Salt A Scalable Systems Management Solution for Datacenters Open Source Data Center Conference April 26-28, 2016 Sebastian Meyer Linux Consultant & Trainer B1 Systems GmbH meyer@b1-systems.de B1 Systems GmbH - Linux/Open Source

slide-1
SLIDE 1

Salt – A Scalable Systems Management Solution for Datacenters

Open Source Data Center Conference April 26-28, 2016

Sebastian Meyer Linux Consultant & Trainer B1 Systems GmbH meyer@b1-systems.de

B1 Systems GmbH - Linux/Open Source Consulting, Training, Support & Development

slide-2
SLIDE 2

Introducing B1 Systems

founded in 2004

  • perating both nationally and internationally

nearly 100 employees provider for IBM, SUSE, Oracle & HP vendor-independent (hardware and software) focus:

consulting support development training

  • perations

solutions

B1 Systems GmbH Salt – Scalable Systems Management 2 / 47

slide-3
SLIDE 3

Areas of Expertise

B1 Systems GmbH Salt – Scalable Systems Management 3 / 47

slide-4
SLIDE 4

Salt – Introduction

B1 Systems GmbH Salt – Scalable Systems Management 4 / 47

slide-5
SLIDE 5

Yet Another Systems Management Solution?

takes inspiration from Puppet, Chef or Ansible focuses on the entire system life cycle easily scalable to a few thousand systems convenient and easy to learn configuration management and remote execution

B1 Systems GmbH Salt – Scalable Systems Management 5 / 47

slide-6
SLIDE 6

Salt – Concept

B1 Systems GmbH Salt – Scalable Systems Management 6 / 47

slide-7
SLIDE 7

Master & Minions

B1 Systems GmbH Salt – Scalable Systems Management 7 / 47

slide-8
SLIDE 8

Scalability: Masters, Syndics & Minions

B1 Systems GmbH Salt – Scalable Systems Management 8 / 47

slide-9
SLIDE 9

High Availability: Multiple Masters& Minions

B1 Systems GmbH Salt – Scalable Systems Management 9 / 47

slide-10
SLIDE 10

Salt Modes

minions pull from master master pushes to Minions minions apply states locally master applies states on minions via SSH

B1 Systems GmbH Salt – Scalable Systems Management 10 / 47

slide-11
SLIDE 11

Remote Execution System

B1 Systems GmbH Salt – Scalable Systems Management 11 / 47

slide-12
SLIDE 12

Salt Command

B1 Systems GmbH Salt – Scalable Systems Management 12 / 47

slide-13
SLIDE 13

Grains

B1 Systems GmbH Salt – Scalable Systems Management 13 / 47

slide-14
SLIDE 14

Configuration Management

B1 Systems GmbH Salt – Scalable Systems Management 14 / 47

slide-15
SLIDE 15

States

ID: module.function:

  • name: name
  • argument1: value
  • argument2:
  • value1
  • value2

B1 Systems GmbH Salt – Scalable Systems Management 15 / 47

slide-16
SLIDE 16

Top File

base: ’*’:

  • monitoring
  • ssh
  • syslog

’*lan*’:

  • ntp.lan

’*dmz*’:

  • ntp.dmz
  • firewall

all servers:

monitoring ssh config syslog

servers in LAN:

ntp config

servers in DMZ:

ntp config firewall

B1 Systems GmbH Salt – Scalable Systems Management 16 / 47

slide-17
SLIDE 17

Pillars

B1 Systems GmbH Salt – Scalable Systems Management 17 / 47

slide-18
SLIDE 18

Pillar Data

Pillar Example

ntp: {% if grains[’id’].startswith(’myntpserver’) %} ntpservers: ["0.us.pool.ntp.org","1.us.pool.ntp.org"] comment: ’’ {% else %} ntpservers: ["10.1.1.20","10.1.1.21"] comment: ’myinternalservers’ {% endif %}

Source: https://github.com/saltstack-formulas/ntp-formula/blob/master/pillar.example B1 Systems GmbH Salt – Scalable Systems Management 18 / 47

slide-19
SLIDE 19

Pillars and States

States top.sls

base: ’*’:

  • monitoring
  • ssh
  • syslog
  • ntp

’*dmz*’:

  • firewall

Pillar top.sls

base: ’*’:

  • monitoring
  • ssh
  • syslog

’*lan*’:

  • ntp.lan

’*dmz*’:

  • ntp.dmz
  • firewall

B1 Systems GmbH Salt – Scalable Systems Management 19 / 47

slide-20
SLIDE 20

Deploying the State

Master pushes to minions

salt ’*’ state.highstate salt ’*’ state.sls mystate

Minions pull from master

salt-call state.highstate salt-call state.sls mystate

B1 Systems GmbH Salt – Scalable Systems Management 20 / 47

slide-21
SLIDE 21

Reusing States: Formulas

reusing existing code roughly the same as Puppet modules/Ansible roles collection of States and files github.com/saltstack-formulas/ for "official" formulas

B1 Systems GmbH Salt – Scalable Systems Management 21 / 47

slide-22
SLIDE 22

Using Formulas

directly from VCS or local extendable via include configurable via Pillar data variables mapped via Jinja map requirements across Formulas possible

B1 Systems GmbH Salt – Scalable Systems Management 22 / 47

slide-23
SLIDE 23

Demo

B1 Systems GmbH Salt – Scalable Systems Management 23 / 47

slide-24
SLIDE 24

Returners

salt ’*’ disk.usage --return redis_return

B1 Systems GmbH Salt – Scalable Systems Management 24 / 47

slide-25
SLIDE 25

Salts Event Driven Infrastructure

B1 Systems GmbH Salt – Scalable Systems Management 25 / 47

slide-26
SLIDE 26

Overview

actions trigger events events are communicated via the event bus reactors execute trigger actions responding to events

B1 Systems GmbH Salt – Scalable Systems Management 26 / 47

slide-27
SLIDE 27

Event Bus

B1 Systems GmbH Salt – Scalable Systems Management 27 / 47

slide-28
SLIDE 28

Actions & Events

master# salt ’salt-minion-01’ disk.percent /srv salt-minion-01: 11%

B1 Systems GmbH Salt – Scalable Systems Management 28 / 47

slide-29
SLIDE 29

Actions & Events

20160422163250339970 { [...] } salt/job/20160422163250339970/new { "_stamp": "2016-04-22T14:32:50.340357", "arg": [ "/srv" ], "fun": "disk.percent", "jid": "20160422163250339970", "minions": [ "salt-minion-01" ], "tgt": "salt-minion-01", "tgt_type": "glob", "user": "root" }

B1 Systems GmbH Salt – Scalable Systems Management 29 / 47

slide-30
SLIDE 30

Actions & Events

salt/job/20160422163250339970/ret/salt-minion-01 { "_stamp": "2016-04-22T14:32:50.536877", "cmd": "_return", "fun": "disk.percent", "fun_args": [ "/srv" ], "id": "salt-minion-01", "jid": "20160422163250339970", "retcode": 0, "return": "11%", "success": true }

B1 Systems GmbH Salt – Scalable Systems Management 30 / 47

slide-31
SLIDE 31

Events in a State

b1/mystate/status/update: event.send:

  • data:

status: "Installation done!"

B1 Systems GmbH Salt – Scalable Systems Management 31 / 47

slide-32
SLIDE 32

Beacons

hook into system on minion create events inotify, diskusage, load, journald ...

B1 Systems GmbH Salt – Scalable Systems Management 32 / 47

slide-33
SLIDE 33

Beacons - Example

inotify Beacon

beacons: inotify: /etc/motd: mask:

  • modify

B1 Systems GmbH Salt – Scalable Systems Management 33 / 47

slide-34
SLIDE 34

Reactors

B1 Systems GmbH Salt – Scalable Systems Management 34 / 47

slide-35
SLIDE 35

Calling Reactors on Events

Reactor Example

reactor:

  • ’salt/minion/*/start’:
  • /srv/reactor/start.sls
  • ’b1/mystate/status/*’:
  • salt://reactor/status.sls

B1 Systems GmbH Salt – Scalable Systems Management 35 / 47

slide-36
SLIDE 36

Demo

B1 Systems GmbH Salt – Scalable Systems Management 36 / 47

slide-37
SLIDE 37

Use Cases?

load-balancing job automation alerting

B1 Systems GmbH Salt – Scalable Systems Management 37 / 47

slide-38
SLIDE 38

Salt Cloud

B1 Systems GmbH Salt – Scalable Systems Management 38 / 47

slide-39
SLIDE 39

Overview

B1 Systems GmbH Salt – Scalable Systems Management 39 / 47

slide-40
SLIDE 40

Providers

Amazon EC2 Provider Example

my-ec2: driver: ec2 id: ’MYEC2ID’ key: ’adsfrf453fMYKEYasdsadg43’ private_key: /etc/salt/my_key.pem keyname: my_key securitygroup: default minion: master: saltmaster.example.com

B1 Systems GmbH Salt – Scalable Systems Management 40 / 47

slide-41
SLIDE 41

Profiles

profile name provider image or template

  • ptions for the instance

minion options

B1 Systems GmbH Salt – Scalable Systems Management 41 / 47

slide-42
SLIDE 42

Profiles

LXC Profile Example

myfancyprofile: provider: lxc-host01 lxc_profile: template: ubuntu

  • ptions:

release: trusty password: test123

B1 Systems GmbH Salt – Scalable Systems Management 42 / 47

slide-43
SLIDE 43

Maps

Mapfile

profile1:

  • instance_name_1
  • instance_name_2

profile2:

  • instance_name_3:

grains: mykey: myvalue

  • instance_name_4

Execute Mapfile

salt-cloud -m /path/to/mapfile

B1 Systems GmbH Salt – Scalable Systems Management 43 / 47

slide-44
SLIDE 44

Bootstrapping a New Salt Environment

Mapfile

profile1:

  • instance_name_1:

make_master: True minion: master: myoldmaster local_master: True

  • instance_name_2
  • instance_name_3
  • instance_name_4

...

B1 Systems GmbH Salt – Scalable Systems Management 44 / 47

slide-45
SLIDE 45

Saltify Existing Machines 1/2

Saltify Provider

saltify-all-machines: driver: saltify minion: master: mysaltmaster

Saltify Profile

salt-machine: provider: saltify-all-machines ssh_username: root key_filename: ’/etc/salt/pki/master/ssh/salt-ssh.rsa’

B1 Systems GmbH Salt – Scalable Systems Management 45 / 47

slide-46
SLIDE 46

Saltify Existing Machines 2/2

Mapfile

salt-machine:

  • first-machine:

ssh_host: 1.2.3.4

  • second-machine:

ssh_host: 1.2.3.5

  • third-machine:

ssh_host: 1.2.3.6

B1 Systems GmbH Salt – Scalable Systems Management 46 / 47

slide-47
SLIDE 47

Thank You!

For more information, refer to info@b1-systems.de

  • r +49 (0)8457 - 931096

B1 Systems GmbH - Linux/Open Source Consulting, Training, Support & Development
