Welcome

for the Workshop on Hydro- Meteorological Instrumentation

Real-Time Water Quality Monitoring System for

River Ganga

Suneel Dave Incharge NGRBA Cell

The Ganga

NGRBA Cell, CPCB Delhi 2

The Ganga - Important Locations

2nd September 2013 NGRBA Cell, CPCB Delhi 3

OBJECTIVES OF THE PROJECT

NGRBA Cell, CPCB Delhi 4

• To assess nature and extent of pollution.
• To understand the environmental fate of

different pollutants.

• To evaluate effectiveness of pollution control

measures in place.

• To evaluate water quality trend.
• To assess the fitness of water for different

uses

The Network – Locations

 On Main Stem :

• Upstream and downstream of major urban areas
• Downstream of Point sources from Industrial & Domestic

discharge

 Major tributaries : Upstream of the confluence with the

Ganga

 In major drains  At important mass bathing place  Upstream of intake well for drinking water treatment plants  Downstream of wastewater treatment plants

NGRBA Cell, CPCB Delhi 5

State Station Type Total Class I Class II Class III

Uttarakhand 3 4 1 8 Uttar Pradesh 21 17 19 57 Bihar 4 1 8 13 West Bengal 12 14 9 35 Total 40 36 37 113

6

The Network - Stations

NGRBA Cell, CPCB Delhi

Class I: Indicates the primary stations at selected locations of the Ganga main stem. These will act as impact or baseline stations for maximum parameters Class II: Indicates the secondary stations at the remaining locations, on the main stem and at important tributaries for limited parameters Class III : Indicates stations in major drains for selected parameters

7

The Network – Parameters

NGRBA Cell, CPCB Delhi

• Sl. No.

Parameter Abbreviation/ Symbol 1 Ammonia NH3 2 Biochemical Oxygen Demand BOD 3 Benzene, Toluene, and Xylenes BTX 4 Chloride Cl- 5 Chemical Oxygen Demand COD 6 Color Color 7 Dissolved Oxygen DO

8

Electro Conductivity EC 9 Fluoride F- 10 Hydrogen Sulfide H2S 11 Nitrate NO2-N 12 Nitrites NO3-N 13 pH pH 14 Potassium K+ 15 Temperature T 16 Turbidity Turbidity 17 Total Suspended Solids TSS 18 Total Organic Compounds TOC 19 Water level Water level

The Network – Data Purchase

River

Installation

• f

Water Quality Probe DATA Logging Calibration checks, Quality Assurance

Transfer to CPCB

DATA Stored at CPCB Server

Ganga Knowledge Centre

Release of Payment

Processing for payment

DATA Processed

Dissemination to WEB GIS

NGRBA Cell, CPCB Delhi 8

DATA Validation

NGRBA Cell, CPCB Delhi 9

Similar nature of Experience - No. of parameters & monitoring stations, River Characteristics & Geographical Spread Key aspects - DATA PURCHASE CONCEPT Available Technologies and expertise on RTWQM Implementation Models pros and cons Possible options for the CPCB

Points of Discussion

NGRBA Cell, CPCB Delhi 10
