SCOI ACI/MACI Where Are We At? SCOI ACI/MACI The following relations exists Royalties and stock options Smith and Nephew, Wolters Kluwer Consulting income Smith and Nephew, Geistlich, Ossur, Cannuflow Research and educational

SLIDE 1

SCOI

SLIDE 2

SCOI

ACI/MACI

Where Are We At?

SLIDE 3

SCOI

ACI/MACI

The following relations exists

Royalties and stock options – Smith and Nephew, Wolters Kluwer Consulting income – Smith and Nephew, Geistlich, Ossur, Cannuflow Research and educational support – Mitek, Smith & Nephew & Arthrex

SLIDE 4

SCOI

Treatment Options for Cartilage Defects

< 1 cm2

Debridement Drilling MicroFracture

2.5 - 4 cm2

Drilling Osteochondral Transplants ACI Allografts Juvenile Allografts Micronized Cartilage Matrix Focal Resurfacing Replacement

1 - 2.5 cm2

Debridement Drilling MicroFracture Osteochondral Transplants ACI Allografts Juvenile Allografts Micronized Cartilage Focal Resurfacing Replacement

SLIDE 5

SCOI

SLIDE 6

SCOI

Indications for ACI in the Ankle

Patients Aged 15 – 55 Focal Defect > 1 cm2 Unipolar (Only Talus) Contained Edge Loading Failed Previous Surgery Large Lesions with Subchondral Cystic Changes in Primary Cases

SLIDE 7

SCOI

ACI – MM Osteotomy

Incision Over Medial Malleolus and Expose Anterior & Posterior Avoid Injury to N-V Structures & Tendons Using Fluro, Place Guide Pin over Bone at Correct Osteotomy Site and Mark with Methylene Blue Predrill Two Oblique Cannulated Screw Holes Prior to Osteotomy

SLIDE 8

SCOI

Use Guide Pin & Fluro to Mark Osteotomy Osteotomy Plane Orientated to Allow Two Interfrag. Screws + Plate & Exits at Syndesmosis Pre-Drill Interfrag. Screw Holes

Technique for OFO

SLIDE 9

SCOI

Chondro-Gide

Chondro-Gide is a Porcine Type I/III Collagen Membrane (Matrix) Bilayer Matrix With One Compact (Smooth) and One Porous Surface Membrane Takes the Place of Periosteum Used for ACI-C (CACI) and AMIC as a Patch Sold in USA as Bio-Gide Currently Being Used Instead of Periosteum

SLIDE 10

SCOI

Bio-Gide Collagen Membrane

Type I/III Bilayer Porcine Collagen Membrane Gomoll et al. Compared Subsequent Surgeries After ACI-P & ACI-C (Bio-Gide) in Knee Results Similar Except Hypertrophy Related Surgery ACI –P = 26% ACI-C = 5.0%

AJSM 37:20S, 2009

SLIDE 11

SCOI

ACI – Defect Preparation

Incise Lesion Vertically and Remove All Damaged Cartilage From Subchondral Bone Make 90º, Sharp Walls B/N Defect and Healthy Cartilage

SLIDE 12

SCOI

ACI Membrane Implantation

Membrane is Implanted and Secured With 6-0 Vicryl to OLT Bed Fibrin Glue is Used to Seal the Membrane “Water Tight” Except a Hole is Left for Cell Insertion

SLIDE 13

SCOI

ACI Cell Implantation

Insert Catheter Through Opening in Membrane Slowly Inject Cells Suture Remaining Hole in Membrane Seal Hole With Fibrin Glue

SLIDE 14

SCOI

ACI “Sandwich” Bone Grafting

CYST

SLIDE 15

SCOI

Rehabilitation

Initially Short Leg Cast NWB At Two Weeks, Stitches Out and Start 30lbs WB In CAM Boot for 4 Weeks At Six Weeks, Progress to FWB and Start Phase I P.T.

SLIDE 16

SCOI

ACI Results - Ferkel (2014)

32 Patients Total

Male = 16; Female = 16 Medial = 24; Lateral = 8 32/32 = Previous Surgery Current Study: F/U 29/32 = 91%

Ave. Age = 34 (18-54)
Ave. F/U = 70 Mos (24-129)

“Sandwich” Procedures = 9 2nd Look = 90% (26/29)

Excell. = 8, Good = 15, Fair = 5

Poor = 1

AJSM, 42:2156, 2014

SLIDE 17

SCOI

ACI Results in Ankle

Giannini et al. (2014) Developed an Arthroscopic ACI Procedure 46 pts. Had the Procedure With Mean Age = 31 Mean Follow up: 7 + 1.2 yrs Pre-op AOFAS = 57, Post-op AOFAS = 92 Failures = 3

KSSTA 22:1311, 2014

SLIDE 18

SCOI

ACI - Pearls

Adequate Osteotomy Excise All Diseased Tissue Bone Graft Deep Cysts When Suturing Periosteum/Membrane, Grasp 4-5 mm Into Normal Cartilage Seal Graft Completely Correct Associated Instability Rigid Fixation of Osteotomy

SLIDE 19

SCOI

MACI Scaffold

Matrix Induced ACI Biocomposite With Highly Purified Bioresorbable Type I-III Collagen Membrane Supporting ACI Launched in 2000 in Europe and Australia with 3200 Pts Treated Vericel Acquired Genzyme & is Developing MACI in US

Courtesy of Eric Giza, MD

SLIDE 20

SCOI

MACI Scaffold

Remove Osteochondral Lesion Size Defect Apply MACI with Fibrin Glue

Courtesy of Prof. Pedro Guillen Garcia

SLIDE 21

SCOI

MACI Case Study

37 y/o Female Who Suffered FX-

Disl. Left Ankle During Roller

Derby Match on 9-1-14 She Had ORIF by PMD and Healed With Pain OLT Noted and Scope Debridement and MicroFX by PMD Without Help 8-2015 Pt Had Scope Knee & Ankle + ACI Biopsy MACI Was Done With Excision of OLT & Cyst. ICBG Insert With Sandwich Procedure = MACI

SLIDE 22

SCOI

MACI Case Study – Pre op CT

SLIDE 23

SCOI

MACI Case Study

1 2 3 4 5 6

SLIDE 24

SCOI

MACI Case Study

7 8 9 10 11 12

SLIDE 25

SCOI

MACI Case Study

13 14 15 16 17 18 19 20 21

SLIDE 26

SCOI

MACI

Aurich et al (2011) – Studied 18 Pts With Scope MACI Used Arthrometrix Woven Tissue SCORES Pre Post

FFI Pain 5.5 2.8 FFI Disability 5.0 2.6 AOFAS 59 80

Excellent – Good 64% 81% Returned to Sports

AJSM 39:311, 2011

SLIDE 27

SCOI

OLT Ankle - Summary

Newer Technology Shows Positive Early Results But More Cases With Longer F/U Needed

Max. Clinical & Histological

Results at 24 mos. Or Longer Future – Scaffolds, Stems Cells, Growth Factors, ? Solution is Within Our Grasp and Must Be Done Arthroscopically Stepwise Evolution of Concepts and Science

Cartilage Solution

SLIDE 28

SCOI

ACI/MACI Treatment

International Consensus Meeting

n Cartilage Repair of the Ankle

Nov 17-18, 2017, Pittsburgh, PA

Significant Recommendations for Treatment of OLTs Publications Coming Early 2018

SLIDE 29

SCOI

T H A N K

ACI/MACI

Where Are We At?

Y O U
