SDC DB Support for Distributed Computing PanDAMon Integration in CMS Workshop on Analysis Tools Development May 16 th 2013 Nicol Magini CERN IT-SDC-OL CERN IT Department CH-1211 Geneva 23 date Author etc Switzerland www.cern.ch/i t

SLIDE 1

Support for Distributed Computing

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

DB SDC

Author etc

PanDAMon Integration in CMS

Workshop on Analysis Tools Development May 16th 2013 Nicolò Magini CERN IT-SDC-OL

date

SLIDE 2

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

2 Author etc 2013-05-16

Outline

Status after the prototype
Current status of the testbed deployment
Plans for the integration testbed
Next steps

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 3

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

3 Author etc 2013-05-16

Monitoring of PanDA jobs

Reminder: “Monitoring of jobs in PanDA” is

more than “PanDA Monitor”

ATLAS ops and users take advantage of

Dashboard (populated from PanDA DB) to complement PanDA Monitor, especially for

– Task monitoring – Historical view

Here I’m going to look only at the

“PanDA Monitor” itself, in particular for job debugging

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 4

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

4 Author etc 2013-05-16

PanDAMon for the prototype

Using ATLAS PanDA Monitor as-is, with

minimal updates by V. Fine (ATLAS PanDAMon developer) to make it functional for CMS jobs

Already working successfully by CMS power

users in proof of concept phase

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 5

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

5 Author etc 2013-05-16

PanDAMon for the prototype

viewlogfiles: perform LFN2PFN conversion with PhEDEx

datasvc to find log file location (instead of looking up in central ATLAS catalog) – Recently had an issue with logfile retrieval, now fixed by V. Fine

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 6

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

6 Author etc 2013-05-16

Testbed deployment

Additional 2 core, 8 GB VM could be useful as PanDA Mon

“development instance” to test deployment and new modules

vocms09 Panda Mon (varnish) SLC6 LB Preslav VM 2 cores, 8 GB mem, 500 GB disk prototype vocms35 Panda Mon (varnish) SLC6 LB Preslav VM 2 cores, 8 GB mem, 500 GB disk prototype vocms33 Panda Mon SLC6 - power node LB Preslav 23-JAN-14 24 cores, 32 GB mem, 2x750 GB disk prototype vocms100 Panda Mon SLC6 LB (temporary node, this is the ASO spare) Preslav 27-JAN-14 8 cores, 24 GB mem, 3x1TB disk spare Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 7

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

7 Author etc 2013-05-16

Testbed status

Basic quattor configuration performed by

VOC on all machines following ATLAS templates

Now in contact with ATLAS Distributed

Computing operators for software deployment and configuration procedures

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 8

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

8 Author etc 2013-05-16

PanDAMon testbed goals

During testbed phase

– Reproduce working PanDA Monitor setup from prototype phase in CMS instance – Identify “ATLAS” assumptions in monitoring, assess usability for CMS

Some examples found by developers in job debugging

views reported in the following

More surely to be found by CMS ops and users, will

gather feedback

– Produce new PandaMon custom modules for CMS integration for items not covered by current PanDAMon or Dashboard

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 9

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

9 Author etc 2013-05-16

Navigation

A lot of information on the website is

aggregated by cloud

For CMS, more useful to look at sites rather

than clouds?

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 10

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

10 Author etc 2013-05-16

Dataset info

Dataset info linking to DQ2

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 11

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

11 Author etc 2013-05-16

Dataset info

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

Need to update to link to DAS/DBS

SLIDE 12

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

12 Author etc 2013-05-16

Task monitoring

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

Linked to ATLAS Task Monitoring
Integrate with CMS Task Monitoring

SLIDE 13

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

13 Author etc 2013-05-16

Output file links

Links to log and output file locations working in “viewlogfile”

page, need to fix in “findfile“

(do we want to update output location in PanDA DB from

/store/temp/user to /store/user after ASO?)

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 14

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

14 Author etc 2013-05-16

Error reporting

ASO failures reported to DB and visible in

monitoring but not in “Error details”

CMS transformation (job wrapper) exit code

visible in PanDAMon, but not detailed error message - includes cmsRun messages

Update links to support mail…

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL

SLIDE 15

CERN IT Department CH-1211 Geneva 23 Switzerland

www.cern.ch/it

SDC

15 Author etc 2013-05-16

Next steps

Next week: deploy PanDAMon as-is on dev

server in testbed setup

When testbed setup is ready, start looking

into reported issues

Interact with PanDAMon developers to learn

how to integrate new modules if needed by CMS

– First session already done

Reproduce deployment on prod server

Workshop on Analysis Tools Nicolò Magini CERN IT-SDC-OL
