Investigating the Role of Hob1 in Repairing Double Stranded DNA Breaks in the Fission Yeast, Schizosaccharomyces pombe Sarah Ozturk, Andy Mai, Daitoku Sakamuro, Ph.D., and Amy Abdulovic Cui Ph.D . Department of Biological Sciences and the

slide-1
SLIDE 1

Investigating the Role of Hob1 in Repairing Double Stranded DNA Breaks in the Fission Yeast, Schizosaccharomyces pombe

Sarah Ozturk, Andy Mai, Daitoku Sakamuro, Ph.D., and Amy Abdulovic‐Cui Ph.D. Department of Biological Sciences and the Department of Biochemistry & Molecular Biology, Georgia Regents University, Augusta, GA.

slide-2
SLIDE 2

DNA & Genomic Integrity

  • DNA
  • Mutations, lesions
  • Cancer, disease
  • Restoring DNA

http://www.euroimmun.us/img/dsDNS_12.jpg

http://www.nwfsc.noaa.gov/publications/scipubs/techmemos/tm17/figures/p arkfig2.gif

slide-3
SLIDE 3

Double Stranded Breaks

  • Causes

– X-rays – Gamma radiation

  • 1 single double stranded

break is lethal to cell

http://blog.ctl.net/wp- content/uploads/2013/04/photo.jpg

slide-4
SLIDE 4
  • DNA strand breaks
  • Checkpoint pathways

activated

  • Repair Pathways

– Homologous Recombination – Non-Homologous End Joining

Damage and Repair

https://achemicallife.files.wordpress.com/2012/12/ dna_breaks.png

slide-5
SLIDE 5

Homologous Recombination

  • Sister chromatids as template

– More accurate, higher precision – Non mutagenic

  • Only occurs after DNA synthesis

https://teaching.ncl.ac.uk/bms/wiki/ima ges/d/d2/Sister_Chromatids.JPG

slide-6
SLIDE 6

MRN protein arrives to break site, checkpoint

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-7
SLIDE 7

Rad51 interacts with single stranded

  • verhangs

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-8
SLIDE 8

Strand invasion of sister chromatid

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-9
SLIDE 9

Bidirectional replication producing two identical double stranded DNA

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-10
SLIDE 10
  • Process of joining two DNA ends together
  • No sister chromatid involved
  • Nuclease activity, mutagenic

– Lose DNA information

  • Insert picture with DNA mutation

Non-Homologous End Joining

http://www.nwfsc.noaa.gov/publications/scipubs/techme mos/tm17/figures/parkfig2.gif

slide-11
SLIDE 11

Ku proteins interact with ends of break

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-12
SLIDE 12

Nuclease

Ku recruits other proteins to site Nuclease activity trims flaps to allow for ligation

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-13
SLIDE 13

Nuclease

Ligation occurs and forms 1 copy

  • f mutagenic double stranded

DNA

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

slide-14
SLIDE 14

Nuclease

Bin1 Bin1 interacts with Ku proteins

Picture edited from: Brandsma and van van Gent Genome Integrity 2012, 3:9 http://www.genomeintegrity.com/content/3/1/9

Bin1 No Bin1 NHEJ (Mutagenic, cancer) No NHEJ (Apoptosis or HR)

slide-15
SLIDE 15

Hob1

  • Homolog of mammalian Bin1
  • Role in inhibiting Non-Homologous End Joining

(NHEJ)

slide-16
SLIDE 16

Hypothesis

  • Hypothesis: Hob1 plays a fundamental role in
  • S. pombe by inhibiting non-homologous end

joining.

slide-17
SLIDE 17
  • Fission yeast
  • Eukaryotic model system
  • Manipulation
  • 2-4 hr generation time
  • Conserved repair pathways

Schizosaccharomyces pombe

http://www.ucl.ac.uk/gee/images/carousel-2014/Sz-pombe- strains

slide-18
SLIDE 18

Methods

  • Genetically in yeast, in vivo

1.) Extract E.coli plasmid 2) Linearize plasmid 3) Transform plasmid into S. pombe 4) Allow for selective growth 5) Assess the success of the transformation

slide-19
SLIDE 19

Plasmid: pAL19

  • Transcriptional start site
  • Ampicillin
  • ARS
slide-20
SLIDE 20

1.) Extract plasmid from E.coli 2) Linearize plasmid with restriction enzyme

slide-21
SLIDE 21

Leu- v Heat and Chemical Shock NHEJ

slide-22
SLIDE 22

Density of Total Cells (cells / mL) Counted Colonies NHEJ Rate (Density/C

  • lonies)

Wild Type 2.45x10^7 59 2.6x10-6 hob1Δ 2.2x10^7 <4.1x10-8 100 fold DECREASE in NHEJ

Promoting DSB repair

slide-23
SLIDE 23

#1 Possible Reasons for Data

  • There was not a control used to test the intake
  • f DNA into the yeast.

– In future experiments, a control plasmid will be used to verify that transformation occurred.

slide-24
SLIDE 24

Leu- v Pal19 isolated from E. coli Control plasmid with Ura Linearized Plasmid Transformed linearized plasmid and control DNA rejoined to form circular plasmid and control is present Yeast able to grow on plates without leucine Ura- v Yeast able to grow on plates without uracil

Experiment Design Using Control

slide-25
SLIDE 25

#2 Possible Reasons for Data

  • Yeast Hob1 could behave differently than

mammalian Bin1

– Multicellular – Unicellular

  • Homologous recombination

– Prevalent in yeast – Investigate role of Hob1

slide-26
SLIDE 26

Summary

  • Hob1 role in NHEJ
  • Hypothesized that it would behave similar to Bin1
  • Experiment

– Extracted and cut plasmid – Transformed into fission yeast – Selectively grew to assess NHEJ repair

  • 100 fold reduction in NHEJ rate

– Hob1 induces DSB repair

slide-27
SLIDE 27

Thanks to Dr. Sakamuro and Dr. Abdulovic-Cui lab group!

slide-28
SLIDE 28

References

  • Bennardo, Nicole, Anita Cheng, Nick Huang, and Jeremy M. Stark. "Alternative-NHEJ Is a

Mechanistically Distinct Pathway of Mammalian Chromosome Break Repair." PLOS Genetics. N.p., 27 June 2008. Web. 23 Sept. 2014

  • Brandsma, I., & Van Gent, D. (2012, January 1). Pathway choice in DNA double strand break repair:

Observations of a balancing act. Retrieved from http://www.genomeintegrity.com/content/pdf/2041-9414-3-9.pdf

  • Forsburg, S. L. "THE YEASTS SACCHAROMYCES CEREVISIAE AND SCHIZOSACCHAROMYCES POMBE:

MODELS FOR CELL BIOLOGY RESEARCH." Gravitational and Space Biology (2005): n. pag. Web.

  • Ramalingam, A., Farmer, G., Stamato, T., & Prendergast, G. (2007, August 1). Bin1 Interacts with and

Restrains the DNA End-Binding Protein Complex Ku. Retrieved from http://www.tandfonline.com/doi/abs/10.4161/cc.6.15.4514

  • Routhier, E., Donover1,2, P., & Prendergast, G. (2002, October 22). Hob1 , the fission yeast homolog
  • f Bin1, is dispensable for endocytosis or actin organization, but required for the response to

starvation or genotoxic stress. Retrieved from http://www.nature.com/onc/journal/v22/n5/full/1206162a.html
