ROCKAWAY WATER PLAZA

Sustainable Environmental Systems Capstone

Zoë Piccolo

Produced for Pratt Institute and the Rockaway Waterfront Alliance

SPRING 2017

Sustainable Redesign of a Vacant Plot In Arverne

AGENDA

1.

Delta City Challenges

2.

Case Study

3.

NYC Initiatives

4.

Rockaway Background

5.

Client and Project Site

6.

Designs and Calculations

7.

Challenges

8.

Recommendations

SPRING 2017 4

DELTA CITY WATER CHALLENGES

• Delta cities
• IPCC climate predictions:

– sea level rise – increased probability of extreme weather events

• U.N. Urbanization trends

– 53.8% (2015) > 66% (2055)

CASE STUDY De Urbanisten: Benthemplein

Credit: De Urbanisten 5 SPRING 2017

SPRING 2017 6

7 SPRING 2017

• Originally developed in late 1800s
• Interest declined in the 1950s-early 2000s
• Recent resurgence, increased beach attendance
• Primarily 1-2 family residential/multi family residential

/vacant/open space

• Separate sewer systems; Rockaway WWTP
• 10’ or less above sea level
• Average ~43 inches annual rainfall; 4” in July – 2.5” February

ROCKAWAY PENINSULA/JAMAICA BAY

SPRING 2017 8

SPRING 2017 9

SPRING 2017 10

CURRENT CONDITIONS

SPRING 2017 11

SPRING 2017 12

SPRING 2017 13

Multipurpose Programming and Respite Ecology, Education, and Recreation

DESIGN I DESIGN II +

SPRING 2017 14

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 15

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

SPRING 2017 16

DESIGN I MULTIPURPOSE PROGRAMMING AND RESPITE

:

A A1 B1 C1 D1 B C D

STORMWATER RETENTION

SPRING 2017 17

=107,821 GALLONS

Enough storage to capture water from the entire site during a ~4 inch rain storm

SPRING 2017 18

DESIGN II

ECOLOGY, EDUCATION, AND RECREATION :

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

19

ECOLOGY, EDUCATION, AND RECREATION

SPRING 2017

:

DESIGN II

SPRING 2017 20

DESIGN II

ECOLOGY, EDUCATION, AND RECREATION :

A A1 B1 C1 D1 B C D

STORMWATER RETENTION

SPRING 2017 21

= 91,256 GALLONS

Enough storage to capture water from the entire site during a ~3.5 inch rain storm

SPRING 2017 22

MARITIME GRASSLAND

1. Juniperus virginiana - Red Cedar 2. Prunus serotina - Black Cherry 3. Myrica pensylvanica - Northern Bayberry 4. Gaylussacia baccata - Black Huckleberry 5. Solidago sempervirens - Seaside Goldenrod 6. Aster ericoides - Heath Aster 7. Lespedeza capitata - Bushclover 8. Oenothera biennis - Evening Primrose 9. Ammophila breviligulata - Beachgrass

• 10. Schizachyrium scoparium - Little Bluestem
• 11. Panicum virgatum - Switchgrass
• 12. Sorghastrum nutans - Indian Grass

CHALLENGES

• Water table + engineered pumping system
• Land ownership
• Budget
• Community input

SPRING 2017 23

RECOMMENDATIONS

• Survey of the site
• Partner with engineering firm
• Begin discussions with City agencies
• Combination of the 2 designs is possible
• Community evaluation / vote

SPRING 2017 24

THANK YOU!

APPENDIX I: Benthemplein Images

Project and Images: De Urbanisten

APPENDIX II: Arverne Land Use

NYC ZoLa Map

APPENDIX III: JFK Avg. Monthly Precipitation

3.16 2.59 3.78 3.87 3.94 3.86 4.08 3.68 3.5 3.62 3.3 3.39

2 2.5 3 3.5 4 4.5

In Inches

AVERAGE M MONT NTHL HLY P PRECIPITATION, N, JF JFK

PRECIPITATION

APPENDIX IV: Design I Volume

SECTION LENGTH (ft) WIDTH (ft) DEPTH (ft) CUBIC FEET GALLONS 1 135 2 0.67 180.00 1346.40 2 110 2 1.33 293.33 2194.13 3 85 2 2.00 340.00 2543.20 4 120 2 0.67 160.00 1196.80 5 80 2 1.33 213.33 1595.73 6 50 2 2.00 200.00 1496.00 7 15 53 1.00 795.00 5946.60 8 15 49 1.67 1225.00 9163.00 9 15 45 2.42 1631.25 12201.75 10 25 23 0.67 383.33 2867.33 11 25 23 1.33 766.67 5734.67 12 25 23 2.00 1150.00 8602.00 13(A) 10 41 2.67 1093.33 8178.13 13(B)* 60 15 2.67 1200.00 8976.00 13(C) 40 25 2.67 2666.67 19946.67 13(D) 10 10 2.67 266.67 1994.67 14 55 10 1.67 916.67 6856.67 15 40 70 0.67 933.33 6981.33 TOTAL: 14415 107821 *Triangle, no formula; (B(60)*H(15))/2 = 450 * 32")

APPENDIX V: Design II Volume

SECTION LENGTH (ft) WIDTH (ft) Triangular Area (ft^2) DEPTH (ft) CUBIC FEET GALLONS 1 25 30 375 2 750 5610 2 25 30 375 2 750 5610 3 90 30 1350 2 2700 20196 4 30 60 900 2 1800 13464 5 100 30 1500 2 3000 22440 6 30 80 1200 2 2400 17952 7 20 40 400 2 800 5984 TOTAL: 12200 91256

APPENDIX VI: Shipping Container Conversion

= = 40’ x 8’ x 8.6’ = = 2,752 cub ubic ic feet

DESIGN I:

14415 ft 14415 ft3

3 /

/ 2,752 ft3 = = 5.24

5.24 sh

shipping co containers

DESIGN II:

12200 ft 12200 ft3

3 /

/ 2,752 ft3 = = 4.43

4.43 sh

shipping co containers

APPENDIX VII: Stormwater Capacity

(S (Site Square Feet/12)*I )*Inches of Rainfall)7 )7.48= Gallons

∴

DESIGN I: ((107,821 gallons/7.48)*12)/44,500 sq. ft.=

(Site Square Feet/12)*Inches of Rainfall= Gallons/7.48 Site Square Feet/12= (Gallons/7.48)/Inches of Rainfall Site Square Feet*Inches of Rainfall= (Gallons/7.48)*12

Inc Inche hes o

• f R

Rainf infall= ( ll= ((Ga Gallo llons ns/7.48)*12)/Sit Site Sq Squa uare F Feet

3.887 inches

DESIGN II: ((91,256 gallons/7.48)*12)/44,500 sq. ft.= 3.290 inches
