Road to High Speed WLAN Xiaowen Wang Introduction 802.11n standardization process. Technologies enhanced throughput Raw data rate enhancement Overhead management Final remarks LSI Confidential 2 Background


slide-1
SLIDE 1

Road to High Speed WLAN

Xiaowen Wang

slide-2
SLIDE 2

LSI Confidential 2

Introduction

  • 802.11n standardization process.
  • Technologies enhanced throughput

– Raw data rate enhancement – Overhead management

  • Final remarks
slide-3
SLIDE 3

LSI Confidential 3

  • Jan. 2004, 11n working group started with the goal of reaching network

throughput of over 200Mb/s.

  • Since then, several industry consortiums began to work on proposals

for 11n, namely, TGnSync and WWiSE.

  • Jan. 2005 3 complete proposals were submitted to 11n by TGnSync,

WWiSE and MITMOT.

  • Till July 2005, no one proposal can pass the confirmation vote. The

three parties began the work of merging to a joint proposal.

  • EWC (enhanced wireless connection) formed in Oct. 2005 by

members of TGnSync and WWiSE working on the joint proposal.

  • Jan. 2006 proposal from EWC was approved as confirmed proposal.
  • First letter ballot stated in March 2006.
  • Nov. 2006, draft 1.06 was approved.
  • Draft 2.0 was approved in March 2007.

Background

slide-4
SLIDE 4

LSI Confidential 4

  • Highest raw link data rate in 802.11a/g is 54Mb/s

– Coding rate: 3/4 – Modulation: 64QAM – Symbol duration: 3.2µs – GI duration: 0.8µs

  • With network efficiency of 90%, the network throughput would be

48Mb/s.

– 16µs training and 4µs signal field – IFS – ACK and other control packages

Starting Point

slide-5
SLIDE 5

LSI Confidential 5

Solutions

  • Increase raw physical layer link data rate

– Increase coding rate – Increase constellation density – Increase bandwidth – MIMO: spatial multiplexing

  • Reduce overhead

– Physical layer signaling, training, MAC layer header, control and signaling package. – Increase data package length.

slide-6
SLIDE 6

Data Rate Enhancement

slide-7
SLIDE 7

LSI Confidential 7

Advanced Coding

  • Goal: achieve higher data rate and enhance performance
  • Convolutional code:

– New code rate: 5/6

  • LDPC code: optional

– Code rates: ½, 2/3,3/4,5/6.

  • Turbo code had been considered, but does not make it to the final draft.
  • STBC: 1 spatial stream to 2 Tx antennas: optional
  • Data rate increase: x10/9
  • Overhead associated: signaling and training
slide-8
SLIDE 8

LSI Confidential 8

High Density Constellation

  • 256QAM was considered but not accepted in the current draft.
  • The SNR requirement is too high, over 30dB required for PER of 10%.
  • Possible data increase: x2
  • Overhead associated: signaling
slide-9
SLIDE 9

LSI Confidential 9

Bandwidth Increase

  • Bandwidth is doubled from 20MHz to 40MHz: optional
  • One user can have as many as 108 subcarriers.
  • Data rate increase: x2.25
  • Overhead associated

– Signaling – MAC layer probing

slide-10
SLIDE 10

LSI Confidential 10

MIMO

  • Spatial multiplexing: map Nsts spatial streams (independent data

streams) to Ntx transmitter antennas.

– Direct mapping: Nsts = Ntx, either identity or CSD matrices – Spatial expansion (optional): Nsts < Ntx, simple CSD or selective diversity – Beamforming (optional): decide the steering matrix on the run according to the channel information by the sounding packet

  • Data rate increase: x4
  • Overhead:

– Signaling – Training – MAC support

     

1 1

STS TX STS STS

N N N N

k k k

  

 Y Q X

slide-11
SLIDE 11

LSI Confidential 11

MAC Layer Procedure of Beamforming

  • Implicit feedback

– Use the reciprocity of the channel – Beamformer send training request, beamformee send training back, then beamformer starts beamforming. – Calibration is needed to ensure reciprocity.

  • Explicit feedback

– Null sounding packet is sent by the beamformer and then beamformee estimate the channel and quantize and feedback the channel information to the beamformer.

slide-12
SLIDE 12

Overhead Management

slide-13
SLIDE 13

LSI Confidential 13

OFDM Symbol Level

  • GI (guard interval) length

– 11a/g, GI length is ¼ of symbol length – There are 3 different GI legnth

  • ¼ of symbol length, 0.8μs
  • 1/8 of symbol length, 0.4μs
  • ½ of symbol length, 1.6μs
  • FFT size of symbol length

– MIT/MOT proposed to double the symbol length to 128, but was not adopted by the current draft. – To realize the efficiency benefit, the MAC layer package has to be certain length which is not the case in practice.

slide-14
SLIDE 14

LSI Confidential 14

PPDU Level

  • Signal field has to increase to accommodate the more complex PHY.

– Current HT signal field has 2 OFDM symbols transmitted in BPSK. – Legacy signal field is kept for backward compatibility.

  • Training requirement is basically proportional to the number of spatial

streams.

– A 4μs HT-STS is added to improve AGC accuracy – Long training design criteria

  • All tones of different channel corresponding to different antenna pairs should be

independently trained. The column of U should be orthognal.

  • All transmitter chains should be excited all the time.
  • No beam should be formed as different transmitter chains transmit correlated

signals.

– CSD*Walsh

TX LTF

N N

LTS LTS LTS

            U 

slide-15
SLIDE 15

LSI Confidential 15

Greenfield Operation

  • In the HT mixed format, a legacy (11a/g) training and signal field are

transmitted.

– Attempt to reuse the legacy training had been considered.

  • AGC accuracy is the reason for adding HT-STF and HT-LTF
  • Signal field is kept for backward compatibility.
  • Greenfield operation: no legacy transmission exists

– Greenfield condition is assured by MAC protection scheme. – Save 16μs compared to HT-mixed format – Only 2 pilots instead of 4 pilots are used.

  • Each HT-LTF is only half the size (one symbol) of the L-LTF, more

sophisticated channel estimation algorithm is required to ensure the performance.

L-STF L-LTF L-signal HT-STF HT-LFT1 HT-LFT1 HT-signal HT-STF HT-LTF HT-LFT2 HT-LTF2 HT-signal

slide-16
SLIDE 16

LSI Confidential 16

MAC Level

  • Aggregation

– HT PHY increases the signal field and training – HT PHY decreases the data portion – MAC layer data packet size is limited by higher layer (such as TCP/IP) – Aggregate several MAC layer packets and transmit them in one PPDU.

  • Block ACK

– One ACK package is at least 24μs no matter how fast the PHY is. – Block ACK is not only a QoS scheme, but also increase the throughput.

  • RIFS
slide-17
SLIDE 17

LSI Confidential 17

Final Remarks

  • 802.11n is the first wireless standard that MIMO takes the center stage.

– Spatial multiplexing – STBC – Transmitter beamforming

  • WiFi announced last August, they are going to began certificate pre-

11n products this year. The feature list is still in working, but only baseline system would be certified.

– Convolutional code with rate ½, 2/3, ¾, 5/6. – 2x2 20MHz spatial multiplexing – Greenfield operation – Packet aggregation and block ACK

  • Lessons learned from this successful MIMO OFDM practice.

– System becomes more and more flexible. – Control pane becomes more and more a challenge – Cross layer optimization and tradeoff.

slide-18
SLIDE 18

LSI Confidential 18
