Renhotec Electronics

• W e

m a k e c o n n e c t i o n e a s i e r

www.renhotecpro.com sale@renhotec.com

M Series Connectors & Cables

Renhotec Group's M5/M8/M12 Connector System includes a broad range of straight, angled, LED and multi-positionfield installable and board connectors that are easily intermateable . Renhotec

• ffers

a complete line

• f

M5/M8/M12 connector solutions with variety

• f

tyeps, such as Panel Mount Receptacle, Field Wireable Assembly Cable Plug and Molding Cable .

www.renhotecpro.com sale@renhotec.com

M12 Panel Mount

www.renhotecpro.com sale@renhotec.com

M12 Male Panel Mount Connector

Gender: Male Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: PCB /Soldering Cable Length: Base on customer request

Electrical & Mechanical data

Connection type Front Mount/Back Mount Orientation Straight Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ Shielding Non-Shielded IP rating IP67

M12 Panel Mount

www.renhotecpro.com sale@renhotec.com

M12 Female Panel Mount Connector

Gender: Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: PCB /Soldering Cable Length: Base on customer request

Electrical & Mechanical data

Connection type Front Mount/Back Mount Orientation Straight Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ Shielding Non-Shielded IP rating IP67

M12 Panel Mount

www.renhotecpro.com sale@renhotec.com

M12 R/A Panel Mount Connector

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: PCB

Electrical & Mechanical data

Connection type Front Mount Orientation Right Angle Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ Shielding Non-Shielded IP rating IP67

M12 Panel Mount

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin /12Pin Coding: A/B/D Code Termination: PCB /Soldering Cable Length: Base on customer request

M12 Flange Mount Connector

www.renhotecpro.com sale@renhotec.com Connection type Front Mount Orientation Straight Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ Shielding Non-Shielded IP rating IP67

Electrical & Mechanical data

M12 Field Installable Connector

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: Screw-joint Cable Length: Base on customer request

M12 Field Installable Cable Connector

www.renhotecpro.com sale@renhotec.com Connection Type Field wireable Orientation Straight Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Shell material Pastic Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ IP rating IP67

Electrical & Mechanical data

M12 Field Installable Connector

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin /12Pin Coding: A/B/D Code Termination: Screw-Joint

M12 R/A Field Installable Connector

www.renhotecpro.com sale@renhotec.com

Electrical & Mechanical data

Connection Type Field wireable Orientation Right Angle Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Shell material Pastic Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ IP rating IP67

M12 Field Installable Connector

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: Screw-joint Cable Length: Base on customer request

M12 Field Installable Cable Connector

www.renhotecpro.com sale@renhotec.com Connection Type Field wireable Orientation Straight Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Shell material Metal Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ IP rating IP67

Electrical & Mechanical data

M12 Field Installable Connector

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin /8Pin/12Pin Coding: A/B/D Code Termination: Screw-joint Cable Length: Base on customer request

M12 Field Installable Cable Connector

www.renhotecpro.com sale@renhotec.com Connection Type Field wireable Orientation Right Angle Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Shell material Pastic/Metal Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ IP rating IP67

Electrical & Mechanical data

M12 Adapter

Gender: Male to Female Number of Contacts: 3Pin /4 Pin /5Pin /6Pin /8Pin Coding: A/B/D Code Termination: Soldering Cable Length: Base on customer request

M12 T Type Adapter

www.renhotecpro.com sale@renhotec.com Connection type Soldering Orientation T type/Y type Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ Shielding Non-Shielded IP rating IP67

Electrical & Mechanical data

M12 Molding Cable

Gender: Male/Female Number of Contacts: 3Pin /4 Pin /5Pin/8Pin/12Pin Coding: A/B/D Code Termination: Soldering Cable length: base on customer request

M12 Molding Cable

www.renhotecpro.com sale@renhotec.com Connection Type Single ended cable/Double ended cable Cable jacket material PVC/PUR (by Custom) Orientation Straight/Right Angle Insert/ Housing NYLON66 + GF Rated current 4A：3/4/5PIN 2A：8PIN 1.5A: 12PIN Rated voltage 250V：3/4/5PIN 60V: 8PIN 30V: 12PIN Connector contacts Brass with gold plated Coupling nut/screw Brass with nickel plated screw Ambient temperature

• 40°C ~ + 85°C

Insulation resistance ≥100 MΩ Contacts resistance ≤ 5 mΩ IP rating IP67

Electrical & Mechanical data

M12 Dust Cap

Description IP67 M12 male & female connector's protection cap with strip and rubber gasket inside which kept the connector from dust or water invade. Gender: Male/Female Termination: Soldering Electrical & Mechanical data

M12 Dust Cap

www.renhotecpro.com sale@renhotec.com Overmold/ Shell NYLON66 + GF Coupling nut/screw Metal/Plastic Sealing Straight/Right Angle Temperature Range

• 40°C ~ + 85°C

THANK YOU

Please feel free to contact us to get free samples for testing . Welcome to view our web:

• www.renhotecpro.com
• www.elecbee.com

Welcome to contact us:

• sale@renhotec.com
