SANREMO PRESENTATION COMPANY PROFILE More than twenty years of experience in the production of Espresso Coffee Machines, allow our company SANREMO to propose itself as one of the worldwide leaders in the espresso machines market. All the

slide-1
SLIDE 1

SANREMO PRESENTATION

slide-2
SLIDE 2

More than twenty years of experience in the production of Espresso Coffee Machines, allow our company SANREMO to propose itself as one of the worldwide leaders in the espresso machines market. All the Sanremo professional espresso coffee machines are the results of design projects entirely carried out by a skillful team of technicians and designers highly motivated and trustworthy within the company. Sanremo’s philosophy and success are based on passion and focus on the detail clearly visible on the aesthetic lines of our models which make them a unique piece of interior design appealing in all the baristas and coffee shops that use Sanremo’s quality products. Sanremo’s quality covers the entire production cycle: from the designing and technical planning to the models’ series production. Our commitment to product quality goes so far that each machine is tested two times before leaving the factory to insure that they are true precision instruments worthy

  • f the Sanremo name. These main features of innovation and high standard

performances are the fundamental core of the success of our models. Our commercial network, not only present in the Italian area, but also worldwide, allow us to constantly and efficiently assist the final clients. Throughout the years Sanremo aimed to strengthen its distribution network increasing its customer service and always providing a careful assistance on-site. A developed network of distributors and direct branches in different areas (Europe, United States, Mexico, Australia) guarantees constant support and attentive care of transferring the necessary abilities. Throughout the years Sanremo has developed its own “training school” where we deepen and teach the most update techniques to obtain an espresso and cappuccino of optimum quality. Every year we participate worldwide, directly or indirectly, at over thirty international exhibitions in collaboration with well-known Roasters to contribute to spread the culture of the Italian Espresso. SANREMO S.r.l Marketing Manager

  • C. de Sordi

COMPANY PROFILE

slide-3
SLIDE 3

9 2 3 4 5 1 8 7 6

Elements:

  • 1. Cold water entrance
  • 2. Hot water return
  • 3. Heating element
  • 4. Hot water
  • 5. Steam
  • 6. Steam withdrawal

7 . Hot water flow

  • 8. Water flow to supply coffee
  • 9. Filter
  • 10. Temperature drill
  • 11. Level drill
  • 12. Safety valve

TRADITIONAL TECHNICAL SYSTEM

10 12 11

slide-4
SLIDE 4

ADVANTAGES OF THE TCS SYSTEM:

  • according to the different requirement of each blend of coffee
  • coming directly from the water line, and so without taking the boiler’s

backwater as in the traditional system

  • done at the same time without interfering with one another
  • the TCS system, in fact there is a maximum temperature shift that
  • so reduced technical services
  • and leaving the other open to work
  • which works through second fraction pulses that guarantees maximum

precision of the desired temperature. While in the traditional system

  • Elements:
  • 1. Cold water entrance
  • 2. Boiler heating element
  • 3. Hot water
  • 4. Hot water return
  • 5. Hot water flow
  • 6. Water flow to supply coffee

7 . Filter

  • 8. Entrance of clean, cold water coming

from the water network

  • 9. Boiler’s heating element
  • 10. Hot water and steam boiler
  • 11. Hot water exit
  • 12. Steam withdrawal
  • 13. Steam
  • 14. Hot water

7 2 3 1 4 6 5

TEMPERATURE CONTROL SYSTEM

94,5

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

94,7 94,9 95,1 95,3 95,5 95,7

12 11 8 9 10 13 14

Obtained Temp °C Group 1 Set up Temp °C Group 1

slide-5
SLIDE 5

SED - TCS Features

  • Built-in volumetric pump
  • electronically
  • Copper boiler and pipes
  • Single double-scale pressure gauge
  • Boiler level indicator
  • Adjustable feet
  • Manual safety circuit
  • Cup heater

On request

  • Auto steam
  • External volumetric pump

2 groups 3 groups width mm - inch 850 - 33'' 1080 - 42'' coffee heating element power kW 2 3 depth mm - inch 560 - 22'' 560 - 22'' heating element kW 2,7 2,7 height mm - inch 510 - 21'' 510 - 21'' power pump W 150 165 voltage V 230-400 230-400 gross weight kg 94 - 206’’ 117 - 257’’ steam boiler capacity lt 8,6 8,6 supplying tea exchang. capacity lt 0,6 0,6 coffee boiler capacity lt 0,56 0,84 power kW 4,7 5,7

2-Units TCS

With 2 steam taps

  • 3-Units TCS

With 2 steam taps

slide-6
SLIDE 6

width mm - inch 820 - 32'' 1020 - 40'' boiler heating element power kW 2,7 2,7 depth mm - inch 610 - 24'' 610 - 24'' coffee heating element power kW 2 3 height mm - inch 590 - 23'' 590 - 23'' power pump W 150 165 voltage V 230-400 230-400 gross weight kg 74 - 162’’ 91 - 200’’ steam boiler capacity lt 8,6 14 supplying tea exchang. capacity lt 0,6 0,9 coffee boiler capacity lt 0,56 0,84 power kW 4,7 5,7

SED - TCS Features

  • Built-in volumetric pump
  • electronically
  • Copper boiler and pipes
  • Single double-scale pressure gauge
  • Boiler level indicator
  • Adjustable feet
  • Manual safety circuit
  • Cup heater

On request

  • Auto steam
  • External volumetric pump

2-Units TCS

With 2 steam taps

  • 3-Units TCS

With 2 steam taps

  • 2 groups 3 groups
slide-7
SLIDE 7

width mm - inch 820 - 32'' 1020 - 40'' depth mm - inch 610 - 24'' 610 - 24'' height mm - inch 590 - 23'' 590 - 23'' voltage V 230-400 230-400 heating-element kW 2,7/4,5 5,1 power pump W 150 165 gross weight kg 74 - 162'' 91 - 200''

SED-SAP Features

  • Built-in volumetric pump
  • Copper boiler and pipes
  • Single double-scale pressure gauge
  • Boiler level indicator
  • Adjustable feet
  • Manual safety circuit
  • Cup heater

On request

  • Auto steam
  • External volumetric pump

2 groups 3 groups

slide-8
SLIDE 8

TA LL

width mm - inch 820 - 32'' 1020 - 40'' boiler heating element power kW 2,7 2,7 depth mm - inch 610 - 24'' 610 - 24'' coffee heating element power kW 2 3 height mm - inch 652 - 25'' 650 - 25'' power pump W 150 165 voltage V 230-400 230-400 gross weight kg 82 - 180’’ 101 - 222’’ steam boiler capacity lt 8,6 14 supplying tea exchang. capacity lt 0,6 0,9 coffee boiler capacity lt 0,56 0,84 power kW 4,7 5,7

SED Features

  • Built-in volumetric pump
  • Copper boiler and pipes
  • Single double-scale pressure gauge
  • Boiler level indicator
  • Adjustable feet
  • Manual safety circuit
  • Cup heater

On request

  • Auto steam
  • External volumetric pump

2 groups 3 groups

slide-9
SLIDE 9

TA LL

width mm - inch 820 - 32'' 1020 - 40'' boiler heating element power kW 2,7 2,7 depth mm - inch 610 - 24'' 610 - 24'' coffee heating element power kW 2 3 height mm - inch 650 - 25'' 650 - 25'' power pump W 150 165 voltage V 230-400 230-400 gross weight kg 82 - 180’’ 101 - 222’’ steam boiler capacity lt 8,6 14 supplying tea exchang. capacity lt 0,6 0,9 coffee boiler capacity lt 0,56 0,84 power kW 4,7 5,7

SED Features

  • Built-in volumetric pump
  • Copper boiler and pipes
  • Single double-scale pressure gauge
  • Boiler level indicator
  • Adjustable feet
  • Manual safety circuit
  • Cup heater

On request

  • Auto steam
  • External volumetric pump

auto steam

2 groups 3 groups

slide-10
SLIDE 10

SED - SAP Features

  • Incorpored motor pump
  • Copper boiled and piping
  • One double-scale pressure gauge
  • Boiler level indicator
  • Manual safety circuit
  • Sight glass

On request

  • External motor pump
  • Cup heater

2-Units SED - SAP

With 2 steam taps

  • 2-cup filter holder

3-Units SED - SAP

With 2 steam taps

  • 2-cup filter holder

width mm - inch 820 - 27'' 950 - 37'' depth mm - inch 540 - 21'' 540 - 21'' height mm - inch 535 - 21'' 535 - 21'' voltage V 230-400 230-400 boiler capacity lt 12 19 power W 2,7/4,5 5,1 power pump W 150 165 gross weight kg 64 - 140’’ 85 - 187’’ 2 groups 3 groups

slide-11
SLIDE 11

SED - SAP Features

  • Built-in volumetric pump
  • Copper boiled and piping
  • One double-scale pressure gauge
  • Electronic automatic level

On request

  • Version with electronic coffee counter
  • Cup heater
  • External volumetric pump

2-Units SED - SAP

With 2 steam taps

  • 2-cup filter holder

3-Units SED - SAP

With 2 steam taps

  • 2-cup filter holder

width mm - inch 640 - 32'' 870 - 40'' depth mm - inch 500 - 24'' 500 - 24'' height mm - inch 535 - 23'' 535 - 23'' voltage V 230-400 230-400 boiler capacity Lt 8,6 14 power kW 2,7/4,5 5,1 power pump W 150 165 gross weight kg 61 - 162’’ 79 - 200’’ 2 groups 3 groups

slide-12
SLIDE 12

SED - SAP Features

  • Built-in volumetric pump
  • Copper boiled and piping
  • One double-scale pressure gauge
  • Electronic automatic level
  • Electronic pre-infusion

(can be deactivated)

On request

  • Version with electronic coffee counter

width mm - inch 425 - 16'' 590 - 23'' depth mm - inch 485 - 18'' 485 - 18'' height mm - inch 535 - 21'' 535 - 21'' voltage V 230-400 230-400 boiler capacity lt 4,5 8,6 power W 1,95/2,4 2,7/4,5 power pump W 150 150 gross weight kg 41 - 90’’ 53 - 116’’ 1 group 3 groups

slide-13
SLIDE 13

SR50 SR70 SR80

Features

  • Continuous micrometric

grinding regulation

  • Available in automatic

and manual versions

  • Grinding regulation with graduated ring
  • With counter

width mm - inch 230 - 9'' 230 - 9'' 160 - 6’’ depth mm - inch 270 - 10'' 270 - 10'' 290 - 11’’ height mm - inch 610 - 24'' 610 - 24'' 510 - 20’’ voltage V 230 230 230 bell housing capacity kg 1,5 1,5 1,5 level gridwheels 0 mm 64 64 63,5 power W 350 350 350 quantity idjustment gr 5,5 - 8 / 4 - 8,5 rpm (50Hz) min 1350 1350 1400 rpm (60Hz) min 1550 1550 1580 net weight kg 14 14 10,50

FITTINGS FOR ESPRESSO COFFEE MACHINES

GRINDERS SR50 GRINDERS SR70 GRINDERS SR80

slide-14
SLIDE 14

Features

  • Simple operation with large graphic

display

  • Integrated grinder for finely

ground coffee

  • Micro-fine sieve for more aroma

from less coffee

  • Maximum quality ensured by variable

pressure for each coffee speciality

  • Two bean container for different blends
  • Automatic milk frother for fresh milk
  • Access via multi-level chip key system
  • Automatic cleaning system
  • hygiene standard

hot water 1 width mm - inch 560 - 22'' steam

  • depth

mm - inch 500 - 19'' milk frother yes height mm - inch 590 - 23'' cappuccino 90 grinder (G) 2 hot water: litres/hr. 25 capacity power consuption in kW 2,8 hourly output in no. of cups electrical connection (V) 230 Option: bar sub-frame Refrigerator 560 mm 280 mm 800 mm 465 mm coffee crème/Schümli 100 espresso 150

SR 1000

1W-2G

slide-15
SLIDE 15

Hourly performance: approx. 180, cups dependingon product and volume of each drink Hourly performance:

  • approx. 80/100 cups
  • ptional: 2nd grinder, bean hopper 2 = 1,4 kg

electrical: 110 V / 0,15 kW ca. istant container - chocolate powder/decaf. coffee = 1,3 kg empty: 17 kg istant container - milk powder = 1,3 kg measurements: (W - D - H) 300 X 350 X 770 mm 11" X 13" X 30" inch

  • utlet height: mm - inch 135 - 5" inch/with cup table: 80 - 3" inch

measurements: mm - inch 400 - 15"wide, 519 - 20"deep, 790 - 31"high water connection: R 3/4 / DN 10 minimumheightrequired to refill the machine: mm - inch 400 - 15" waste-water connection: DN 15 empty weght: 52/56 kg

  • ptional water-filter: Everpure/Brita

electrical connection: 110 V / 50 Hz; 2,9 Kw

SR 2000

reddot design award

winner 2003

slide-16
SLIDE 16

SANREMO s.r.l. Via Bortolan, 52 Zona Industriale Treviso Nord 31050 Vascon di Carbonera (Tv)

  • tel. +39 0422 448900

fax +39 0422 448935 info@sanremomachines.com www.sanremomachines.com
