Fast Synthesis of Fast Collections Calvin Loncaric Emina Torlak Michael D. Ernst University of Washington

Data structures are everywhere Lists, maps, and sets solve many problems What if I need a custom data structure? 2

Cozy synthesizes collections Rep. Impl. Inductive Specification Outline Rep. Impl. Verifier Synthesizer Rep. Impl. • Correct by construction • Specifications orders-of-magnitude shorter than implementations, synthesized in < 90 seconds • Equivalent performance to human-written code 3

Myria Analytics Storage Request 1 Goal: efficient retrieval of entries for a particular request ID in a Request 2 particular timespan time 4




 Myria Analytics Storage Insert an entry into the data structure class AnalyticsLog {
 void log (Entry e)
 Iterator<Entry> getEntries (
 int queryId,
 int subqueryId,
 int fragmentId,
 long start,
 long end)
 Retrieve entries } 5




 Myria Analytics Storage Specification: class AnalyticsLog {
 Entry has:
 queryId : Int,
 subqueryId : Int,
 void log (Entry e)
 fragmentId : Int,
 start, end : Long,
 Iterator<Entry> getEntries (
 … int queryId,
 int subqueryId,
 getEntries : all e where
 int fragmentId,
 e.queryId = queryId and
 e.subqueryId = subqueryId and
 long start,
 e.fragmentId = fragmentId and
 long end)
 e.end >= start and
 e.start <= end } 6








 Cozy synthesizes collections Specification: class Structure {
 Entry has:
 field1 : Type1 ,
 field2 : Type2 ,
 void add (Entry e)
 …,
 void remove (Entry e)
 start, end,
 Cozy void update (Entry e, …)
 … Iterator<Entry> retrieveA (…)
 retrieveA : all e where
 Iterator<Entry> retrieveB (…)
 condition
 e.subqueryId = subqueryId and
 retrieveB : all e where
 }
 condition art and
 e.start <= end 7


 Trivial Solution retrieve : all e where
 P(e, input)
 List<Entry> data;
 There has to be a better way! Iterator<Entry> retrieve (input) {
 for e in data:
 if P(e, input) :
 yield e
 } 8


 Entry has:
 void add (Entry e)
 field1 , field2 , …
 void remove (Entry e)
 Intractable retrieveA : all e where
 void update (Entry e, …)
 condition
 retrieveB : all e where
 Iterator retrieveA (…)
 condition Iterator retrieveB (…) synthesis Specification Implementation algorithm Tractable ? Tractable Specification → Outline Outline → Implementation In the quest for a good solution, the specific enough to describe search space of “all asymptotic performance Outline possible programs” general enough to encode is simply too large a data structure succinctly 9

Outlines Plans for retrieving entries • All ( ) • HashLookup ( outline, field = var ) • BinarySearch ( outline, field > var ) • Concat ( outline 1 , outline 2 ) • Filter ( outline, predicate ) 10

Outlines → Implementations Rep. Rep. Impl. Impl. Inductive Inductive Specification Specification Outline Outline Rep. Rep. Impl. Impl. Verifier Verifier Synthesizer Synthesizer Rep. Rep. Impl. Impl. 11




 Outlines → Implementations class Structure {
 HashLookup (
 T data;
 All (),
 Iterator<Entry>
 e.queryId = q ) retrieve (q) { … }
 }
 12




 Outlines → Implementations class Structure {
 HashLookup (
 T data;
 data ,
 Iterator<Entry>
 e.queryId = q ) retrieve (q) { … }
 }
 13




 Outlines → Implementations class Structure {
 HashLookup (
 HMap< K,V > data;
 data ,
 Iterator<Entry>
 e.queryId = q ) retrieve (q) { … }
 }
 14




 Outlines → Implementations class Structure {
 HashLookup (
 HMap<int ,V > data;
 data ,
 Iterator<Entry>
 e.queryId = q ) retrieve (q) { … }
 }
 V = ArrayList<Entry> V = LinkedList<Entry> 15




 Outlines → Implementations class Structure {
 HashLookup (
 HMap<int , V> data;
 data ,
 Iterator<Entry>
 e.queryId = q ) retrieve (q) { … }
 }
 16





 Outlines → Implementations add, remove, class Structure {
 update HashLookup (
 HMap<int , V> data;
 data ,
 Iterator<Entry>
 e.queryId = q ) retrieve (q)
 { v = data.get(q);
 return v.iterator(); } 17

Specification → Outline Rep. Rep. Impl. Impl. Inductive Inductive Specification Specification Outline Outline Rep. Rep. Impl. Impl. Verifier Verifier Synthesizer Synthesizer Rep. Rep. Impl. Impl. 18

Specification → Outline CEGIS Remembers all Must ensure the examples; only outline is correct for reasons about all possible inputs examples collected and all possible data candidate thus far. structure states. Inductive Verifier Synthesizer retrieve : all e where
 e.queryId = q and … counterexample - or - ∀ I ∀ S , out = certification of correctness { e | e ∈ S ∧ P ( I , e ) } 19

Cost Model O ( n ) O (1) O (1) O (1) Filter (
 HashLookup (
 > All (),
 All (),
 e.queryId = q ) e.queryId = q ) Cozy prefers outlines with lower cost 20

Inductive Synthesis Enumerative search Concat( HashLookup(…) ,…) vs correct on all current examples Concat( Filter(…) ,…) size 1 size 2 size 3 HashLookup( HashLookup(All, x=y) HashLookup(…), a=b) Filter( Filter( All Filter(All, x=y) HashLookup(…), p=q) HashLookup(…), p=q) Filter( BinarySearch(All, x>y) BinarySearch(…), x<y) … … 21




 Outline Verification Specification: HashLookup (
 All (),
 { e | e ∈ S ∧ P ( I , e ) } { e | e ∈ S ∧ Q ( I , e ) } Entry has:
 queryId : Int,
 e.queryId = q) subqueryId : Int,
 … representative predicate Q retrieve : all e where
 P e.queryId = q and …
 e.queryId = q 22

Outline Verification ? = { e | e ∈ S ∧ P ( I , e ) } { e | e ∈ S ∧ Q ( I , e ) } yes if and only if for all I , e : P ( I , e ) = Q ( I , e ) equivalence can be checked with an SMT solver 23

Evaluation • Improve correctness • Save programmer effort • Match performance 24

Case studies • Myria: analytics • ZTopo: tile cache Analytics data Tracks map tiles in a indexed by least-recently-used timespan and by cache request ID 11 bugs • Bullet: volume tree • Sat4j: variable metadata Stores axis-aligned Tracks information bounding boxes for fast about each variable collision detection in the formula 15 bugs 7 bugs 25

Specifications vs. Implementations Original Spec 2582 Lines of code 1383 269 292 22 25 11 23 Myria ZTopo Sat4j Bullet 26

Synthesis Time Outline Synthesis Auto-Tuning 90 Time (s) 60 30 0 Myria ZTopo Sat4j Bullet 27

Performance Original Synthesized Data structures are Binary search tree vs. Small overhead; Original implementation has nearly identical space partitioning tree performance dominated worst-case linear time by other factors Myria ZTopo Bullet Sat4j 28

Related Work • J. Earley: “ High level iterators and a method for automatically designing data structure representation ” (1974) • Hard-coded rewrite rules • S. Agrawal et al: “ Automated selection of materialized views and indexes in sql databases ” (2000) • Enumerate possible views & indexes based on query syntax and use the planner to decide which ones to keep • P. Hawkins et al: “ Data representation synthesis ” (2011) • Enumerate representations and use a planner to implement retrieval operations; conjunctions of equalities only 29

http://cozy.uwplse.org Rep. Impl. Inductive Specification Outline Rep. Impl. Verifier Synthesizer Rep. Impl. • Implementation outlines make the Special thanks to: problem tractable • Synthesis completes < 90 seconds • Cozy generates correct code, and Michael Emina matches handwritten implementation Ernst Torlak performance also Haoming Liu & Daniel Perelman 30
