RUSOILTECHNOLOGY GROUP OF COMPANIES CONTENTS Company Profile - - PowerPoint PPT Presentation

RUSOILTECHNOLOGY GROUP OF COMPANIES

Company Profile Global Reach of the Company Members of Rus Oil TechnologyGroup of Companies Our Customers Basic list of deliveries Oil and gas equipment Comprehensive Deliveries of Power-generating Equipment Fluid Pumping Automated Diagnostic Control Systems (ADCS) Our Partners Contact Details Additional Information

CONTENTS

COMPANY PROFILE

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

RusOilTechnology, OOO is a group of domestic companies that is engaged in the wholesale and retail trade of petroleum and gas field equipment. The companies are engaged in process developments in the field of information, consulting as well.

54 4 13

COUNTRIES COMPANIES EMPLOYEES

The activities of the Group of Companies covers 4 countries – Russia, Serbia, Kazakhstan, Kyrgyzstan 54 employees are engaged in the Group of Companies The Groups of Companies includes 13 organizations

GLOBAL REACH OF THE COMPANY

4

Russia Serbia Kazakhstan Kyrgyzstan

The Company operates on the territory of the Russian Federation and abroad

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

RUS OIL TECHNOLOGY GROUP OF COMPANIES

5

The group of companies includes 13 different organizations with related activities, forming a perfectly balanced system.

(Russia) (Russia) (Russia) (Serbia) (Kazakhstan) (Kazakhstan) (Kazakhstan) (Kazakhstan) (Kazakhstan) (Kazakhstan) (Kazakhstan) (Kyrgyzstan) (Kazakhstan)

OUR CUSTOMERS

Prompt picking of orders of any size and complexity, by all types of transport in a short time. The whole range complies with the requirements of GOST of Russia, is included in the unified register, corresponds to the specifications of products approved for use in NK Rosneft, OAO, Gazprom, OAO and other leading companies of the

• il and gas complex of Russia and the CIS.

IRZ TEK, OOO NIS j.s.c. Novi Sad Sojaprotein Jkp vodovod i kanalizacija Severelektro, OAO Gazprom, OsOO Kyrgyzstan National Energy Holding Company, OAO Elektricheskie stantsii, OAO National Electrical Grid of Kyrgyzstan, OAO

6

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

OUR CUSTOMERS

7

REPUBLIC OF KAZAKHSTAN

Kazakhoil Aktobe, TOO SP Kazgermunay, TOO Ozenmunaygaz, AO PetroKazakhstan - Oil and Gas Group Mangistaumunaygaz, AO Kazpetrol group, TOO

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

BASIC LIST OF DELIVERIES:

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

BASIC LIST OF DELIVERIES:

• ESP control stations with direct, soft start and frequency regulation
• ESP submersible telemetry systems
• Equipment for geophysical monitoring of oil producing wells
• Remote control complexes for facilities and other equipment
• Spare parts for ESP repair and configuration
• The whole range of cabling and wiring products
• Transformers
• Horizontal pumping systems

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

CABLING AND WIRING PRODUCTS

Cables and wires with following designs:

• Flame retardant in single laying;
• Flame retardant in bunched laying - ng(a);
• Low smoke and gas emission, version - ng(a)- LS;
• Low-toxicity with smoke and gas emission -ng(a)- lsltx;
• Cold resistant version - HL and ng(a)-hl;
• Made of polymer compounds not containing halogens, version - ng(a)- HF;
• Flame-resistant, version - ng(a)-frls, - ng(a)-frlsltx
• Flame-resistant, version - ng(a)-frhf
• Armored, shielded

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

SUBMERSIBLE TELEMETRY SYSTEMS FOR SEVERE ENVIRONMENT

Specifications:

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

SUBMERSIBLE TELEMETRY SYSTEMS FOR SEVERE ENVIRONMENT

The submersible telemetry system is designed to control and transmit the following current parameters during oil production:

• Intake pressure of the pumping unit;
• SEM oil pressure;
• SEM oil temperature;
• Reservoir fluid temperature;
• SEM stator winding temperature;
• SEM vibration level;
• SEM and power cable insulation resistance.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

SUBMERSIBLE TELEMETRY SYSTEMS FOR SEVERE ENVIRONMENT

Telemetry information from the submersible unit is transmitted via SEM power cable, processed in the ground unit and transmitted to the external devices (control station).

The system consists of two units:

• submersible unit series BP-103M;
• ground unit TMS-E5 or ASPT.

The submersible unit is mounted directly to the bottom of the SEM or by the bearing support and adaptor supplied separately for a specific type of SEM. The ground unit TMS-E5 is mounted outside the control station.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

SUBMERSIBLE TELEMETRY SYSTEMS FOR SEVERE ENVIRONMENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

DIAGNOSTIC COMPLEX

The device enables functional testing of submersible units with the SEM in operation (without stopping the control station); has a plastic case, self-contained power supply; the IRZ TMS diagnostic complex includes a submersible unit simulator.

Diagnostic complex IRZ TMS has a built-in indicator which shows:

• The current frame number;
• SEM oil pressure;
• SEM oil temperature;
• Reservoir fluid temperature;
• SEM stator winding temperature;
• SEM vibration level;
• SEM and power cable insulation resistance;
• Sensor condition.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

DIAGNOSTIC COMPLEX

The device is designed to simulate the submersible unit series BP- 103MЗ connection to the ground unit series TMS-E5 Purpose of the Submersible Unit Simulator:

• Functional testing of the ground unit series TMS-E5;
• Functional testing of the
• Ground unit series TMS-E5 insulation resistance control device;
• Setting the corresponding inputs of controllers of the submersible electric pump control stations;
• Functional check of algorithms for processing the changes of telemetry information by the control station

controller;

• Testing of algorithms in reduction of isolation resistance of the system "oil transformer for submersible pumps —

cable — SEM" by the control station controller.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

VARIABLE FREQUENCY CONTROL STATIONS

FOR THE ESP WITH ASYNCHRONOUS MOTOR

Purpose:

Control and monitoring of parameters and protection of submersible electric motors (SEM) with a capacity of 5 to 320 kW, with rotational speed regulation.

Advantages:

• Adaptive control algorithms;
• Service modes: jogging, unjamming, swinging,

jarring, PID control, voltage optimization;

• Saving history to an USB flash drive;
• Integrated output sine filter;
• Software update without stopping the SEM;
• Highly informative graphical display;
• Bus-type design of the power section.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

BATTERY OPERATED DYNAMOGRAPH

Easy to use:

• The possibility of replacing the battery in the field allows to;
• Eliminate the problem of sensor charging during long measurements;
• No communication cable and connectors - jamproof Bluetooth radio channel

is used for data transfer and sensor control with a guaranteed range up to 35 meters;

• Can be installed in almost any traverse suspension.

Reliability:

• High strength steel body resistant to mechanical damage;
• No moving parts;
• Special battery designed to work up to -40 °C;
• High reliability and explosion safety due to the absence of

connectors and cable connections

Savings:

• There is no need to purchase and install

cable channels, cabinets, terminal boxes;

• Low cost of ownership and operation - the

maintenance is reduced to periodic inspection and replacement of the sensor batteries.

EQUIPMENT

RECORDING UNIT LCD display with a special technology SR-NLT provides clear image even in bright sunlight. Screen backlit and illuminated keyboard make it easy to operate the unit even in the dark. Measurement process Dynamometer curve

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

ELECTRICALLY DRIVEN CENTRIFUGAL PUMPS

Purpose:

Submersible electrically driven centrifugal pumps and their individual components are designed to work in the units for pumping reservoir fluid from oil wells. Individual versions of submersible electric centrifugal pumps can be supplied as booster pumps, or pumps for pumping liquid in below-packer space to raise or maintain the reservoir fluids pressure in reservoir pressure maintenance (RPM) systems. It can be supplied as a part of double-side units operated with downhole drilling systems with an inner diameter of 89 mm.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

ELECTRICALLY DRIVEN CENTRIFUGAL PUMPS

ESP parameters:

The pumps supplied:

• By dimensions: 4А, 5, 5А, 6.1;
• By purpose: regular, booster and for RPM systems (inverted);
• By capacity from 15 m3/day to 1250 m3/day;
• By head: (2; 3; 3.5; 4; 4.5; 5 meter sections);
• By design: supported or unsupported (support in protector);
• By stage design - single-bearing, single-bearing with elongated hub or between-bearing;
• By assembly type: with floating stages, packet or compression;
• By reservoir fluid temperature: regular 110°C, heat resistant 135°C, or extra heat-resistant 170°C

versions;

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

ELECTRICALLY DRIVEN CENTRIFUGAL PUMPS (CONTINUED)

ESP parameters:

The pumps supplied: By wear resistance (stage material): can be equipped with stages (working elements) made of cast iron, Ni-resist Type I, Ni-resist Type IV, powder pseudoalloys, high-alloy powder, stainless steels and

• ther alternative materials on request;

By corrosion resistance: regular or corrosion-resistant (K) version; By shaft spline design - straight-spline or involute connection; By connection: with six-, eight -, and ten-point design (thread pitch can vary on request); By connection type: housing-flange or flange-flange. The produced pumps are easy to maintain at all service facilities for ESP units.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

INTAKE SECTIONS Purpose:

• The intake section MV is installed between the pump and the hydraulic protection and is designed

to supply the reservoir fluid (mixture of oil, associated water and gas) to the pump.

• The intake section MV is designed to prevent entry of particulate matter contained in the reservoir

fluid into submersible centrifugal pumps (ESP).

• The intake section represents a pump base with suction holes and a strainer, through which the

fluid enters the pump from the well.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

VALVES

Drain valve type KS

Designed to remove fluid from the tubing for well repair. Available with a reinforced drain adapter.

Sealed check ball valve type KOSh

Designed to transfer the liquid (drilling mud, water, reservoir fluid) in one direction. It provides the channel closure in case of pressure drop at the working fluid supply side during the processes, automatically prevents reverse flow of fluid and retains the fluid in the tubing after the pump stop.

Submersible sealed check ball valve type KOSh-P-V

Is used by the pump for pumping liquids in below-packer space. The valve closes the channel after the pump stops and prevents back flow of the fluid.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

Three-phase oil-filled asynchronous motors series PED-Ya and three-phase oil-filled submersible parametric motors series RPPED-Ya (hereinafter the "motors"). The motors can be supplied as drive units for oil extraction units, for fluid injection (a mixture of industrial iodine- bromine water) into below-packer space for raising (maintaining) the reservoir fluid (RPM systems) pressure, as a part of of double-side units.

The motors supplied:

• By dimensions - 103, 117, 130.
• By rated output:
• - Size 103 up to 210 kW;
• - Size 117 up to 360 kW;
• - Size 130 up to 500 kW;
• By heat resistance - regular, heat-resistant (T) or extra heat-resistant (TT) versions;
• By corrosion resistance - regular or corrosion-resistant (K) versions. Corrosion-resistant design can be fully made of stainless

steel or coated by Monel;

• By shaft rotation direction - right (clockwise) or left (counterclockwise);
• By shaft spline design - straight-spline or involute connection;
• By connection with the protector - six-, eight - or ten-point design of pins (thread pitch can vary on request).

EQUIPMENT

SUBMERSIBLE MOTORS

The following design and process solutions are applied in the motors:

• Closed slot of the stator (stator iron core with bulging, in-house production);
• Stator body has a mark of the key slot position - indicator of "non-cranking" of the stator iron core;
• Slot insulation (in-house produced PTFE tube);
• Winding wire (in-house production);
• Impregnation with Elplast-220 compound or VS 346А varnish can be performed on request;
• Packs (in-house production) tested under load before installation in the SEM;
• Self-locking non-magnetic bearings;
• Outputs made of wire PVTFI (in-house production);

All motors have connection dimensions unified with domestic manufacturers. Manufactured motors have high maintainability, including at any service facilities maintaining ESP units.

EQUIPMENT

SUBMERSIBLE MOTORS (CONTINUED)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

Supply of oil and package transformer substations for distribution networks with a voltage rating up to 10 kV. Main products:

EQUIPMENT

TRANSFORMERS

TMG TM TMZ h TMGe TMGe2

TMG pole- type and TMGF

Target purpose oil transformers series TMGP

TS

Package transformer substations (PTS)

TSZ TLS TLSZ OM TSZP OMP OS OSM

It is also possible to manufacture non-standard equipment according to individual specifications of customers.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

Features: Horizontal pump systems are designed to reduce maintenance costs due to higher

reliability, minimum requirements for scheduled repairs, increasing the time between repairs. Modular design allows replacement of main components in the field, as a result reducing the downtime.

Quality standards: Certified according to ISO 9001-2008. Specifications

EQUIPMENT

HORIZONTAL PUMP SYSTEM SE0125

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

EQUIPMENT

HORIZONTAL PUMP SYSTEM SE0125 (CONTINUED)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

30

OIL AND GAS EQUIPMENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

We offer almost all range of equipment Help to automate the production process Offer consultations in calculations and selection of production method

+ +

Lifting methods

31

LIFTING EQUIPMENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

32

GAS LIFT

Application:

• It is used for wells with high gas-oil ratio
• Maintains and increases the blowout rates
• Provides stable influx in a wide range of rates

Advantages:

• Cheaper compared to other lifting methods
• Flexible range
• Relatively small infrastructure at the wellhead
• Easy to use

Limitations:

• High-pressure gas source is required
• Not applicable for wells with low bottom hole pressure
• Limited maximum well flow rate
• Gas contributes to additional cooling

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

33

PLUNGER LIFT

Application:

• Stabilization of production in wells with high water cut and gas shows
• Gas well deliquification
• Prevention of paraffin and salt deposits

Advantages:

• Low capital costs
• No need for removing the tubing for pump withdrawal and repair
• Low operating costs
• Stable production
• Prevention of salt and paraffin deposits
• Prevents well self-killing

Limitations:

• Poor tolerance to solids
• Flow rate limitation
• High GOR is required
• (applicable for wells with a flow rate of up to 15 m3/day)

USED ONLY IN WELLS WITH LOW FLOW RATE AND HIGH GOR

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

34

ESP units

Application:

• Intensification of production at the initial stages of operation
• High-performance wells with a flow rate of 12 to 12500 m3/day
• Fields with developed infrastructure

Advantages:

• Can be used in a wide range of flow rates
• Possibility of using in ultradeep wells

Limitations:

• Relatively high capital costs
• Relatively poor tolerance to mechanical impurities and gas
• Developed infrastructure is required
• Relatively high power consumption

COVERS ALMOST ALL WELL TYPES

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

35

WELL DEVELOPMENT AFTER HYDRAULIC FRACTURING BY DUAL ESP

The motor transmits rotation to drive centrifugal pumps, located on both sides of the SEM. Booster pump takes the liquid through the shank put into the perforation interval of the producing reservoir, drains the bottom hole area, the bottom hole pressure is decreased immediately after starting 2 ESPs and the inflow from the reservoir is stimulated without waiting for dynamic level decrease to create a drawdown. The boosting section draws the technical liquid column off below the main pump suction, from the shank level, reduces the bottom hole pressure and replaces a heavy solution with the reservoir fluid, and ejects the liquid into the well annulus to the upper pump suction. The reservoir fluid ejected from the boosting section, together with mechanical impurities, enters the main (upper) pump, providing additional cooling of the SEM. Next, the liquid flows through the tubing lift to the surface.

Hydraulic pressure Perforation interval Bottom hole pressure

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

36

SINGLE-LIFT DOUBLE-SIDE UNIT FOR DUAL PRODUCTION

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

37

ESP units

Advantages:

• 100% separation of reservoirs, that excludes the impact of one reservoir on another one.
• The unit can be used in wells with any diameter of the production string. In narrow strings, it is possible to use

SEMs of 103 (mm)

• The unit is assembled from standard components used in the oil industry.
• Selective on-line control of water cut, flow rate is possible.
• The customer's equipment can be modernized for the dual production unit.
• Possibility to control the drainage by changing the SEM speed.
• Wide range of producing depths (20 m and more)
• Ease of assembly and arrangement of the unit in the well due to the possibility of using standard wellservice

technologies.

• Low cost compared to other technologies due to the use of standard components and simple design.

Disadvantages:

• The capacities of both pumps are interrelated (when the capacity of one of the pumps used for the production in

its interval changes, the capacity of the second pump is changed simultaneously with the first one).

• Requires a very accurate selection of equipment in accordance with the supply and pressure.

COVERS ALMOST ALL WELL TYPES

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

38

INVERTED PUMPS FOR WATER INJECTION

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

39

WELL DEVELOPMENT AFTER HYDRAULIC FRACTURINGBY DUAL ESP

1. Tubing 2. Discharge section 3. Cable 4. Seal section 5. SEM (double-side) 6. Thermomanometric system 7. Protector P-92(T) 8. Submersible ESPS 9. Nipple (coupling-coupling)

• 10. Elekton TMSR-25 RKM
• 11. Packer (PGYa)
• 12. Shank

1 2 3 4 5 6 7 9 10 11 12 8

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

40

WELL DEVELOPMENT AFTER HYDRAULIC FRACTURING BY DUAL ESP

1. Tubing 2. Cable 3. Seal section 4. SEM (double-side) 5. Thermomanometric system 6. Protector P-92(T) 7. Submersible ESPS 8. Nipple (coupling-coupling) 9. Mechanical string disconnector Elekton TMSR-25

• 10. Packer (PGYa)
• 11. Shank

1 2 3 4 5 6 7 9 10 11 8

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

41

ADDITIONAL PRODUCTS FOR ESPs

Working elements for ESPs Cable sleeves for current leads Seals for current leads Screws and impellers made of composites Filters for ESPs Membranes for seal section

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

42

SUBMERSIBLE CABLE

CABLES FOR OIL-SUBMERSIBLE PUMPS

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

43

PRODUCTION LOCALIZATION IN THE REPUBLIC OF KAZAKHSTAN

ESP manufacture (assembly), ESP repair and service maintenance (city of Kyzylorda)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

44

SUCKER-ROD SCREW PUMP

Application:

• Wells with high content of mechanical impurities and gas
• Production in wells with high-viscosity oil

Advantages:

• Tolerates a high particle content in the pumped liquid
• Relatively low capital cost of equipment
• Relatively adequately tolerates work with gas locks

Disadvantages and limitations:

• Wells with high-temperature reservoir fluids
• To select the correct elastomer for the stator, special tests are

required with the use of the borehole fluid

• Limited depth of installation

USED IN WELLS WITH LOW FLOW RATE AND HIGH PARTICLES CONTENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

45

SUCKER ROD PUMPING UNIT AND PUMPJACK

Application:

• Brownfield wells with low flow rate
• Highly flooded wells
• Wells drilled for exploration

Advantages:

• Tolerates a high particle content in the pumped liquid
• Relatively adequately tolerates the presence of particles in the fluid
• Low power consumption
• Relatively low capital and operating costs

Disadvantages and limitations:

• Limited depth of descent (limited by the pumpjack load capacity and

sucker rod strength)

• Free gas dramatically reduces the pump efficiency
• Hard to use in wells with abnormal profile (can result in rapid

abrasion of sucker rods and tubings) USED ONLY IN WELLS WITH LOW FLOW RATE

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

46

PRODUCTION AUTOMATION AND OPTIMIZATION

MANUFACTURING OF CONTROL STATIONS FOR SRP, PCP, ESP UNITS, TELEMETRY SYSTEMS Wireless dynamograph Control station ESP units Control station SRP/PCP Submersible telemetry for SRP/PCP/ESP

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

47

REMOTE SITE MONITORING SYSTEM

GSM network Internet Server LAN Router iRZ RUH2

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

48

FLUID PUMPING

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

49

HORIZONTAL PUMPING SYSTEMS (SPSTM)

Application:

• RPM systems
• Water pumping and flow line pressure increase
• Chemical reagent pumping
• Oil refining/product supply and transfer
• Coal mine dewatering
• Product transfer from offshore platforms

Advantages:

• Wide range of motor powers from 50 to 2000HP
• Good reliability of mechanical seals (minimization of leakages and

contamination of the environment)

• Easy installation (delivered on frame)

Disadvantages and limitations:

• Relatively large dimensions
• Sensitive to mechanical impurities in the pumped medium
• Sensitive to gas in the pumped medium

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

50

HORIZONTAL MULTIPHASE PUMPING SYSTEM

Application:

• RPM systems
• Pumping of water and flow line pressure increase (from 5 to

500м3/hour)

• Oil refining/product supply and transfer
• Product transfer from offshore platforms
• Pumping of live (not treated) crude

Advantages:

• Good tolerance of mechanical impurities in the pumped

medium

• Easy installation (delivered on frame)
• Ability to pump fluids with high gas content
• Ability to work with highly viscous media

Disadvantages and limitations:

• Relatively large dimensions (in the case of single-screw pump)
• Maximum possible pressure up to 30MPa

Single screw pump Multi-screw pump

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

51

CASING PIPE, TUBING AND DRILL PIPE

Casing and tubing pipes:

• Various diameters, grades and threaded connections

Drill pipe and drill collars:

• Various diameters, grades and threaded connection

types

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

52

SUCKER ROD

Sucker rod of different types:

• Manufactured in accordance with TU or API specifications
• Hollow sucker rod
• Continuous sucker rod (to solve the problem of tubing cutting in wells with abnormal profile)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

53

WELLWORK

Services in the field of wellwork:

• Engineering services for well control
• Well construction and repair control
• Engineering services in well cementing
• Engineering and process support of works on

well casing with supply of equipment)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

54

NON-STANDARD PRODUCTS

• Face seals
• Compressor shafts
• Couplings, adapters, end details, etc.

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

55

COMPREHENSIVE DELIVERIES OF POWER-GENERATING EQUIPMENT

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

56

MAIN ACTIVITIES

• Pre-project preparation, energy inspection of the site
• Obtaining of permits and specifications
• Integrated design of the power facility
• Coordination of project documentation with expert and

regulatory authorities

• Manufacture and batching of main and auxiliary equipment
• Supply of equipment
• Construction, installation and commissioning works
• Putting the facility into commercial operation
• Warranty and post-warranty service
• Provision of services on operation of constructed facilities

Production of diesel generator plants

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

57

SERVICES AND PRODUCTS:

Production of diesel generator plants Gas piston units Diesel generator plants Design Installation Service, spare parts, tools and accessories

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

58

SERVICES AND PRODUCTS:

Compressors Turbines

• Compressors for metal industry
• CCM for oxygen units and general purpose
• Processing CCM
• CCM for oil and gas industry
• Natural gas blowers
• Changeable flow channels for centrifugal blowers
• Gas turbines
• Steam turbines

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

59

SERVICES AND PRODUCTS:

EGPU Gas pumping units

• Electrically driven gas pumping

units (EGPUs)

• Gas pumping unit GPA-32 "Ladoga"
• f 32 MW Steam turbines
• Gas pumping unit GPA-25 "Ladoga"
• f 22/25 MW
• Gas pumping unit GPA-16 "Ladoga"
• f 16 MW
• Unified gas-pumping units
• n the basis of stationary GTU

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

60

SERVICES AND PRODUCTS:

Electrical products Products of metallurgical production

• Electrical products
• Generation
• Iron casting
• Steel casting

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

61

HORIZONTAL PUMPING SYSTEMS (SPSTM)

• The units have stationary design of different grades, have long service life and

good maintainability. Used on power or heat plants, gas processing plants, underground gas storages and other oil industry facilities.

• Centrifugal compressor machines for compression of the associated

petroleum gas

• Gas pumping units for associated petroleum and natural gas transportation

and processing with electric motor and gas turbine drive (capacity of 4 to 32 MW) coming with centrifugal compressors.

• Distribution transformer substations of different designs (6 kV to 110 kV).
• Mobile diesel power stations with a unit rating of 200 kW to 1.5 MW for the

main and reserve power of facilities.

• Mini–CHP plants with a capacity of 50 MW on the basis of diesel and gas

reciprocating engines with heat recovery systems and boiler equipment for use at mining facilities.

• Gas turbine power plant with a capacity of up to 100 MW to be used as the

primary source of electricity in the fields and compressor stations.

• Automatic power plant control systems

Compressor K 411-122-1

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

AUTOMATED DIAGNOSTIC CONTROL SYSTEMS (ADCS)

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

ADCS OPERATION PRINCIPLE IN OIL AND GAS INDUSTRY

Temperature control is used for monitoring of extended facilities, for example, to detect leaks, and is used to monitor the well profile. Acoustics is used to control the intrusion into the technical area and tie-in attempts. The cable also has additional channels for communication and data transfer.

63

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

AUTOMATED DIAGNOSTIC CONTROL SYSTEM (ADCS) FEATURES

• Detection of temperature changes caused by leaks (gas / liquid)
• Fire detection and prevention
• Detection of heavy machinery work
• Detection of landslides and soil sliding.

Unique combination of two complementary technologies greatly enhances the accuracy of detection of potential accident and leak areas!

64

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

ADCS TECHNOLOGY ADVANTAGES

The system has a number of advantages due to the use of fiber-optic cable:

• Easy installation and integration
• Cable is not susceptible to electromagnetic or fuel exposure
• Safe for use in hazardous areas
• Cable is maintenance free
• Cable is not affected by corrosive environment
• Thousands of measurement points for each zone
• Deployment in difficult access areas
• Operational monitoring of the entire length of the pipeline 24/7
• High precision localization of the cable fault or break areas

65

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

OUR PARTNERS

IRZ TEK, OOO (Izhevsk Radio Manufacturing Plant) Bitek, OOO (Ekaterinburg) Triol-Neft, OOO (Moscow) Petro-Lyub, OOO (Moscow) NIKOM 65 EOOD (Bulgaria, representative office in the city of Kazan (RF), Kaskelen (RF)) GE Oil&Gas (representative office in the city of Moscow) REP Holding, AO (Saint Petersburg) Vezerford, OOO (Moscow) Burkit Oiltek, TOO (Kazakhstan, Almaty) InPTs Pilot, OOO (Bashkortostan, Ufa) Kamsky Kabel, OOO (Perm) ROSSKAT, OAO (Samara)

66

OUR PARTNERS

Dinamika, OOO PNPPK, AO ("Perm Scientific and Production Instrument-making Company")

(CONTINUED)

67

Tekhnologiya, OOO Piter Bell, OOO - Electric power stations Neftyanaya Elektronnaya Kompaniya, ZAO

Registered office and place of business: 1a N. Ershov St, room K-3/100, Kazan 420061, Republic of Tatarstan, Russian Federation E-mail: : info@roilt.org OGRN 1141690077495 INN 1655303544 KPP 165501001 Settl./acc. 40702810600000003678 BRANCH OF AKIBANK, PAO in the city of Kazan BIC 049205916 Corr./acc. 30101810300000000916

THANK YOU FOR YOUR ATTENTION! Contact Details:

RusOilTechnology, OOO Write to Us

68

ADDITIONAL INFORMATION

69

Patents Certificates

RusOilTechnology, OOO Mingariev Marat Faridovich RF +7 965 607-32-33, RK +7 705 301-68-36, RS +381 64 6452 227, E-mail: info@roilt.org.

OUR CERTIFICATES

70

Documents confirming the official dealerships:

OUR CERTIFICATES

71

Documents confirming the official dealerships:

OUR CERTIFICATES

72

Documents confirming the official dealerships:

OUR CERTIFICATES

73

Documents confirming the official dealerships:

OUR CERTIFICATES

74

Documents confirming the official dealerships:

OUR CERTIFICATES

75

Documents confirming the official dealerships:

OUR CERTIFICATES

76

Documents confirming the official dealerships:

OUR CERTIFICATES

77

Documents confirming the official dealerships:

OUR CERTIFICATES

78

Documents confirming the official dealerships:

OUR CERTIFICATES

79

Documents confirming the official dealerships:

PATENTS

80

Patent for oil production device

PATENTS

81

Patent for oil production device Dual completion and dual injection

PATENTS

82

Patent for ESP unit for reservoir fluid production from wells Dual completion and dual injection

PATENTS

83

Patent for SRP unit drive control method The SRP unit drive control method is based on measuring the total energy per rocking cycle, application of scanning method for calculation and compensation of hydrodynamic friction forces.
