Roadmap towards Energy Neutral Sewage Treatment Works in Hong Kong

1

Po-Heng (Henry) LEE

• Dept. of Civil and Environmental Engineering

The Hong Kong Polytechnic University

Butcher Ding's Dismembering Bulls: Taoism

2

Beef Cuts vs STW Cuts

3

ENERGY à C & N

My Taoism in Science & Engineering: Thermodynamics

4

13.7 8 Today 13 10 12 11 9 6 1 2 3 4 5 7 Unit: Unit: Billions years

Big Bang Earth Formed People Appear

Quraks 10-18 Nucleon

Molecule

Atom Smallest Cell Solar System Mountain Human Sun Galaxy 10-15 10-10 10-9 10-5 DNA Length 10-3 106 1 109 1015 1021 Unit: Mit Unit: Miter er

Mass, Energy & Time

Sample Collection

5

A"er degri)ng Primary effluent Secondary effluent Primary Sludge A"er Thickening (secondary sludge) A"er Anaerobic Diges>on

1 2 4 5 3 6

Sample Collecting: Shatin & Shek Wu Hui STWs

Oxygen Bomb Calorimetry Experiment

Mix sample with combus>on aid Make a pellet Weigh the pellet Place the pellet into capsule Connect nichrome wire Assemble the oxygen bomb Charge bomb with

• xygen

Weigh deionized water Put bomb into jacket, connect the electrode, fill water Set up, ignite, record

6

• Samples dried for ~48 h at 104 ̊C

What we learn from this survey?

> Sludge contains more energy than sewage > Sewage energy is much more dilute so that is difficult to capture > Energy content from Ammonium nitrogen is around 10-35% of organics carbon

7

Strategies: Energy Neutral/Positive Saline STWs

Energy Conserva>on

• Smart

aera>on

• Shortcut

denitrifica>on

• Mainstream

Anammox

Energy Produc>on

• Pretreatment

with mono- or co-diges>on

• Solid Oxide

Fuel Cells

• Energy

recovery from ammonium

8

Sewage 1st clarifier

C ─ N ─

C + N +

Mainstream Energy Efficient Anammox

9

Packed-Bed O2-Controled System with 50 mg/L NH4

+-N

Reactor Aerator

Influent Effluent Air Aerated Recycle

Effect of DO/NH3 Ratio

20 40 60 80 100

0.55 0.65 0.75 0.85 0.95 1.05 % Removal DO/NH3 Ra9o

N Removal NH3 Removal

• TA: total species of anammox bacteria; KS: Candidatus Kuenenia stuttgartiensis;

BA: Candidatus Brocadia anammoxidans, BF: Candidatus Brocadia fulgida

Sample KS/TA % BA/TA % BF/TA % Seeding 20.48 0.03 0.17 Site 1 2.73 14.27 0.02 Site 2 1.60 19.38 0.89 Site 3 2.46 28.25 1.75 Site 4 1.02 33.67 1.98

Shifted from KS to BA with concentrated to dilute

Anammox Dominant species

Saline Mainstream Anammox

§ C/N ratio <2 via Anammox-based processes for C and N removal § Saline effect?

13

HK Waste Wate Treatment Plants

Shek Wu Hui Yuen Long Tai Po Sha Tin

seawater?

hbp://"s.com.hk/epd

Maximal Energy Production with Sludge

15

C and N fuels from Sludge

CH4(g)+2O2(g) à CO2(g)+2H2O(l) ΔHR

0=-890 kJ/mol

(1) CH4(g)+ 4N2O(g) à CO2(g) +2H2O(l)+ 4N2(g) ΔHR

0=-1219 kJ/mol

(2) CH4(g)+4NH3(g)+5O2(g)CO2(g)+2N2(g)+8H2O(l) ΔHR

0=-2125 kJ/mol

(3)

16

Coupled Aerobic–Anoxic Nitrous Decomposition Operation (CANDO)

> Ammonium partial oxidization into nitrous oxide via chemical or biological approaches > Methane combustion with Nitrous oxide > Approximately 20 to 30% more energy yield than combustion with

• xygen

17

Scherson et al., 2013

NH3, CH4, and CO2 Reformation using Solid Oxide Fuel Cell

18

NH3 CH4 N2 CO2 N2 Cathode Electrolyte Anode O2- O2

(U.S. Serial No. 62/353,137)

• Prof. Ni Meng

Performance of NH3, CH4, and CO2 Reformation

> 50 to 60% Energy conversion efficiency (30% in combustion)

> Using additional fuel (NH3-N)

• C decomposition can be avoid due to CO2 and NH3 in SOFC
• No NOx emission
• 60% of a net energy output greater than conventional combustion
• A techno-economic analysis shows that the net energy ratio

improves from 1.11 to 1.75 in Hong Kong West New Territories (WENT) Landfill Facility

19

High Gravity (HIGEE) in Rotating Packed Bed Reactor

Effective Gas liquid separation induced by 100 G

• Prof. Yi-Hung Chen

Ammonium Removal from Concentrated Wastewaters

21

21

1 1 2 5 4 3

On-site Treatment Condi9on: QL of wastewater = 7 L/min

• Conc. of NH4-N = 5630 mg/L

pH = 11.5-12 Removal efficiency = 90–98% Power Specifica9on (Full-rated) Rotor: 3 hp Liquid Pump: 1.5 hp Air Pump: 1.5 hp Energy consump9on: Below half of full rated power = 2.2 kW

300 600 900 1200

ω (rpm)

85 90 95 100

η (%)

• 1. Influent tank
• 2. RPB
• 3. Effluent tank
• 4. Air pump
• 5. Scubber

T D

Con9nuous Supply of Fresh Air or Steam Rota9ng Packed Bed (RPB) Clear Effluent Clear Air Con9nuous Inflow of Ammonia-rich Wastewater

• 1. Converted to ammonium sulfate
• 2. Recovery of ammonia solu9on
• 3. Burning as fuel

Neutralizer/ Recovery

H2S Issue

22

H2S Removal from Biogas

23

T D

Con9nuous inflow of Biogas with 1-3 vol.% H2S

On-site treatment condi9on: QG of biogas = 20 L/min Ini9al conc. of H2S = 1–3 vol.% Alkaline: 30 wt.% NaOH Removal efficiency = 90–99%

Rota9ng Packed Bed (RPB)

Purified Biogas

Circulated Alkaline Solu9on

Power Specifica9on (Full-rated) Rotor: 0.5 hp Liquid Pump: 0.5 hp Biogas Pump: 0.5 hp

Energy consump:on: Below half of full rated power = 0.56 kW

• Prof. Yi-Hung CHEN

H2S S Remo mova val fro rom m Bi Biogas s by y Rotating Pa Packe cked Be Bed: Field Exp Experi rime ments s at Ba Bali WWTP

24

Mexa-584L M pH M ATI-C16 M

Alkaline solvents (QL = 0.12-0.6 L/min, G/L = 100-500) 10-30 wt.% NaOH or MDEA (N-methyldiethanolamine) H2S CO2 Air dilu9on

Exceed purified biogas

Biogas with 1-3 vol.% H2S QG: 10-60 L/min Requirements: 100 ppm to atmosphere 650 ppm to combus9on (100 ppm for SOx) 1 ppm to fuel cell

Removal efficiency = 90–98%

Sewage Enhanced 1st clarifier AFMBR: Anammox Effluent (Permeate)

Summary

• Enhanced 1st treatment to remain C and N in sludge
• Ammonia and methane into energy with higher

conversion efficiency

• Mainstream Saline Anammox

Sludge Anaerobic Digestion Digestate CH4 NH3

ENERGY

Thank you very much
