SLIDE 1

Recognizing and Imitating Programmer Style: Adversaries in Program Authorship Attribution

Lucy Simko, Luke Zettlemoyer, Tadayoshi Kohno

sim

simkol@cs.washington.edu homes.cs.washington.edu/~simkol

SLIDE 2

2

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D C A B E F

?

SLIDE 3

Caliskan-Islam et al. “De-anonymizing programmers via code stylometry.” 24th USENIX Security Symposium (USENIX Security), Washington, DC. 2015.

98% accuracy over 250 programmers
Extract syntactic, lexical, and layout features from C/C++ code
Random Forest classifier
Data set: Google Code Jam

○ Programming competition ○ Lots of examples of people solving the same problem in different ways

Open source

3

State of the Art: Source Code Attribution

SLIDE 4

4

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D C A B E F

?

98% accuracy!

SLIDE 5

5

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D C A B E F

?

98% accuracy!

SLIDE 6

6

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D C A B E F

?

98% accuracy!

C E N S O R E D C E N S O R E D

SLIDE 7

Can we fool source code attribution classifiers?

7

Research Question

Yes!

Methodology: Lab study* with C programmers

*Approved by University of Washington’s Human Subjects Division (IRB)

SLIDE 8

Motivation and Research Question
Source Code Attribution: Overview and Background
Evading Source Code Attribution: Definitions and Goals
Methodology
Results: Conservative Estimate of Adversarial Success
Results: How to Create Forgeries

8

Outline

SLIDE 9

9

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D C A B E F

?

SLIDE 10

10

Source Code Attribution

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

D

C

A B E F

Classifier

SLIDE 11

int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; ...

11

Source Code Attribution

D

C

A B E F

Classifier

Pc

SLIDE 12

12

Source Code Attribution

Classifier

{A, B, C, D, E}

Pc

C

SLIDE 13

13

Source Code Attribution

Classifier

Pc

{A, B, C, D, E}

C ✓

Who the classifier thinks wrote this code.

SLIDE 14

Motivation and Research Question
Source Code Attribution: Overview and Background
Evading Source Code Attribution: Definitions and Goals
Methodology
Results: Conservative Estimate of Adversarial Success
Results: How to Create Forgeries

14

Outline

SLIDE 15

1. Train: Given code from original and target authors, learn styles
2. Modify original code to imitate target author (forgery)
Or just hide the original author’s style (masking)

15

Evading Source Code Attribution

Pc

Adversarial manipulation Pc’

Code originally by C, but modified by an adversary.

SLIDE 16

1. Train: Given code from original and target authors, learn styles
2. Modify original code to imitate target author (forgery)
Or just hide the original author’s style (masking)

16

Evading Source Code Attribution

Pc

Adversarial manipulation Pc’

{A, B, C, D, E}

Classifier

A

Forgery

SLIDE 17

Motivation and Research Question
Source Code Attribution: Overview and Background
Evading Source Code Attribution: Definitions and Goals
Methodology
Results: Conservative Estimate of Adversarial Success
Results: How to Create Forgeries

17

Outline

SLIDE 18

Lab Study: Dataset

C code
We used a linter1 to eliminate many typographic style differences
~4000 authors: avg 2.2 files each
5 authors with the most files: avg ~42.8 files

○ Authors: A, B, C, D, E

1 http://astyle.sourceforge.net/

SLIDE 19

Lab Study: Create Forgeries

C5 {A, B, C, D, E}

Precision: 100% Recall: 100% (10-fold XV)

SLIDE 20

Lab Study: Create Forgeries

C20 {A, B, C, D, E, ... + 15}

Precision: 87.6% Recall: 88.2% (10-fold XV)

SLIDE 21

Lab Study: Create Forgeries

C50 {A, B, C, D, E, ... + 45}

Precision: 82.3% Recall: 84.5% (10-fold XV)

SLIDE 22

22

Lab Study: Create Forgeries

28 C programmers (participants):

1. Train: Given code from original and target author, learn styles
2. Modify original code to imitate target author’s style (forgery)

Px

Participant modifies Px

Classifier

Y

Forgery X, Y ∈ {A, B, C, D, E}

Px’

SLIDE 23

23

Lab Study: Create Forgeries

28 C programmers (participants):

1. Train: Given code from original and target author, learn styles
2. Modify original code to imitate target author’s style (forgery)
3. Check forgery success against oracle classifiers

X, Y ∈ {A, B, C, D, E}

Px’

X

C5

Y Y

C20 C50

Px

Participant modifies Px

SLIDE 24

Motivation and Research Question
Source Code Attribution: Overview and Background
Evading Source Code Attribution: Definitions and Goals
Methodology
Results: Conservative Estimate of Adversarial Success
Results: How to Create Forgeries

24

Outline

SLIDE 25

Percent of final forgery attempts that were successful attacks

C5 C20 C50 Forgery 66.6% 70.0% 73.0% Masking 76.6% 76.6% 86.6%

25

Versions of the state-of-the-art machine classifier. The subscript indicates the number of authors in the training set.

Results: Estimate of Adversarial Success

SLIDE 26

C5 C20 C50 Forgery 66.6% 70.0% 73.0% Masking 76.6% 76.6% 86.6%

Percent of final forgery attempts that were successful attacks

26

Forgery: adversary is pretending to be a specific target author. Masking: adversary is obscuring the original author.

Results: Estimate of Adversarial Success

SLIDE 27

C5 C20 C50 Forgery 66.6% 70.0% 73.0% Masking 76.6% 76.6% 86.6%

Percent of final forgery attempts that were successful attacks

27

A successful forgery attack means the classifier output the target author instead of the original author of the code. 66.6% of forgery attacks against the C5 classifier were successful.

Results: Estimate of Adversarial Success

SLIDE 28

C5 C20 C50 Forgery 66.6% 70.0% 73.0% Masking 76.6% 76.6% 86.6%

Percent of final forgery attempts that produced a misclassification

28

C50 attributed forgeries correctly only 13.4% of the time.

Results: Estimate of Adversarial Success

SLIDE 29

Percent of final forgery attempts that produced a misclassification

Lesson: Non-experts can successfully attack this state-of-the-art classifier, suggesting other authorship classifiers may be vulnerable to the same type

f attacks.

29

Results: Estimate of Adversarial Success

C5 C20 C50 Forgery 66.6% 70.0% 73.0% Masking 76.6% 76.6% 86.6%

SLIDE 30

Motivation and Research Question
Source Code Attribution: Overview and Background
Evading Source Code Attribution: Definitions and Goals
Methodology
Results: Conservative Estimate of Adversarial Success
Results: How to Create Forgeries

30

Outline

SLIDE 31

Lesson: Forgers did not know the features the classifier was using for attribution. This suggests that forgeries in the wild might contain the same types of modifications.

31

Results: Methods of Forgery Creation

SLIDE 32

Example: Two Programs by Author C

// libraries imported #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) // variables defined int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1; // libraries imported #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) // variables defined int main() { int i, j, k, l, m, n, t, ok; int a, b, c; int size, count = 0; scanf ("%d", &size); while (size--) { scanf ("%d%d", &n, &m); rep (i, m) { scanf ("%d", s + i);

SLIDE 33

// libraries imported #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) // variables defined int main() { int i, j, k, l, m, n, st; char in[10000]; int fg[5000], chk[128]; int size, count = 0, res; scanf ("%d%d%d", &len, &n, &size); rep (i, n) scanf ("%s", dic[i]); while (size--) { scanf ("%s", in); st = 0; rep (k, n) fg[k] = 1;

Example: Two Programs by Author C

// libraries imported #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) // variables defined int main() { int i, j, k, l, m, n, t, ok; int a, b, c; int size, count = 0; scanf ("%d", &size); while (size--) { scanf ("%d%d", &n, &m); rep (i, m) { scanf ("%d", s + i);

SLIDE 34

Example: Forgery of Author C

Information Structure

Variable name
Syntax
Macros
API calls

Control Flow

Loop type

SLIDE 35

Example: Creating a Forgery of Author C

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

35

Classifier output: A

SLIDE 36

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

ORIGINAL FORGERY

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

36

Classifier output: A Classifier output: ??

SLIDE 37

ORIGINAL FORGERY

37

Classifier output: A Classifier output: ??

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

SLIDE 38

ORIGINAL FORGERY

38

Classifier output: A Classifier output: ??

#define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; cin >> size; for(count=1;count<=size;count++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

SLIDE 39

ORIGINAL FORGERY

39

Classifier output: A Classifier output: ??

#define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; cin >> size; for(count=1;count<=size;count++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

SLIDE 40

ORIGINAL FORGERY

40

Classifier output: A Classifier output: ??

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; scanf("%d", &size); for(count=1;count<=size;count++) { scanf("%d%d%d%d", &D, &I, &M, &N); for(i=0; i<N; i++) scanf("%d", original+i); ...

SLIDE 41

ORIGINAL FORGERY

41

Classifier output: A Classifier output: ??

#define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; scanf("%d", &size); while (size--) { scanf("%d%d%d%d", &D, &I, &M, &N); rep (i,N) scanf("%d", original+i); ... int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ...

SLIDE 42

ORIGINAL FORGERY

42

Classifier output: A Classifier output: ??

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; scanf("%d", &size); while (size--) { scanf("%d%d%d%d", &D, &I, &M, &N); rep (i,N)scanf("%d", original+i); ...

SLIDE 43

ORIGINAL FORGERY

43

Classifier output: A Classifier output: C

int main() { int i,j,k; int cc,ca; cin >> ca; for(cc=1;cc<=ca;cc++) { cin >> D >> I >> M >> N; for(i=0; i<N; i++) cin >> original[i]; ... #define REP(i,a,b) for(i=a;i<b;i++) #define rep(i,n) REP(i,0,n) int main() { int i,j,k; int size, count = 0; scanf("%d", &size); while (size--) { scanf("%d%d%d%d", &D, &I, &M, &N); rep (i,N)scanf("%d", original+i); ...

SLIDE 44

44

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls

Control Flow

Loop type

SLIDE 45

45

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location

Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic

SLIDE 46

46

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location

Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic

Local modifications:

nly need to

understand a line or two of code

Local

SLIDE 47

47

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location

Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic

Local modifications:

nly need to

understand a line or two of code Algorithmic modifications: need a more comprehensive understanding of the code

Local

SLIDE 48

48

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location
Variable type
Data structures
Static and dynamic

memory usage Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic

Local modifications:

nly need to

understand a line or two of code Algorithmic modifications: need a more comprehensive understanding of the code

Local Algorithmic

SLIDE 49

49

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location
Variable type
Data structures
Static and dynamic

memory usage Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic

Local modifications:

nly need to

understand a line or two of code Algorithmic modifications: need a more comprehensive understanding of the code

Local Algorithmic

X

SLIDE 50

50

Results: Methods of Forgery Creation

Information Structure

Variable name
Syntax
Macros
API calls
Libraries imported
Variable decl location
Variable type
Data structures
Static and dynamic

memory usage Control Flow

Loop type
If-statements
Assignments per line
Control flow keywords
Loop logic
Functions refactored
Inlined API calls
Major addition or

removal of control structures Local modifications:

nly need to

understand a line or two of code Algorithmic modifications: need a more comprehensive understanding of the code

Local Algorithmic

X

SLIDE 51

Lessons from methods of forgery creation:

Local modifications are common.
Some forgers copied code directly the target author’s training set.

51

Results: Methods of Forgery Creation

SLIDE 52

Programmers desiring privacy or with malicious intent may seek to

evade source code attribution classifiers

Lab study with C programmers producing forgeries, showing

unsophisticated adversaries can fool a state of the art classifier

Forgeries were successful with local changes that do not require a

high-level understanding of the programming style.

More recommendations in paper!

My coauthors: Luke Zettlemoyer, Tadayoshi Kohno Contact me: Lucy Simko, simkol@cs.washington.edu, https://homes.cs.washington.edu/~simkol/

52
