FP6 CONCERTO II REMINING LOWEX Redevelopment of European Mining Areas into Sustainable Communities by Integrating Supply and Demand Side based on Low Exergy Principles Peter Op ‘t Veld – coordinator Cauberg-Huygen Consulting Engineers Maastricht - the Netherlands

Demonstration Four ambitious local communities (Heerlen the Netherlands, Zagorje Slovenia, Czeladz Poland and Bourgas Bulgaria will demonstrate the use of local available low valued renewable energy sources, specifically from water in abandoned mines for heating and cooling of buildings, based on low exergy principles, facilitated by an integrated design of buildings and energy concepts. They will realize 2 sustainable mining communities (Heerlen and Zagorje) with 50 to 100% CO2 reduction and 60% RES compared with standard national practices. The two demonstration sites contain 440 new houses, 57000 m2 non residential new buildings, 84500 m2 non residential existing buildings, and 3 existing prepared buildings to connect with the mine water grid in Heerlen and 6000 m2 new and 2000 m2 existing buildings connected to mine water and 1154 existing houses connected to biomass in Zagorje. Feasibility studies leading to concrete local sustainable energy plans and implementation will be demonstrated in Czeladz, Bourgas, Zagorje and the nearby former mining communities in Heerlen. Dissemination Dissemination takes place in different levels: direct transfer of knowledge to the REMINING communities, use of geothermal energy and heat/cold storage in mines to mining areas in Europe, Russia and Ukraine by involving EURACOM, and the use of local available low valued renewable energy sources in combination with an integrated energy design of buildings for the development of sustainable communities in general, by involving the European Climate Alliance and the LowEx network. Social aspects REMINING has special emphasis of the social aspects in (former) mining communities like unemployment, fuel poverty, poor health conditions resulting in poor quality of life, environmental problems. An integrated sustainable redevelopment will contribute to a high extent in the rehabilitation of this areas and integrating RES from local available sources in combination with RUE in new and existing buildings.

…a bit of history, from Interreg Minewater project to CONCERTO II Remining-lowex • Interreg Mine Water Project: concerning the feasibility and realisation of an energy supply structure based on the use of mine water (with a pilot in Heerlen 2004-2008) • CONCERTO II Remining-Lowex: realisation of communities with an energy supply and energy demand based on the use of low valued energy i.e. mine water but also other RES • Balancing supply and demand, based on the use of RES in “ECO-buildings” • Including the RE sources, infrastructure and buildings

What is REMINING-Lowex about? • Developing sustainable communities in mining and former mining areas • Using water for abandoned mines in combination with other local renewable sources for heating and cooling of buildings • Balancing the local energy demand (buildings) with the local available low valued energy sources (renewables, i.e. mine water, but also other renewables) • Total eligible costs € 39.565.400 • Total funding € 7.226.357 • Duration: five years

What means ‘Lowex’? • Lowex = low exergy • Taking into account the quality of the energy carries for demand and supply • Try to match the quality of energy of the demand with the supply side

Exergy » The valuable part of energy« • Exergy = Energy x Energy- Quality-factor • 100kJ 1 kg water 12 V at 43° C 2.3 Ah • Known method for, e.g. power stations => here application for buildings

The REMINING Communities • Communities and community partners involved: – Heerlen Netherlands (investments) • Heerlen • Weller • RGD – Zagorje Slovenia (investments) • Zagorje • Mining Zagorje • KOP Municipality services – Czeladz Poland (feasibility) • Czeladz • (CZOK) – Bourgas (Cherno More) Bulgaria (feasibility) • Bourgas

The REMINING communities Fife Council University of Silesia BRE VKA I VKA III Aachen Heerlen S.Limburg/ Silesian basin Heusden Coal Mining Area Coal Mining Area Campina basin REMINING Demo VKA II REMINING Concerto Community Czdz Zasavje basin REMINING Observer REMINING Associated Community VKA IV

Other REMINING partners involved: – Cauberg-Huygen (coordinator) NL – University of Ljubljana SLO – University of Silezia PL – Bulgarian Academy of Science BG – Lowexnet represented by Fraunhofer DE And for dissemination – Climate Alliance EU – EURA COM EU

REMINING Structure • Vertical Activities: Key Actions > the pilot communities Heerlen Municipality – VKA I: Heerlen Zagorje Municipality – VKA II: Zagorje Czeladz Municipality – VKA III: Czeladz Bourgas Municipality – VKA IV: Bourgas Climate Alliance – (VKA V: EU (+) Dissemination) • Horizontal Activities: Work Packages CHRI – WP 1: Management UoLJ – WP 2: Research UoS – WP 3: Demonstration Weller – WP 4: Energy Exploitation Heerlen – WP 5: Legal Aspects Fraunhofer – WP 6: Training – WP 7 : Network and Dissemination Climate Alliance/Euracom

VKA I NL VKA II SLO VKA III PL VKA IV BG VKA V EU+ Parkstad Limburg Zagorje Czeladz Bourgas (Cherno I.1 I.2 I.3 More) WP1: Project Management and Internal Communication WP2 Supporting Research Activities WP2.1 WP2.2 WP2.3 WP2.4 WP3: Demonstration WP 3.3 WP3.4 WP3.1 WP3.2 WP4:Energy Exploitation WP5:Legal Issues WP6:Training WP7:Network and Dissemination

The REMINING Pilot Locations • 2 ‘CONCERTO’ locations: investments and ‘real projects’ – Heerlen, the Netherlands – Zagorje, Slovenia • 2 Associated locations: feasibility and implementation plan (no investments) – Czeladz, Poland – Bourgas, Bulgaria

Lowex approach for the Mine Water Project Heerlen: balancing supply side (RES) with demand side (RUE) on basis of low exergy principles demand Buildings suitable for use of low valued energy (LTH distribution and HTC) LT DH&C 3-pipes system supply Minewater Additional RES Integral system biomass, solar approach for the total built environment

Simulations and reservoir models…. tracer 1 distribution HH1 HH2 shaft C Temperature difference to T0 = 27.7 ° 180 0.3 170 measured DT (t0 = 27.7° C) at HH1 modelled DT 160 0.2 re-injected water - tracer 1 stone drift - zone 2 150 mined zone - tracer 2 0.1 140 mined zone - tracer 3 mined zone - tracer 5 130 0 120 -0.1 110 100 Tracer concentration (mmol/l) -0.2 I II III IV V 90 80 -0.3 0 5 10 15 20 70 -0.4 60 50 -0.5 40 445 m -0.6 30 520 m 20 injection -0.7 10 well HH1 600 m -0.8 0 Time (days) production well HH2 N

….in combination with the old mine maps to determine drilling locations……

Buildings Heerlerheide Centre Heerlerheide H C R phase 1 17 0 C 20…23 0 C 35…40 0 C Energy station 2 Warm Wells Heerlerheide Centre HP HP 25…35 0 C Intermediate Well Heerlen SON 17…20 0 C phase 2 Energy stations Energy 2 Cold Wells buildings stations Energy buildings stations Energy buildings station Maankwartier HP HP

Pilot Demonstration Activities VKA I Heerlen

VKA I.1 Heerlerheide Centre - Buildings • 312 apartments • 3800 m2 commercial buildings • 2500 m2 public and cultural buildings • 11500 m2 health care buildings • 2200 m2 educational buildings • energy station

VKA I.2 Heerlen Centre New buildings Location Maankwartier • 110 apartments • 14000 m2 commercial New CBS office • 4000 m2 hotel • 21000 m2 offices • 19000 m2 offices

VKA I.2 and I.3 Heerlen Centre Retrofitting of Existing Office Buildings CBS building ABP building 43500 m2 offices 41000 m2 offices

The CONCERTO Pilot Zagorje • Specific circumstances concerning local available renewables: – Large volumes of biomass – Cold and warm mine water wells close to surface • Activity 1: Enlarging biomass district heating • Activity 2: Low energy buildings (2 new, 1 retrofitted) with connection to mine water • Activity 3: Retrofitting residential buildings and connection to biomass grid • Activity 4: Energy monitoring and certification

Pilot Demonstration Activities VKA II Zagorje

VKA II Zagorje ob Savi Activity 1: Municipality youth centre Enlarging biomass net district heating Activity 2: Low energy buildings with connection to minewater Activity 3: Retrofitting residential buildings and connection to biomass grid Activity 4: Energy Monitoring Post war multi family and Certification buildings

Activity 2: Low energy buildings with connection to minewater

Activity 3: Retrofitting residential buildings and connection to biomass grid

Activity 4: Energy Monitoring and Certification
