary code
  • Software or physical temporary code generator
  • USB security key
slide-15
SLIDE 15

2FA Poll!

Poll: have you turned on 2-factor authentication for any of your accounts?

A: Yes, whenever the option is available. B: Yes, if the website directly asks me to do so. C: Yes, but only for important accounts. D: Yes, but only when I’m forced to. E: No. Vote at: https://pollev.com/wolfson

slide-16
SLIDE 16

Software-Based 2FA

slide-17
SLIDE 17

Hardware-Based 2FA

  • USB authentication devices
  • Private key is stored on the security key, public key is

stored by the website

  • Challenge response protocol: website sends a challenge

(a string), security key signs it with the private key, website verifies the signature with the public key

  • More secure than temporary codes: one private key per

account, only signs the challenge if it’s on the correct domain (Codes can be phished!)

slide-18
SLIDE 18

Security Keys Aren’t Perfect…

Hardware/firmware bugs can compromise its security In theory: supply chain attacks - introduce backdoor vulnerabilities in the factory/in transit

slide-19
SLIDE 19

Secondary Factors Do Help!

https://security.googleblog.com/2019/05/new-research-how-effective-is-basic.html

slide-20
SLIDE 20

Could We Replace Passwords?

Passwords have many weaknesses

  • Phishing, brute force guessing, password database dumps, password reuse, etc.

Do better systems exist? What other authentication heuristics do we have? Any replacement would ideally be better than passwords in the areas of:

  • Usability: easy-to-learn, efficient-to-use, web compatible
  • Deployment: accessible, negligible cost
  • Security: resilient to phishing, resilient to theft, hard to observe/imitate
slide-21
SLIDE 21

Graphical Passwords

Many variants… One example: Passfaces

  • Assumption: easy to recall faces

Problem: to make passwords easy to remember, users choose predictable faces

slide-22
SLIDE 22

Graphical Passwords

Another variant: draw on the image (Windows 8) Problem: to make drawing easy to remember, users choose predictable points/lines

slide-23
SLIDE 23

Unlock Patterns

Problems:

  • Predictable patterns (sound familiar by now??)
  • Smear patterns
  • Side channels: apps can use accelerometer and

gyroscope to extract pattern!

slide-24
SLIDE 24

What about Biometrics?

Authentication: What you are

Unique identifying characteristics to authenticate user or create credentials

  • Fingerprints
  • Iris scan
  • Facial recognition
  • Behavior characteristics (how one

performs actions): handwriting, typing, gait, etc.

  • Voice recognition
  • DNA profiling
  • Electroencephalogram (EEG) signatures
slide-25
SLIDE 25

Advantages of Biometrics

Nothing to remember Passive Can’t share (generally) With perfect accuracy, could be fairly unique

slide-26
SLIDE 26

What are some disadvantages with biometrics?

slide-27
SLIDE 27

Issues with Biometrics

Private, but not secret

  • Maybe encoded on the back of an ID card?
  • Maybe encoded on your glass, door handle, ...
  • Sharing between multiple systems?

Revocation is difficult (impossible?)

  • Sorry, your iris has been compromised, please create a new one...

Physically identifying

  • Soda machine to cross-reference fingerprint with DMV?

Birthday paradox

  • With false accept rate of 1 in a million, probability of false match is above 50% with only 1609 samples

Legal implications

  • Biometrics not protected by 4th amendment
slide-28
SLIDE 28

Risks with Biometrics

slide-29
SLIDE 29

Attacking Biometrics

An adversary might try to steal biometric info

  • Malicious fingerprint reader
  • Consider when biometric is used to derive a cryptographic key
  • Residual fingerprint on a glass

Example: Apple’s Touch ID

slide-30
SLIDE 30

Attacking Biometrics

[Starbug -- http://istouchidhackedyet.com/]

slide-31
SLIDE 31

Attacking Biometrics

[Starbug -- http://istouchidhackedyet.com/]

slide-32
SLIDE 32

Apple Face ID Vulnerabilities

slide-33
SLIDE 33

Good luck with everything!
